SMT Software Engineering Group
IM Operations YAMAHA MOTOR CO., LTD.
MDOC-SOFT50225
4. Error message list
Table4.1 Error message list
Error
No.
Title Cause and measure
12959
Cannot Use Parts
Shape Teaching
The parts shape teaching does not support the recognition
algorithm used in the parts of this mount data.
Use the point teaching or the cursor teaching.
Mount No.: XXX
Parts No.: XXX
Parts Name: XXX
5. Support / non-support list for every recognition
algorithm
Refer to the following table whether each recognition algorithm supports the parts shape
teaching.
Table5.1 Support / non-support list for every recognition algorithm
Alignment
Group
Alignment
Type
Algorithm
Supported by
parts shape teach
(O: support,
X: non-support)
Normal
O
1: Chamfer Lead
O
2: Check Lead Brightness
O
3: Check Direction
O
4: Check Center Brightness
O
5: Retry Lead Center Search
O
Std.Chip
8: Chip Array
O
Melf Chip Normal
O
Normal
O
12: Size Fitting
O
Bare.Chip
14: Small Bare Chip
O
Cylinder Normal
X
Sp.Chip Normal
O
Chip
Small Chip Normal
O
Normal
O
1: Check Polarity
O
Ball Simple BGA
3: Simple White BGA
O
SMT Software Engineering Group
IM Operations YAMAHA MOTOR CO., LTD.
MDOC-SOFT50225
Normal
O
4: White BGA
O
7: CGA
O
10: Check Direction
O
BGA
12: Ball Circularity Check
O
Normal
O
Simple FlipChip
1: Outside Bump Recognition
O
Normal
O
FlipChip
2: Simple High Speed
O
Normal
O
3: Check Direction
O
2Ends
10: Check Upside-Down
O
Normal
O
Mini-Tr/SOT
4: Check Upside-Down
O
P-Tr Normal
O
Normal
O
1: Side Lead Fitting
O
5: Check Upside-Down
O
6: Check Global Lead Bend
O
7: Direction Check by Lead Width
O
SOP
8: Check Lead Position
O
SOJ Normal
O
Normal
O
1: Side Lead Fitting
O
QFP
4: Check Lead Length
O
Normal
O
1: Side Lead Fitting
O
2: NS Base Search
O
3: WE Base Search
O
PLCC
4: Check Direction
O
IC
OffLead Normal
O
Con-E Normal
O
Con-NSEW Normal
O
Connector
Odd.Con Normal
O
1: Side Lead Fitting
O
2: Long Connector
O
Special
9: Insertion-Component
O
Odd.Chip Normal
O
Normal
X
1: Mark Line
X
2: 2 Objects
X
3: 4 Objects
X
Special
AsMark
4: General
X
SMT Software Engineering Group
IM Operations YAMAHA MOTOR CO., LTD.
MDOC-SOFT50225
6: Check Direction
X
8: 2 Objects (Angle of Terminal)
X
Normal
X
3: Check Direction When “Center
Detection Algorithm”
is
“Center of Gravity”: X,
“Apex of Rectangle”: O
8: Shield Frame
O
10: Check Upside-Down When “Center
Detection Algorithm”
is
“Center of Gravity”: X,
“Apex of Rectangle”: O
Sp.Quad
11: 4 Corner Fitting
O
Gravity Normal
X
Ignore Normal
X
Smart Recognition Normal
X
