2/4
機種( M/C TYPE) ユニット( UNI T) 発行日
I P・QP2 モータフィーダ( MOTOR FEEDER) 00. 10. 27
形式( TYPE) 図番( DWG No. ) S/ N
W16 エンボス( EMBOSS) ( AKDCA61**) KDE‑ 1600‑ 004457〜
番号
品名 図番 個数
No. Dwg. No. QTY
備考
Remarks
Descri pt i on
ﾏｸﾞﾈｯﾄ MAGNET M1003X 5 丸型ﾈｵｼﾞ磁石φ 5x5
11 ｶﾊﾞｰ COVER KDCC1370 1
12 ﾌﾟﾚｰﾄ ｻｲﾄﾞ PLATE, SI DE AKDCC6531 1
ﾌﾟﾚｰﾄ ｻｲﾄﾞ PLATE, SI DE KDCC0821 1
ﾋﾟﾝ ｼﾃﾝ PI N, PI VOT KCAC0420 2
13 ｶﾞｲﾄﾞﾃｰﾌﾟ GUI DE, TAPE KDCC0042 1
14 ｼｬﾌﾄ SHAFT KDCC0053 3
15 ﾛｰﾗ ROLLER KDCC0061 2
16 ｽﾌﾟﾘﾝｸﾞ SPRI NG KDCC0100 1
17 ﾜｯｼｬ WASHER KDCC0111 3
18 ﾌﾟﾚｰﾄ ｻｲﾄﾞ PLATE, SI DE KDCC0124 1
19 ｵｻｴ ﾍﾞｱﾘﾝｸﾞ RETAI NER, BEARI NG KDCC0132 1
20 ﾌﾟﾚｰﾄ PLATE KDCC0742 1
21 ﾌﾟﾚｰﾄ PLATE AKDCC6550 1
ﾌﾟﾚｰﾄ PLATE KDCC1420 1
ﾌﾟﾚｰﾄ PLATE KDCC1340 1
22 ﾚﾊﾞｰ LEVER KDCC0190 1
23 ﾋﾟﾝ PI N KDCC0201 1
24 ｽﾍﾟｰｻ SPACER KDCC0231 4
25 ﾌﾟﾚｰﾄ PLATE KDCC0251 1
26 ﾋﾟﾝ PI N KDCC0262 1
27 ﾘｰﾙ REEL KDCC0282 1
28 ﾌﾟｰﾘ PULLEY KDCC0561 1
29 ﾋﾟﾝ PI N KDCC0321 1
30 ﾋﾟﾝ PI N KDCC0392 2
31 ﾛｰﾗ ROLLER KDCC0400 1
32 ｽﾌﾟﾘﾝｸﾞ SPRI NG KDCC0410 1
33 ｶﾊﾞｰ COVER KDCC0732 1
34 ﾌﾗﾝｼﾞ FLANGE KDCC0811 1
35 ﾌﾟｰﾘ ﾀｲﾐﾝｸﾞ PULLEY, TI MI NG KDCC0513 1
36 ﾌﾞﾛｯｸ BLOCK KDCC0530 1
37 ﾚﾊﾞｰ ｸﾗﾝﾌﾟ LEVER, CLAMP KCAC0310 1 ﾓｰﾀ軸ﾌﾞﾚｰｷ( A)
38 ﾚﾊﾞｰ ｸﾗﾝﾌﾟ LEVER, CLAMP KCAC0320 1 ﾓｰﾀ軸ﾌﾞﾚｰｷ( B)
39 ｽﾌﾟﾘﾝｸﾞ SPRI NG KCAC0330 1
42 ｵｻｴ RETAI NER KCAC0430 1
43 BKT BKT KDCC1491 1
http://www.fuji.co.jp/
Copyright © 2002 by Fuji Machine Manufacturing Co., Ltd. All Rights Reserved.
3/4
機種( M/C TYPE) ユニット( UNI T) 発行日
I P・QP2 モータフィーダ( MOTOR FEEDER) 00. 10. 27
形式( TYPE) 図番( DWG No. ) S/ N
W16 エンボス( EMBOSS) ( AKDCA61**) KDE‑ 1600‑ 004457〜
番号
品名 図番 個数
No. Dwg. No. QTY
備考
Remarks
Descri pt i on
44 BKT BKT KDCC1501 1
45 ﾋﾟﾝ PI N KCBC0681 1
46 ﾒｲﾊﾞﾝ NAMEPLATE KDCC0172 1
47 ﾛｰﾗ ROLLER KDCC0541 1
48 BKT ｾﾝｻ BKT, SENSOR KDCC0591 1
49 ﾋﾟﾝ ﾍﾝｼﾝ PI N, ECCENTRI C KDCC0601 1
50 ﾊｰﾈｽ HARNESS KHEH1240 1
51 ﾌﾟﾚｰﾄ PLATE KHEM1130 1
52 ﾊｰﾈｽ HARNESS KHEH1250 1
53 ｷﾊﾞﾝ ﾌﾟﾘﾝﾄ BOARD, PRI NTED CI RCUI T FH1091A 1
54 ｷﾊﾞﾝ ﾌﾟﾘﾝﾄ BOARD, PRI NTED CI RCUI T FH1108A 1
55 ｼｰﾙ SEAL KHER1120 1
57 ｷﾊﾞﾝ ﾌﾟﾘﾝﾄ BOARD, PRI NTED CI RCUI T FH1047E 1
58 ﾊｰﾈｽ HARNESS KHEH1260 1
59 ｽﾌﾟﾘﾝｸﾞ SPRI NG BFCA0101 1
61 ﾋﾟﾝ PI N BFCC0131 1
62 ﾋﾟﾝ PI N MCC0162 2
63 ｸﾘｯﾊﾟ CLI PPER K3015H 1 SL‑ 3N ( 品川商工)
64 ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ BELT, TI MI NG H4509N 1 344‑ 2GT‑ 9 ( ﾕﾆｯﾀ)
65 ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ BELT, TI MI NG H4509L 1 340‑ 2GT‑ 2 ( ﾕﾆｯﾀ)
66 ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ PI N, SPRI NG H2050T 1 3x16 AW
67 ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ WASHER, SPRI NG W1020H 2 2. 5M/ M
68 ｺﾈｼﾞ +ｱﾅﾅﾍﾞ SCREW, C/R PAN K5175S 2 M2x5
69 ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ WASHER, SPRI NG W1020A 2 2M/ M
70 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5359E 27 M4x8
71 ｺﾈｼﾞ 6ｶｸｱﾅﾎﾞﾀﾝ SCREW, HEX SOCKET BUTTON K5255T 3 M3x6
72 ﾎﾞﾙﾄ 6ｶｸｱﾅ BOLT, HEX SOCKET H5289A 2 M4x12
73 ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ WASHER, SPRI NG W1022A 6 4M/ M
74 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5357M 8 M3x6
75 ｺﾈｼﾞ 6ｶｸｱﾅﾎﾞﾀﾝ SCREW, HEX SOCKET BUTTON K5256A 4 M3x8
76 ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ WASHER, SPRI NG W1021A 15 3M/M
77 ｺﾈｼﾞ SCREW K5168L 2 M2. 5x12 ﾊﾞｲﾝﾄﾞ ｺﾈｼﾞ
78 ﾜｯｼｬ ﾋﾗ WASHER, FLAT W1042A 2 4W‑ 3
79 ﾅｯﾄ 6ｶｸ NUT, HEX N1076A 11 M3 P=0. 5
80 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5359A 2 M4x6
81 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5357T 5 M3x8
http://www.fuji.co.jp/
Copyright © 2002 by Fuji Machine Manufacturing Co., Ltd. All Rights Reserved.
4/4
機種( M/C TYPE) ユニット( UNI T) 発行日
I P・QP2 モータフィーダ( MOTOR FEEDER) 00. 10. 27
形式( TYPE) 図番( DWG No. ) S/ N
W16 エンボス( EMBOSS) ( AKDCA61**) KDE‑ 1600‑ 004457〜
番号
品名 図番 個数
No. Dwg. No. QTY
備考
Remarks
Descri pt i on
83 ﾅｯﾄ 6ｶｸ NUT, HEX N1075A 2 M2. 5
84 ﾅｯﾄ 6ｶｸ NUT, HEX N1080A 4 M4
85 ｻｰｸﾘｯﾌﾟ CI R‑ CLI P S1021A 2 STｰEWｰ3
86 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5357G 4 M3x4
87 ﾜｯｼｬ ﾋﾗ WASHER, FLAT W1041A 3 M4
90 ｺﾈｼﾞ 6ｶｸｱﾅﾎﾞﾀﾝ SCREW, HEX SOCKET BUTTON K52565 1 M4x6
91 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5358A 6 M3x10
92 ｺﾈｼﾞ +ｱﾅｻﾗ SCREW, C/R COUNTERSUNK K5169D 3 M2. 5x4
93 ﾎﾞﾙﾄ 6ｶｸｱﾅ BOLT, HEX SOCKET H5273A 1 M3x5
95 ｼｰﾙ SEAL KDCC0630 1
96 ｼｰﾙ SEAL BFCC0200 1
97 ｽﾄｯﾊﾟ STOPPER KDCC0641 1
98 ﾜｯｼｬ ﾋﾗ WASHER, FLAT W1039D 2 M2x0. 3x5( ﾐｶﾞｷ丸)
99 ｶﾊﾞｰ COVER KDCC0762 1
100 ｼｰﾄ SHEET KHEM1081 1
101 ｼｰﾄ SHEET KDCC1280 1
102 ﾛｰﾀﾘｰ SW ROTARY SW S3087S 1
103 ﾜｯｼｬ ﾋﾗ WASHER FLAT W1039H 2 2. 5M/ M
104 ﾎﾞﾙﾄ 6ｶｸｱﾅ BOLT, HEX SOCKET H5277A 7 M3X12
105 ﾜｯｼｬ ｻﾗ WASHER，CONI CAL W1010A 5 M−3−L
106 ﾌﾟﾚｰﾄ PLATE KDCC1221 1
107 ｺﾈｼﾞ +ｱﾅｻﾗﾅﾍﾞ SCREW, C/R PAN K51757 2 M2. 5x6
108 ﾜｯｼｬ ﾋﾗ WASHER, FLAT W1040A 5 M3
