4 / 4 機種( M / C TY P E) ユニット( U N I T) 発行日 I P ・Q P 2 モータフィーダ( M O TO R FEE D E R ) 0 0 . 1 0 . 2 7 形式( TY P E) 図番( D W G N o . ) S / N W 1 6 エンボス( E M B O S S) ( A K D C A 6 1 * * ) K D E‑ …
3/4
機種( M/C TYPE) ユニット( UNI T) 発行日
I P・QP2 モータフィーダ( MOTOR FEEDER) 00. 10. 27
形式( TYPE) 図番( DWG No. ) S/ N
W16 エンボス( EMBOSS) ( AKDCA61**) KDE‑ 1600‑ 004457〜
番号
品名 図番 個数
No. Dwg. No. QTY
備考
Remarks
Descri pt i on
44 BKT BKT KDCC1501 1
45 ﾋﾟﾝ PI N KCBC0681 1
46 ﾒｲﾊﾞﾝ NAMEPLATE KDCC0172 1
47 ﾛｰﾗ ROLLER KDCC0541 1
48 BKT ｾﾝｻ BKT, SENSOR KDCC0591 1
49 ﾋﾟﾝ ﾍﾝｼﾝ PI N, ECCENTRI C KDCC0601 1
50 ﾊｰﾈｽ HARNESS KHEH1240 1
51 ﾌﾟﾚｰﾄ PLATE KHEM1130 1
52 ﾊｰﾈｽ HARNESS KHEH1250 1
53 ｷﾊﾞﾝ ﾌﾟﾘﾝﾄ BOARD, PRI NTED CI RCUI T FH1091A 1
54 ｷﾊﾞﾝ ﾌﾟﾘﾝﾄ BOARD, PRI NTED CI RCUI T FH1108A 1
55 ｼｰﾙ SEAL KHER1120 1
57 ｷﾊﾞﾝ ﾌﾟﾘﾝﾄ BOARD, PRI NTED CI RCUI T FH1047E 1
58 ﾊｰﾈｽ HARNESS KHEH1260 1
59 ｽﾌﾟﾘﾝｸﾞ SPRI NG BFCA0101 1
61 ﾋﾟﾝ PI N BFCC0131 1
62 ﾋﾟﾝ PI N MCC0162 2
63 ｸﾘｯﾊﾟ CLI PPER K3015H 1 SL‑ 3N ( 品川商工)
64 ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ BELT, TI MI NG H4509N 1 344‑ 2GT‑ 9 ( ﾕﾆｯﾀ)
65 ﾍﾞﾙﾄ ﾀｲﾐﾝｸﾞ BELT, TI MI NG H4509L 1 340‑ 2GT‑ 2 ( ﾕﾆｯﾀ)
66 ﾋﾟﾝ ｽﾌﾟﾘﾝｸﾞ PI N, SPRI NG H2050T 1 3x16 AW
67 ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ WASHER, SPRI NG W1020H 2 2. 5M/ M
68 ｺﾈｼﾞ +ｱﾅﾅﾍﾞ SCREW, C/R PAN K5175S 2 M2x5
69 ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ WASHER, SPRI NG W1020A 2 2M/ M
70 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5359E 27 M4x8
71 ｺﾈｼﾞ 6ｶｸｱﾅﾎﾞﾀﾝ SCREW, HEX SOCKET BUTTON K5255T 3 M3x6
72 ﾎﾞﾙﾄ 6ｶｸｱﾅ BOLT, HEX SOCKET H5289A 2 M4x12
73 ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ WASHER, SPRI NG W1022A 6 4M/ M
74 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5357M 8 M3x6
75 ｺﾈｼﾞ 6ｶｸｱﾅﾎﾞﾀﾝ SCREW, HEX SOCKET BUTTON K5256A 4 M3x8
76 ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ WASHER, SPRI NG W1021A 15 3M/M
77 ｺﾈｼﾞ SCREW K5168L 2 M2. 5x12 ﾊﾞｲﾝﾄﾞ ｺﾈｼﾞ
78 ﾜｯｼｬ ﾋﾗ WASHER, FLAT W1042A 2 4W‑ 3
79 ﾅｯﾄ 6ｶｸ NUT, HEX N1076A 11 M3 P=0. 5
80 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5359A 2 M4x6
81 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5357T 5 M3x8
http://www.fuji.co.jp/
Copyright © 2002 by Fuji Machine Manufacturing Co., Ltd. All Rights Reserved.
4/4
機種( M/C TYPE) ユニット( UNI T) 発行日
I P・QP2 モータフィーダ( MOTOR FEEDER) 00. 10. 27
形式( TYPE) 図番( DWG No. ) S/ N
W16 エンボス( EMBOSS) ( AKDCA61**) KDE‑ 1600‑ 004457〜
番号
品名 図番 個数
No. Dwg. No. QTY
備考
Remarks
Descri pt i on
83 ﾅｯﾄ 6ｶｸ NUT, HEX N1075A 2 M2. 5
84 ﾅｯﾄ 6ｶｸ NUT, HEX N1080A 4 M4
85 ｻｰｸﾘｯﾌﾟ CI R‑ CLI P S1021A 2 STｰEWｰ3
86 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5357G 4 M3x4
87 ﾜｯｼｬ ﾋﾗ WASHER, FLAT W1041A 3 M4
90 ｺﾈｼﾞ 6ｶｸｱﾅﾎﾞﾀﾝ SCREW, HEX SOCKET BUTTON K52565 1 M4x6
91 ｺﾈｼﾞ 6ｶｸｱﾅｻﾗ SCREW, HEX SOCKET COUNTERSUNK K5358A 6 M3x10
92 ｺﾈｼﾞ +ｱﾅｻﾗ SCREW, C/R COUNTERSUNK K5169D 3 M2. 5x4
93 ﾎﾞﾙﾄ 6ｶｸｱﾅ BOLT, HEX SOCKET H5273A 1 M3x5
95 ｼｰﾙ SEAL KDCC0630 1
96 ｼｰﾙ SEAL BFCC0200 1
97 ｽﾄｯﾊﾟ STOPPER KDCC0641 1
98 ﾜｯｼｬ ﾋﾗ WASHER, FLAT W1039D 2 M2x0. 3x5( ﾐｶﾞｷ丸)
99 ｶﾊﾞｰ COVER KDCC0762 1
100 ｼｰﾄ SHEET KHEM1081 1
101 ｼｰﾄ SHEET KDCC1280 1
102 ﾛｰﾀﾘｰ SW ROTARY SW S3087S 1
103 ﾜｯｼｬ ﾋﾗ WASHER FLAT W1039H 2 2. 5M/ M
104 ﾎﾞﾙﾄ 6ｶｸｱﾅ BOLT, HEX SOCKET H5277A 7 M3X12
105 ﾜｯｼｬ ｻﾗ WASHER，CONI CAL W1010A 5 M−3−L
106 ﾌﾟﾚｰﾄ PLATE KDCC1221 1
107 ｺﾈｼﾞ +ｱﾅｻﾗﾅﾍﾞ SCREW, C/R PAN K51757 2 M2. 5x6
108 ﾜｯｼｬ ﾋﾗ WASHER, FLAT W1040A 5 M3
http://www.fuji.co.jp/
Copyright © 2002 by Fuji Machine Manufacturing Co., Ltd. All Rights Reserved.
1/4
機種( M/C TYPE) ユニット( UNI T) 発行日
I P・QP2 モータフィーダ( MOTOR FEEDER) 00. 10. 27
形式( TYPE) 図番( DWG No. ) S/N
W16 エンボス( EMBOSS) ( AKDCA71**) KDE‑ 1600‑ 004457〜
番号
品名 図番 個数
No. Dwg. No. QTY
1 ﾎﾝﾀｲ BODY AKDCC6505 1
ﾎﾝﾀｲ BODY KDCC0715 1
ﾍﾞｱﾘﾝｸﾞ ﾐﾆｭﾁｭｱ BEARI NG, MI NI ATURE H4443A 1 LF‑ 850ZZ ( NMB)
ﾍﾞｱﾘﾝｸﾞ ﾐﾆｭﾁｭｱ BEARI NG, MI NI ATURE H4450A 2 LF‑ 1480ZZ( NMB)
ﾋﾟﾝ ﾍｲｺｳ PI N, PARALLEL H2092F 4 A4x10SUS303
2 ｵｻｴ RETAI NER KDCC1261 1
3 ｵｻｴ ﾘｰﾙ RETAI NER, REEL AKDCC6021 1
ｵｻｴ ﾘｰﾙ RETAI NER, REEL KDCC0030 1
ﾌﾟﾚｰﾄ PLATE KDCC0160 1
4 ｼｬﾌﾄ SHAFT AKDCC6033 1
ｼｬﾌﾄ SHAFT KDCC0072 1
ﾌﾟｰﾘ ﾀｲﾐﾝｸﾞ PULLEY, TI MI NG KDCC0381 1
ｽﾌﾟﾛｹｯﾄ SPROCKET KCAC0241 1
ｺﾈｼﾞ +ｱﾅｻﾗ SCREW, C/R COUNTERSUNK K5169D 3 M2. 5x4
ｺﾈｼﾞ +ｱﾅﾅﾍﾞ SCREW, C/R PAN K51757 3 M2. 5x6
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ WASHER, SPRI NG W1020H 3 M2. 5
5 ﾌﾟﾚｰﾄ ﾘﾔ PLATE, REAR KDCC1311 1
6 ｷﾞﾔ GEAR AKDCC6133 1
ﾌﾟｰﾘ ﾀｲﾐﾝｸﾞ PULLEY, TI MI NG KDCC0551 1
ﾌﾟｰﾘ ﾀｲﾐﾝｸﾞ PULLEY, TI MI NG KDCC0422 1
ｼｬﾌﾄ ﾌﾟｰﾘ SHAFT, PULLEY KDCC0470 1
ｷﾞﾔ GEAR KCBC0401 1
ｺﾈｼﾞ +ｱﾅｻﾗ SCREW, C/R COUNTERSUNK K5169D 3 M2. 5x4
7 ﾌﾟﾚｰﾄ ﾘﾔ PLATE, REAR AKDCC6526 1
ﾌﾟﾚｰﾄ ﾘﾔ PLATE, REAR KDCC0756 1
ｽﾍﾟｰｻ SPACER KCBC0160 1
ﾍﾞｱﾘﾝｸﾞ ﾐﾆﾁｭｱ BEARI NG, MI NI ATURE H4569A 1 LFｰ630ZZ ( NMB)
8 ﾓｰﾀ ｽﾃｯﾋﾟﾝｸﾞ MOTOR, STEPPI NG AKDCC6072 1
ｶﾗｰ COLLAR KCAC0270 1
ｷﾞﾔ ﾋﾟﾆｵﾝ GEAR, PI NI ON KCAC0470 1
ﾓｰﾀ ｽﾃｯﾋﾟﾝｸﾞ MOTOR, STEPPI NG KDCC1400 1
9 ｶﾊﾞｰ COVER AKDCC6122 1
ｶﾊﾞｰ COVER KDCC0571 1
ｶﾊﾞｰ COVER KDCC0581 1
10 ﾘｰﾙ REEL AKDCC6670 1
ﾘｰﾙ REEL KDCC1890 1
備考
Remarks
Descri pt i on
http://www.fuji.co.jp/
Copyright © 2002 by Fuji Machine Manufacturing Co., Ltd. All Rights Reserved.
