User manual SIPLACE E 6 Station extensions
From software version SC 708.0 12/2014 Edition 6.3 SIPLACE JTF-MW
285
6.3.2 Overview
6
Fig. 6.3 - 2 SIPLACE JTF-MW on SIPLACE E
(1) Changeover table
(2) SIPLACE JTF-MW
(1)
(2)
6 Station extensions User manual SIPLACE E
6.3 SIPLACE JTF-MW From software version SC 708.0 12/2014 Edition
286
6.3.3 Technical data
6
Position JTF-MW
Dimensions
Width 322.40 mm
Height 946 mm
Length 1209 mm
Location on SIPLACE E
Installed / docked at location 2 only
JEDEC waffle pack tray specification
JEDEC Standard: 95-1 & IEC 60286-5
Storage capacity
30 JEDEC waffle pack trays
15 cookie trays, each can hold 2 JEDEC trays
Max component height from tray base
10.8 mm (zero tray level skipping)
24.6 mm (1 tray level skipping)
38.4 mm (2 tray level skipping)
Cassette
Dimensions (L x W x H) 344 mm x 300 mm x 228 mm
Total weight loading 30 kg
(cookie tray + components)
Max. weight per cookie tray
2.0 kg, ± 10%
Pneumatics
5 bar to 10 bar
Compressed air consumption
28.3 NL/min.
Communication
Pogo-pin interface, Can bus
Weight
~ 45kg excluding cookie trays & magnets
~ 60 Kg including 15 cookie trays & magnets
User manual SIPLACE E 6 Station extensions
From software version SC 708.0 12/2014 Edition 6.3 SIPLACE JTF-MW
287
6.3.4 Dimensions with JTF-MW
6
Fig. 6.3 - 3 Dimensions of SIPLACE E machine with JTF-MW
