Physical XS-Line (300 Liters) XS-Line (600 Liters) XS-Line (900 Liters) XT -Line (1250 Liters) XL-Line (1840 Liters) Net V olume 300 Lt 625 Lt 925 Lt 1250 Lt 1840 Lt Net V olume (Thermal Insulated) 285 Lt 600 Lt 890 Lt 1…
FEATURES
Electrostatic Painted Metal Sheet Body
2°C - 20 °C Temperature set range
0.5% Rh -95% Rh Humidity set range
Automatic Door Locks by Password
7” Touch Screen Control Panel, 800*480 Pixel Screen Resolution
Internet Connection by Wi-Fi or Ethernet Cable
USB Connection
Datalogger (2 GB)
Remote Monitoring System (RMS)
Indoor Sensor (±0.5 ° C Temperature ve ± 0.3% Rh Humidity Sensor Precision)
Door Alarm with Buzzer
Alarm notification by E-mail
4 x Casters (2 of them are lockable)
Adjustable Stabilization Legs 2 pcs
Motion Sensor
ESD Protected
MSD Track Software (optionally)
FIFO (optionally)
Alarm Warning Lamp (optionally)
RFID Access (optionally)
LED Illumination (optionally)
Stainless Steel Shelf (optionally)
Stainless Steel (SS) Sliding Shelf (optionally)
X-Treme Series Dryer Unit (optionally)
X-Treme Series N2 Auto Flow System (optionally)
X-Treme Series Hybrid Systems (optionally)
Hepa Filter Option-Class 1000 (ISO 6) (optionally)
SOLDER PASTE
STORAGE CABINET
Physical
XS-Line
(300 Liters)
XS-Line
(600 Liters)
XS-Line
(900 Liters)
XT-Line
(1250 Liters)
XL-Line
(1840 Liters)
Net Volume
300 Lt 625 Lt 925 Lt 1250 Lt 1840 Lt
Net Volume
(Thermal Insulated)
285 Lt 600 Lt 890 Lt 1215 Lt 1790 Lt
External Dimensions
(WxHxD)
606x1128x750mm 606x1990x750mm 606x1990x1050mm 1200x1990x750mm 1200x1990x1050mm
Internal Dimensions
(WxHxD)
603x792x630mm 603x1654x630mm 603x1654x930mm 1197x1654x630mm 1197x1654x930mm
Internal Dimensions
(WxHxD)
(Thermal Insulated)
584x772x630mm 584x1634x630mm 584x1634x930mm 1178x1634x630mm 1178x1634x930mm
Wight
(Depends on configuration)
90 kg 134 kg 160 kg 190 kg 280 kg
Shelf Load Capacity
50 kg
Height From Ground
30 mm
Body Material
Electrostatic Painted Steel Body, Stainless Steel Interior Panel (AISI 430)
Door Glass
24 mm Insulated Glazing
Shelves and Drawers
2 pcs Stainless Steel 5 pcs Stainless Steel 5 pcs Stainless Steel 10 pcs Stainless Steel Optional
Electrical
Voltage
220 - 240 V AC 50 Hz - 110 V AC 60 Hz (±10%)
Current / Max. Power
10 A - 16 A (Maximum) / 2200 W Max
Average Power Consumption
50 W/h
Max. Power Consumption
1500 W/h
Operational
XS-Line
(300 Liters)
XS-Line
(600 Liters)
XS-Line
(900 Liters)
XT-Line
(1250 Liters)
XL-Line
(1840 Liters)
Humidity Set Range
0.5% - 95% RH (Ambient to Set Value)
Temperature Set Range (Optional)
2 °C / 15 °C / 45 °C / 60 °C / 100 °C (Ambient to Set Value)
Time to Reach to Set Humidity Level
<15 min. Single Dryer; <7 min. Double Dryer(values for 1% RH )
Number of Doors
1 2 2 4 2
Door Lock
Automatic, Password Protected
Version 3.0 Software - Industry 4.0
Display -Control Panel
Type Touch Screen Display
Active Area 7" - (155 x 86mm)
Resolution 800 x 480 Pixel
Datalogger
Capacity 2 GB
Connection Type Wi-Fi (Wireless), Ethernet Cable (Network), USB Flash Disk
USB (AF Type) Connector Right and Left Side of the Cabinet
RMS (Remote Monitoring)
Monitoring via PC, Phone, Tablet
Connection Type Wi-Fi (Wireless), Ethernet Cable (Network)
Cabinet Specifications
Cooling
Capacity 0,5HP
Cooling Type R134a Type
Insulation Material
Elastomeric Rubber Foam Faced with Aluminium Foil,
Thermal Conductivity < 0.040 W/mK
Control Automatic
Shelf Capacity
Material Stainless Steel
Max Pcs / Cabinet 8 16 16 36
36
Min. Shelf Height 60mm
Mounting / Demounting With Shelf Holder Parts, No Tools Required
Customized Storage Options
(Depends on Customers’ Requirement)
Sliding Shelves
Sliding Shelf Dividers
Alarm Light Bar
Type Buzzer and Two-Colored Lights, Magnetic Base
Buzzer Noise Level 70 dB (A)
Light Type and Color Yellow and Red, 12 V, 5 W Lamps
Shape and Visibility Cylindrical, 360° View
Mounting Easy Attachable with Magnetic Base Plate, Built-In Screw Holes
Connection 4-Pin XLR Connector Behind Cabinet
Alarm Function
Alarm Type
Standard Internal Buzzer, Optional Alarm Light Bar
Alarm Duration
Adjustable, Internal Buzzer: 5 - 255 sec. Alarm L. Bar: 1 - 60 min.
Humidity Level Alarm
Adjustable Offset: 0% RH - 40% RH
Temperature Level Alarm
Adjustable Time After Door Close: 1 - 60 minutes
Door Left Open Alarm
Adjustable Time to Alarm: 10 - 240 seconds
SOLDER PASTE
STORAGE CABINET
Sensor Specifications
Relative Humidity Measurement
Location Cabinet Inside (Standard), Cabinet Outside (Optional)
Range 0 - 99% RH
Accuracy ± 0.3% RH (0…20% RH) ± 1.5% RH (20…99% RH) (After
Calibration) (Indoor Sensor)
Resolution 0.01% RH < 10% RH - 0.1% RH > 10% RH (Indoor Sensor)
Temperature Measurement
Location Cabinet Inside (Standard), Cabinet Outside (Optional)
Range -20 - +110 °C
Accuracy ± 0,5 °C (at 25 °C)
Resolution 0.1 °C
Date & Time
Date (dd.mm.yy) and Time (hh:mm:ss) Display With Real Time Clock (RTC)
