Cabinet Specifications
Cooling
Capacity 0,5HP
Cooling Type R134a Type
Insulation Material
Elastomeric Rubber Foam Faced with Aluminium Foil,
Thermal Conductivity < 0.040 W/mK
Control Automatic
Shelf Capacity
Material Stainless Steel
Max Pcs / Cabinet 8 16 16 36
36
Min. Shelf Height 60mm
Mounting / Demounting With Shelf Holder Parts, No Tools Required
Customized Storage Options
(Depends on Customers’ Requirement)
Sliding Shelves
Sliding Shelf Dividers
Alarm Light Bar
Type Buzzer and Two-Colored Lights, Magnetic Base
Buzzer Noise Level 70 dB (A)
Light Type and Color Yellow and Red, 12 V, 5 W Lamps
Shape and Visibility Cylindrical, 360° View
Mounting Easy Attachable with Magnetic Base Plate, Built-In Screw Holes
Connection 4-Pin XLR Connector Behind Cabinet
Alarm Function
Alarm Type
Standard Internal Buzzer, Optional Alarm Light Bar
Alarm Duration
Adjustable, Internal Buzzer: 5 - 255 sec. Alarm L. Bar: 1 - 60 min.
Humidity Level Alarm
Adjustable Offset: 0% RH - 40% RH
Temperature Level Alarm
Adjustable Time After Door Close: 1 - 60 minutes
Door Left Open Alarm
Adjustable Time to Alarm: 10 - 240 seconds
SOLDER PASTE
STORAGE CABINET
Sensor Specifications
Relative Humidity Measurement
Location Cabinet Inside (Standard), Cabinet Outside (Optional)
Range 0 - 99% RH
Accuracy ± 0.3% RH (0…20% RH) ± 1.5% RH (20…99% RH) (After
Calibration) (Indoor Sensor)
Resolution 0.01% RH < 10% RH - 0.1% RH > 10% RH (Indoor Sensor)
Temperature Measurement
Location Cabinet Inside (Standard), Cabinet Outside (Optional)
Range -20 - +110 °C
Accuracy ± 0,5 °C (at 25 °C)
Resolution 0.1 °C
Date & Time
Date (dd.mm.yy) and Time (hh:mm:ss) Display With Real Time Clock (RTC)
