YV100II_E Main part list机器细节图.pdf - 第3页

1 Maintenance Parts Base CRK556 KG7-M8501-40X KG7-M8502-40X AIR FILTER MIST FILTER 1 1 1 2 No. Part No. Part Name Q’ty Remarks Rank A A 2 1

100%1 / 16
CONTENTS
Maintenance Parts
Base..................................................................................................................... 1
Feeder Holder E ....................................................................................................2
Feeder Holder C .................................................................................................. 2
Feeder Floating Detection (Front)......................................................................... 3
Feeder Floating Detection (Rear)...........................................................................3
X-Axis....................................................................................................................4
Y-Axis ....................................................................................................................4
W-Axis.................................................................................................................. 5
Auto Width Conveyor (Option).............................................................................5
ManualWidth Conveyor (Standard)...................................................................... 6
Head Combination ...............................................................................................6
Body Head ...........................................................................................................7
Nozzle Selection.................................................................................................. 8
Nozzle Changer....................................................................................................9
Push Up............................................................................................................... 9
Locate Pin .......................................................................................................... 10
Main Stopper ..................................................................................................... 10
Sub Stopper ....................................................................................................... 11
Push In............................................................................................................... 11
Edge Clamp ....................................................................................................... 12
Moving Camera ................................................................................................. 12
Multi Vision Camera........................................................................................... 13
Single Vision Camera.......................................................................................... 13
Exterior .............................................................................................................. 14
Main Box ........................................................................................................... 14
NOTE
Rank A : The functions of these parts gradually deteriorate with operating time.
Rank B : The machine stops immediately if the functions of these parts are disabled.
Rank C : The machine still operates even if the functions of these parts are disabled,
because there are many parts.
Qíty : The number of identical parts used in one machine.
1
Maintenance Parts
Base
CRK556
KG7-M8501-40X
KG7-M8502-40X
AIR FILTER
MIST FILTER
1
1
1
2
No. Part No. Part Name Q’ty Remarks Rank
A
A
2
1
2
Maintenance Parts
Feeder Holder E
Feeder Holder C
1
2
C
A
KU0-M3410-41X
KG2-M3407-A0X
VALVE KIT
AIR JOINT
50
50
1
2
No. Part No. Part Name Q’ty Remarks Rank
1
2
C
A
KU0-M3410-41X
KG2-M3407-A0X
VALVE KIT
AIR JOINT
8
8
1
2
No. Part No. Part Name Q’ty Remarks Rank
