5 Maintenance Parts W-Axis Auto Width Conveyor (Option) 3 2 3 1 FOR CONVEYOR FOR P.C.B FOR P.C.B 4 4 KH4-M4886-00X KM0-M655F-10X KU0-M655F-20X KM0-M9129-00X MOTOR ASSY 6 SENSOR, 1-3 SENSOR, 1-3 BELT, 1 CONVEYOR 1 1 2 2 1…
4
Maintenance Parts
Y-Axis
X-Axis
1
3
2
FOR X AXIS
FOR 2ND LIMIT
FOR ORG.
90K55-87134X
KM0-M655A-00X
KM0-M655E-00X
AC SERVO MOTOR
SENSOR, 1-1
SENSOR, 1-2
1
1
1
1
2
3
No. Part No. Part Name Q’ty Remarks Rank
B
B
B
1
2
3
FOR 2ND LIMIT
FOR ORG.
FOR Y AXIS
KM0-M655A-00X
KM0-M655E-00X
90K55-8A134Y
SENSOR, 1-1
SENSOR, 1-2
AC SERVO MOTOR
1
1
1
1
2
3
No. Part No. Part Name Q’ty Remarks Rank
B
B
B
5
Maintenance Parts
W-Axis
Auto Width Conveyor (Option)
3
2
3
1
FOR CONVEYOR
FOR P.C.B
FOR P.C.B
4
4
KH4-M4886-00X
KM0-M655F-10X
KU0-M655F-20X
KM0-M9129-00X
MOTOR ASSY 6
SENSOR, 1-3
SENSOR, 1-3
BELT, 1 CONVEYOR
1
1
2
2
1
2
3
4
No. Part No. Part Name Q’ty Remarks Rank
B
B
B
A
5
2
3
4
1
FOR W AXIS ORG.
FOR W AXIS
KH2-M9110-10X
KG7-M9114-00X
KG7-M9115-00X
KH2-M655E-10X
90K55-4W032W
BELT, PULLEY MOTOR
BELT, MOTOR W AXIS
BELT, W AXIS
SENSOR, 1-2
AC SERVO MOTOR
1
1
1
1
1
1
2
3
4
5
No. Part No. Part Name Q’ty Remarks Rank
A
A
A
B
B
6
Maintenance Parts
Manual Width Conveyor (Standard)
Head Combination
2
1
KH2-M9110-00X
KG7-M9115-00X
BELT, PULLEY MOTOR
BELT, W AXIS
1
1
1
2
No. Part No. Part Name Q’ty Remarks Rank
A
A
1
90K55-4W034Z
AC SERVO MOTOR
1
FOR Z AXIS
No. Part No. Part Name Q’ty Remarks Rank
1
B
