FCS300-R-2LT-H-Manual-1.pdf - 第6页
COMPLETE SYSTEM BILL OF MATERIALS FOR FCS300-R-2LT-H: Refer to Drawing # 163-03534 Item Part Number Description Quantity 1 FC10-3 Air fittin g : 1/4mnpt x quick disconnect 1 2 AR20-N02-Z-A Air pressure re g ulator: 0-105…
2. Remove air pressure from the regulator (2) feeding the valve (13) and trigger
handle assembly (15).
3. The system can be left unpressurised with fluid still inside it.
Spare Parts
The components listed below are considered wear items and disposable fluid
delivery components that should be kept as spare parts to avoid downtime.
Item Part Number Description Quantity
1 4-ALO
K
-316 ¼” Ferrule Tube Kit 2
2 TFETB01870250B ¼”od UV Safe Teflon Tubin
g
7
3 FCS3-SP Spare Parts Kit for FCS300-
R
Valve 1
Contact your PVA sales representative for pricing
Optional Accessories
To optimize your manual conformal coating system, PVA has developed a few
accessories that can be used to assist the operators.
Part #
PV106-S
This stand provides the operator with a place to
set the valve and trigger handle assembly when
it’s not in use to prevent it from tipping. The
purge cup located on the front of the stand allows
the operator to pull the trigger when the unit is in
its holster to clean the nozzle if it has been sitting
for long periods of time.
Low Level
PVA offers a low level scale that can be used
to detect the overall weight of the tank and
material to provide feedback to the operator
before the tank runs out of fluid.
The controller of this scale can be connected
to a PLC or stand alone indicator box.
COMPLETE SYSTEM
BILL OF MATERIALS FOR FCS300-R-2LT-H:
Refer to Drawing #163-03534
Item Part Number Description Quantity
1 FC10-3 Air fittin
g
: 1/4mnpt x quick disconnect 1
2 AR20-N02-Z-A Air pressure re
g
ulator: 0-105psi 1
3
K
-50-MP0.7-N01M Air pressure
g
au
g
e: 0-100psi 1
4 AR22P-270AS Mountin
g
bracket for air pressure re
g
ulator 1
5 PV105-
R
Stand to Hold Re
g
ulators 1
6 KQ2L07-35AS Air fittin
g
: 1/4mnpt x 1/4tube 90 1
7 TU0604BU Air tubin
g
: blue, 1/4o
d
x 8ft 1
8 KQ2L07-32A Air fittin
g
: 10/32unf x 1/4tube 90 1
9 PVA-2LTUV 2-Liter bottle pressure tank assembl
y
1
10 4MTC6N-316 Fittin
g
: 3/8mnpt x 1/4tube thru 1
11 TFETB01870250B Teflon material tubin
g
: black, 1/4o
d
x 8ft 1
12 4MSEL2N-316 Fittin
g
: 1/8mnpt x 1/4tube 90 1
13 FCS300-
R
FCS300-
R
spra
y
valve, extended cap 1
14 114-6752 Valve mountin
g
bracket for PV101 1
15 PV101 Pneumatic valve handle 1
16 KQ2L03-32A Air fittin
g
: 10/32unf x 5/32tube 90 5
17 KQ2U03-00A Air fittin
g
: 5/32tube union "Y" 1
18 TU0425
R
Air tubin
g
: red, 5/32od x 8ft 1
19 KQ2L03-35AS Air fittin
g
: 1/4mnpt x 5/32tube 90 2
20 US23892 Precision air re
g
ulator with
g
au
g
e: 0-15psi 1
21 1/8 CD 45 Fittin
g
: 1/8mnpt x 1/8fnpt 45 1
22 TU0425BU Air tubin
g
: blue, 5/32o
d
x 8ft 2
