Royce 610
Dedicated Wire Pull Bond Tester
Royce 600 Series Dimensions and Facility Requirements
650 620 610
Dimensions
Height
Width
Depth
635 mm (25 in)
432 mm (17 in)
585 mm (23 in)
560 mm (22 in)
432 mm (17 in)
585 mm (23 in)
460 mm (18 in)
320 mm (12.5 in)
560 mm (22 in)
Weight
55 kg (120 lbs) 50 kg (110.5 lbs) 27 kg (59.5 lbs)
Power Supply
90 – 264 VAC
47 – 63 Hz
90 – 264VAC
47 – 63 Hz
90 – 264 VAC
47 – 63 Hz
Pneumatic Supply
420 – 550 kPa
(60 – 80 psi)
420 – 550 kPa
(60 – 80 psi)
N/A
Vacuum Supply
500 mm Hg
67.7 kPa, (20 in Hg)
500 mm Hg
67.7 kPa, (20 in Hg)
N/A
Royce 610 Dedicated Wire Pull Bond Tester
The Royce 610 Dedicated Wire Pull Bond Tester is designed
for maximum throughput at an affordable cost, in a reliable
system. It features:
V Data output to any
PC
using
RS
232
V Ergonomic design to support operator comfort over long
shifts
V Simple calibration interface to allow user to quickly and
easily check and recalibrate the instrument with on-screen
instructions (NIST traceable calibration weights available)
V Optional strip printer
V Optional keypad for enhanced failure code input
V Optional external Royce
PC
with Bond Test Manager soft-
ware for data storage and networking
The Royce 610 has an optional strip printer unit that
allows you to print out a hard copy of test data. The
610 can also be linked to the centralized database
by using the Royce SurePC option.
To position the part for testing, a number of
manipulators are available for the Royce 610.
* All
PC
s include a 32
GB
solid state hard drive with 1,000,000 hours
MTBF
, Windows
®
7, 17-inch color monitor, internal
DVD
-
CD
RW
drive,
USB
, network ports, keyboard with integrated touch pad, Bond Test Manager, Excel
®
compatible IBM Lotus
Symphony office suite, Adobe
®
Acrobat
®
Reader, and PDF creation software.
Royce 600 Series Product Comparison
650 620 610
Maximum Wire Pull Test
Force
10 kgf 10 kgf 100 gf
Maximum Shear Test Force
200 kgf 5 kgf
N/A
Maximum Tweezer Pull Test
Force
10 kgf 10 kgf
N/A
Maximum Push Test Force (3
point die strength test)
10 kgf 10 kgf
N/A
Maximum Stud Pull Test
Force
200 kgf 5 kgf
N/A
Total System Accuracy
±0.1% ±0.1% ±0.25%
Z Resolution
±0.1 µm ±0.1 µm ±2.5 µm
X,Y Resolution
<1 µm
N/A N/A
Step Back Accuracy
± 1 µm over 2 mil travel ± 1 µm over 2 mil travel
N/A
Computer*
Internal Windows
®
7 PC
with Bond Test Manager
Internal Windows
®
7 PC
with Bond Test Manager
Optional external
Windows
®
7 PC with
Bond Test Manager
Part Manipulation
Joystick-controlled
motorized XY table
(305 mm x 155 mm)
Manual manipulators
(MPS-2 and MPS-3)
Manual manipulators
(MPS-12 and MPS-14)
Module Height and Tool
Theta Control
Joystick with Z and theta
control
Joystick with Z and theta
control
3-button mouse with Z and
theta control
Microscope
Leica S6 Stereozoom Leica S6 Stereozoom Leica S6 Stereozoom
Centralized Database
Compatibility
YES YES
YES
with
optional PC
Ethernet Port for Network
Capability
YES YES
YES with optional PC
International Standard
Compliance
MIL-STD-883
MIL-STD-750 ASTM F1269
JESD22-B117 JESD22-B116
CE
MIL-STD-883
MIL-STD-750 ASTM F1269
JESD22-B117 JESD22-B116
CE
MIL-STD-883
CE
