SMT Software Engineering Group
IMOperationsYAMAHAMOTORCO.,LTD.
MDOC-SOFT50118
5/7
Table5.1 Movementoftheoperationpanelbuttons.
MachineStatebefore
pressingthebutton
MachineStateafter
pressingthebutton
Button
LaneSelect
Switchstate
Lane1 Lane2 Lane1 Lane2
Note
1
2
1 & 2
Reset Reset Auto Run Auto Run
When the [START] butt
on is
pressed
under the state of reset,
the all lanes start auto
running
without depending on the state of
LaneSelectSwitch.
1 Stop Stop Auto Run Stop
2 AutoRun Stop AutoRun Auto Run
Start button
1 & 2 Stop AutoRun Auto Run AutoRun
1 Auto Run AutoRun Stop AutoRun
2 AutoRun Stop AutoRun Stop
1 & 2 Auto Run Auto Run Stop Stop
Stop button
1 & 2 Stop Auto Run Stop Stop
1 Auto Run Stop
2 Auto Run Auto Run
Reset Button
1 & 2 Stop Auto Run
Reset Reset
When the [
RESET] button is
pressed,thealllanesbecome
ina
thestateofLaneSelectSwitch.
SMT Software Engineering Group
IMOperationsYAMAHAMOTORCO.,LTD.
MDOC-SOFT50118
6/7
6. Lighting condition of the Signal Light
6.1 Signal Light
ThestateofLane1andLane2isindicatedwithone Signal Tower.Thelightingconditionsof
SignalTowerareshowninthefollowingtable(Table6.1).
Forexample,whenthestatesofLane1andLane2are“ErrorStop”and“AutoRunning”,green
andyellowlightswork.
Table6.1 LightingconditionoftheSignalLight
SignalLightThestateof
theLane1
Thestateof
theLane2
Green
Yellow
Red
Buzzer
Reset Reset    OFF
Stop Stop    OFF
AutoRun AutoRun ●   OFF
AutoRun Stop ●   OFF
ErrorStop AutoRun ● ●  ON
Stop
(Componentsrunout)
AutoRun    ON
Emergencystop Emergencystop   ● OFF
●:Lighting:Blink:Dependsonotherconditions
SMT Software Engineering Group
IMOperationsYAMAHAMOTORCO.,LTD.
MDOC-SOFT50118
7/7
7. Status Area
7.1 Split screen of the Status Area
Thestatusindicationisdividedintotwobanks,anddisplaystheeachlanestatus(SeeFig7.1).
Fig7.1StatusArea
