Flexible rotary table high speed LFD assembly cell
Output approx. 80 pcs./min. (depending on product
specifications)
Compact and space saving rotary table system
Easily adaptable to manufacture different devices
Flexible set-up of workstations depending on LFD
specifications
Quick and easy change-over with minimal change
parts (Poka Yoke)
In-house qualification services and support
For different LFD specifications additional worksta-
tions can be added or changed
Various strip cutter versions available (i.e. reel, single
card, card magazine, customized)
Optical quality control of product parts and each as-
sembly step to guarantee maximum quality (i.e. parts
positioning, defect detection, correct assembly, …)
Common industrial software platform
GxP/GAMP 5 compliant
21 CFR 820 / 21 CFR Part 11
High Speed LFD Assembly −
Key Features
04 | 05
Strip CutterHousing Infeed Systems Strip Infeed – Reel
Intuitive Multi-Touch
User Interface
Accessibility PULSE Pro Software Suite –
Smart Alerts
Housing PressStrip Infeed – Card Magazine LAMINO-Flowbox
ASYS LIFE SCIENCE
Labeling
Feeder Solutions
Testing Depaneling
Tray Handling
Laser Marking
Press-Fit
Plasma Cleaning
Laser Cleaning
Dispensing/Potting
Laser Depaneling
Resistance Welding
Laser Cutting
Tray Load/Unload
Riveting
Laser Welding
Laser Reflow Soldering
Screwing
Transport
Assembly Processes
