SIPLACE OIS 13.1 / Software Version Description Ausgabe 05/2016 Edition
6
1.1.1 OIS Functionality
The OIS server records the operating data in a relational database and conveys this data to the
OIS client. The OIS client provides a graphical user interface to display this data.
1.1.2 SIS Functionality
SIS records recipe and setup specific data received from SIPLACE Pro via the SpiXML adapter in
a relational database.
SIPLACE OIS 13.1 / Software Version Description Ausgabe 05/2016 Edition
7
2 Scope of Delivery
SIPLACE OIS Application V13.1, item no. [00117819-xx] is included in "SIPLACE Pro Media
Package V13.1", item no. [00117811-xx] and contains:
Quantity Item
1 CD-ROM with V13.1 of the SIPLACE OIS
and SIS
software
1 Installation Manual, item no. [00198013-xx]
1 Support Media
NOTICE
To Support Media:
Please use the Navigation Guide button of the Support Media Launcher to navigate
through the documentation.
The navigation guide and all related documents are available with
the Support Media that
is shipped with the SIPLACE Pro / SIPLACE OIS package.
SIPLACE OIS 13.1 / Software Version Description Ausgabe 05/2016 Edition
8
3 Interfaces for OIS Client
NOTICE
As of SIPLACE OIS version 12, OIS can only be installed on computers on which
Windows 7 is running. Machines with Windows XP still require the 11.x version. The 13
.x
OIS server is completely compatible with the 11.x clients. The current 11.2 SP1 version
is included in the OIS package.
3.1 Platform 1 Machines
Supported machines: SIPLACE S-20, S-23, F
4
, F
5
, F5-HM
Data interface for capturing the station software operating data:
● Version 407.xx
● Version 408.xx
3.2 Platform 2 Machines
Supported machines: SIPLACE S-25, S-27, HS-50, HS-60, HF, HF/3
Data interface for capturing the station software operating data:
● Version 503.xx (not supported 503.01)
● Version 504.xx
● Version 505.xx
3.3 Platform 2+ Machines
Supported machines:
SIPLACE CA3
1)
, CA4
1)
, X2, X3, X4, SIPLACE D1 / D1i
2)
, D2 / D2i
2)
, D3, D4 / D4i
2)
Data interface for capturing the station software operating data:
● Version 601.xx
● Version 602.xx
● Version 603.xx
● Version 604.xx
● Version 605.xx
●
1)
Version 605.03 – 605.03 SP5. Not supported as of Version 605.04 anymore!
2)
as of Version 605.03 SP3
