MODEL GXH-1 0409-002 194 電装ボックス L ELECTRICAL BOX L Fig. BL-1 電装ボックス Electrical Box 55 89 86 . 81 . 83 84 88 71 70 57 71 88 83 89 86 . 81 . 58 90 82 87 . 83 88 80 56 89 86 . 81 . 79 80 88 84 88 80 56 79 80 88 84 89 86 . 8…
MODEL GXH-1
0909-004
193
Fig. BL
電装ボックス
L ELECTRICAL BOX L
MODEL GXH-1
0409-002
194
電装ボックス
L ELECTRICAL BOX L
Fig. BL-1
電装ボックス
Electrical Box
55
89
86
.
81
.
83
84
88
71
70
57
71
88
83
89
86
.
81
.
58
90
82
87
.
83
88
80
56
89
86
.
81
.
79
80
88
84
88
80
56
79
80
88
84
89
86
.
81
.
82
87
.
90
MODEL GXH-1
1012-004
195
Key No. PART No. PART NAME Q’ty REMARKS New Code
NOTE
BL-1
55 6301326290 BRACKET 1 803BL-210-055 211F9149
56 6301295480 BRACKET 2 803BL-210-056 211F8718
57 6301243405
BRACKET(BRACKET) 1 803BL-210-057 211F8070
58 6301326375
BRACKET 1 803BL-210-058 211F9155
70 6301405506
MOTOR,DC 1 M109 803BL-210-170 4M130026
71 6301399805
ACCESSORY,MOT-M 2 803BL-210-171 23M00062
79 6301405490 MOT
OR,DC 2 M110,M111 803BL-210-179 4M130025
80 6301399799 ACCESSORY,MOT-M 4 803BL-210-180 23M00061
81 6300007749 BOL
T,HEX-SCT 10 M5X10 221A0029
82 6300007886 BOL
T,HEX-SCT 4 M6X16 221A0043
83 411
1410307 NUT HEX 4 12 M4 221F0104
84 411
1132506 SCR PAN 4X40 12 M4X40 PAN 221E0508
86 41
11416705 WASHER SPR 5 10 SW5 221H0287
87 411
1413001 WASHER SPR 6 4 SW6 221H0289
88 411
1414008 WASHER V 4X9X0.8 24 FW4 221H0318
89 411
1414107 WASHER V 5X10X1 10 FW5 221H0320
90 6300010237 W
ASHER 4 BW6 221H0006
