5.2 Preparation for Maintenance
Preparation for Cleaning and Oiling
•
Rag (Extra Cloth)
Use a rag made of such material (cotton, etc.) that produces as less waste thread
as possible.
A clean rag must be used depending on a spot to be cleaned.
Notice
The remaining waste thread if any will cause the machine to break
down.
•
Alcohol
Do not use alcohol on unspecied locations.
•
Air Gun
Do not use the air gun for any spots other than the specied ones.
If dirt and dust are dispersed, moving mechanisms, causing the tape feeder to
break down.
•
Vacuum Cleaner
If the suction hole of the vacuum cleaner is changed to a smaller one, some
spots can be cleaned more easily.
•
Cotton Applicator (SIGMA-G5/G5S/F8 Main Machine Line Accessory)
It is used for removing dirt stuck onto the sensor section.
•
Greasing Jig (SIGMA-G5/G5S/F8 Main Machine Line Accessory)
Grease is applied using this syringe type jig.
(When grease for one division on the gauge is injected, grease of 0.1 ml is
applied).
•
Greasing Jig Nozzle (SIGMA-G5/G5S/F8 Main Machine Line Accessory)
Grease is applied using this syringe type jig.
•
Grease
Use MOLYNOC GREASE AP1 (NIPPON OIL CORPORATION) or its
equivalent.
1504-001
5.2 Preparation for Maintenance
OM-1833
5-2
MOLYNOC GREASE AP1 (NIPPON OIL CORPORATION) or its equivalent
Table E1
Grease Names Makers
DAPHNE M-No.1 Idemitsu Kosan Co., Ltd
JOMO Lisonix Grease M No. 1 JX Nippon Oil & Energy
COSMO MOLYBD GREASE No. 1 COSMO OIL LUBRICANTS
BEACON Q2 ESSO OIL
Gemico MD2 TonenGeneral Sekiyu K.K.
M5 GREASE 1 KYGNUS
1504-001
5.2 Preparation for Maintenance
OM-1833
5-3
5.3 Maintenance Check List
5.3.1 Weekly Maintenance
Table E2
Location to be Maintained
Work Working Tools Check
Name
Reference
Drawing
Suppressor Section Component
Pick-up Unit
Fig. E2 Cleaning Air Gun
Cover Tape
Processing
Section
Fig. E2 Cleaning Air Gun
Suppressor Fig. E3 Cleaning Air Gun
Loading Unit
Loading
Suppressor
Fig. E5 Cleaning Air Gun
Preceding Tape
Travel Guide
Fig. E5 Cleaning Air Gun
5.3.2 Quarterly Maintenance
Table E3
Location to be Maintained
Work Working Tools Check
Name
Reference
Drawing
Suppressor Section Component
Pick-up Unit
Fig. E2 Cleaning Alcohol, Rag or Cotton Swab
Cover Tape
Processing
Section
Fig. E2 Cleaning Alcohol, Rag or Cotton Swab
Suppressor Fig. E3 Cleaning Alcohol, Rag or Cotton Swab
Chute
Fig. E3 Cleaning Alcohol, Rag or Cotton Swab
Cover Tape Take-up
Gear Section
Sprocket (1)
Fig. E8 Cleaning Alcohol, Rag or Cotton Swab
Lubrication
MOLYNOC GREASE AP1, Greasing Jig
Sprocket (2)
Fig. E8 Cleaning Alcohol, Rag or Cotton Swab
Lubrication
MOLYNOC GREASE AP1, Greasing Jig
Loading Unit
Loading
Suppressor
Fig. E5 Cleaning Alcohol, Rag or Cotton Swab
Preceding Tape
Travel Guide
Fig. E5 Cleaning Alcohol, Rag or Cotton Swab
Tape Present/
Adsent Sensor
Fig. E7 Cleaning Air Gun
Sprocket (3)
Fig. E6 Cleaning Alcohol, Rag or Cotton Swab
Lubrication
MOLYNOC GREASE AP1, Greasing Jig
Flat End Fig. E7 Cleaning
MOLYNOC GREASE AP1, Greasing Jig
Suppressor Section Pick-up
Position
Fig. E4 Adjustment Feeder Adjusting Jig JG-0209
(Purchase separately)
1504-001
5.3 Maintenance Check List
OM-1833
5-4
