4 4 . アウトコンベア O u t c o n v e y o r ( W Q C ) CP-642ME P AR TS LIST ver05 4 4 - 1 4 4 . アウトコンベア( カバー) ( オプション) ( W Q C ) 4 4 . O u t c o n v e y o r ( C o v e r ) ( O p t i o n ) ( W Q C ) 1 1 2 2 2 2 5 2 6 2 5 2 1 3 2 7…
43.インコンベア In conveyor(WQC)
CP-642ME PARTS LIST ver05
43-2
43.インコンベア(カバー)(オプション)(WQC)
43.In conveyor(Cover)(Option)(WQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
193585WQC6010 1 BKT BKT
293585WQC6020 1 DOOR 扉
3WQC4450 2 RAIL ﾚｰﾙ
4WQC4460 1 DOOR 扉
5WQC4480 1 STOPPER ｽﾄｯﾊﾟ
6WQC4490 1 PLATE ﾌﾟﾚｰﾄ
7WQC4500 1 PLATE ﾌﾟﾚｰﾄ
8WQC4510 1 STOPPER ｽﾄｯﾊﾟ
9WQC4520 1 STOPPER ｽﾄｯﾊﾟ
10WQC4530 1 BKT BKT
11WQC0301 4 BKT, COVER BKT ｶﾊﾞｰ
12IQC6072 8 NUT ﾅｯﾄ
13PPK0260 3 PLATE ﾌﾟﾚｰﾄ
14WQC4620 1 BKT BKT
15WQC4540 1 PLATE, SW ﾌﾟﾚｰﾄ SW
16WQC4550 1 PLATE ﾌﾟﾚｰﾄ
17M1011Z 1
MAGNET CATCH
ﾏｸﾞﾈｯﾄｷｬｯﾁ TL-148
18T5011S 1
HANDLE
取手
TTHA-00425
19A1002A 1 ACTUATOR ｱｸﾁｭｴｰﾀ VAL2
20S3160H 1
SW, MICRO
SW ﾏｲｸﾛ V-15-1B6
21H5273A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M3X5L
22H5287A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X8L
23H5288A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M4X10L
24K5212A
SCREW, TRUSS
ｺﾈｼﾞ ﾄﾗｽ M4X15L
25H5298A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X10L
26H5299A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X12L
27H5300A
BOLT, HEX SOCKET
ﾎﾞﾙﾄ 六角穴
M5X15L
28K5214A
SCREW, TRUSS
ｺﾈｼﾞ ﾄﾗｽ M5X8L
29.
SCREW, TRUSS
ｺﾈｼﾞ ﾄﾗｽ M5X15L
30K5362A
SCREW,HEX SOCKET COUNTERSUNK
小ﾈｼﾞ 六角穴皿
M5X15L
31W1021A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 3M/M
32W1022A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
33W1023A
WASHER, LOCK
ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
34W1043A
WASHER, FLAT
ﾜｯｼｬ 平
4W-4
35W1044A
WASHER, FLAT
ﾜｯｼｬ 平
4W-5 ･
44.アウトコンベア Out conveyor(WQC)
CP-642ME PARTS LIST ver05
44-1
44.アウトコンベア(カバー)(オプション)(WQC)
44.Out conveyor(Cover)(Option)(WQC)
1
12
22
25
26
25
21
3
27
18
17
14
7
26
25
23
27
27
2
6
4
16
28
20
25
28
5
19
10
25
22
24
20
20
24
25
22
10
19
19
13
25
22
15
25
22
11
19
19
13
25
22
29
x5.6
44.アウトコンベア Out conveyor(WQC)
CP-642ME PARTS LIST ver05
44-2
44.アウトコンベア(カバー)(オプション)(WQC)
44.Out conveyor(Cover)(Option)(WQC)
番号 図番 & ｺｰﾄﾞ番号 個数 品名 規格 備考
No. Drg.No. & Code No. QTY Description Rating Remarks
1WQC5710 1 BKT BKT
2WQC5720 1 COVER ｶﾊﾞｰ WQC5720+WWM0210
3WQC0342 1 COVER ｶﾊﾞｰ WQC0342+WWM0210
4WQC5730 1 BAR ﾊﾞｰ
5WQC0362 1 BAR ﾊﾞｰ
6WQC5740 1 HINGE 蝶番
7WQC5750 1 BKT BKT
10WQC0301 2 BKT, COVER BKT ｶﾊﾞｰ
11WQC0310 1 BKT, COVER BKT ｶﾊﾞｰ
12CLC4251 1 STOPPER ｽﾄｯﾊﾟ
13MQC6031 2 BKT BKT
14IPK8090 1 PLATE, SW ﾌﾟﾚｰﾄ SW (Option)
15IPK8510 1 BOLT ﾎﾞﾙﾄ
16T5011S 1 HANDLE, ROUND 取手 丸 TTHA-00425
17S3160H 1 SW, MICRO SW ﾏｲｸﾛ V-15-1B6
18A1002A 1 ACTUATOR ｱｸﾁｭｴｰﾀ VAL-2
19IQC6072 10 NUT ﾅｯﾄ
20H5290A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M4X15L
21H5298A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X10L
22H5299A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X12L
23H5302A BOLT, HEX SOCKET ﾎﾞﾙﾄ 六角穴 M5X20L
24W1022A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 4M/M
25W1023A WASHER, LOCK ﾜｯｼｬ ｽﾌﾟﾘﾝｸﾞ 5M/M
26W1044A WASHER, FLAT ﾜｯｼｬ 平 4W-5
27K5257A SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M4X8L
28. SCREW, HEX SOCKET BUTTON 小ﾈｼﾞ六角穴ﾎﾞﾀﾝ M4X15L
29CLC4261 1 NUT, ROUND ﾅｯﾄ 丸 ･
