1OM-1603
1-17
2. Name and Function of Each Section : Chap.1
1007-004
•
When the machine is powered under low temperature, the brightness of
the back light drops. It turns out to be normal in a few minutes and the
deterioration is not abnormal.
When the back light is turned on or off repeatedly at low temperature, the
life will be shortened.
•
Before cleaning the touch screen, be sure to turn off the [POWER ON]
button. Otherwise, the touch screen will react to your touch during cleaning,
resulting in data corruption.
If the surface of the touch screen gets dirty, wipe it softly with a soft cloth
soaked in ethanol to remove dirt and dust.
Notice
Never use an organic solvent such as acetone, thinner, benzine to
clean the touch screens.
If the surface is wiped with an organic solvent, it may melt or get
cloudy.
[2] [POWER ON] Button
Turning ON or OFF this button supplies or intercepts the power for
operations.
When the [POWER ON] button is pressed and the power for operations is
supplied, the LED of the [START] button ickers.
[3] [START] Button
When the [START] button is pressed while the lamp is ickering after the
machine is powered, the automatic operation starts and the LED of the button
turns green.
While the LED is ON, it indicates that the automatic operation is being
performed.
When the [STOP] button is pressed during the automatic operation, the
automatic operation stops temporarily and the lamp of the [START] button
extinguishes.
While each device is being zeroed, the LED is kept ON.
[4] [STOP] Button
When this button is pressed, the machine stops running temporarily.
When the machine is running automatically, it stops temporarily after all the
picked components are placed.
When the [STOP] button is pressed during the zeroing operation, the zeroing
operation of each device is interrupted.
1OM-1603
1-18
2. Name and Function of Each Section : Chap.1
1003-003
[5] [LOCK] Lamp
When this lamp is ON, it indicates that the operation panel is set in the
"LOCK" mode and the operation panel on this lamp side is available.
The other operation panel cannot be selected.
When the operation panel on the opposite side is used with this lamp "ON",
the lamp starts ickering.
To cancel the ickering, press the [PNL CHANGE] button and follow the
procedure to set the "LOCK" mode again.
CAUTION
Beforeperforminganywork,conrmthatthe"LOCK"
lamp on the operation panel is "ON" (green).
•
If the "LOCK" lamp is not turned on, the machine
can be operated at any time from the front and
rear sides, endangering the operators around
the machine.
•
Before performing any setup work with the
machine being powered up, turn on the [PNL
CHANGE] button and the "LOCK" lamp on the
front or the rear operation panel.
1OM-1603
1-19
2. Name and Function of Each Section : Chap.1
1007-004
[6] [PNL CHANGE] Button
This button is used to select either the front or the rear operation panel. This
button is prepared on each operation panel. When the LED of the button is
ON, it indicates that the corresponding operation panel is available.
When this button is pressed with the LED "ON", the operation panel is set in
the "LOCK" mode and the "LOCK" lamp illuminates.
When the operation panel is set in the "LOCK" mode, the other operation
panel on the opposite side cannot be selected on the other operation panel
side.
To cancel the "LOCK" mode, press this button again.
Note
(a) While the LED of this button is ON, the followings become
available.
•
Touch Screen
•
[START] and [STOP] Buttons and [EMERGENCY STOP] Switches
(b) The [STOP] buttons and the [EMERGENCY STOP] switches are
always available, regardless of which [PNL CHANGE] button is
selected.
(c) When both operation panels are not set in the "LOCK" mode and the
[PNL CHANGE] button on the unavailable operation panel side is
pressed, the unavailable operation panel is selected and set available.
(d) When the operation panel is not locked and the [STOP] button on
the unselected operation panel is pressed, the operation panel on the
pressed button side becomes activated automatically.
[7] [EMERGENCY STOP] Switch
Press this switch to immediately stop the machine in an emergency.
When this switch is pressed, the machine stops running immediately and the
[POWER ON] button on the operation panel illuminates in red.
