Page 17 DH P ositioning System Assembly , Non P/T T46230811 Rev . J This Document Supports Assembly 46230811 Rev J DET NO. ITEM NO. DESCRIPTION QTY U/M 123 80000609 SHCS 1/4-20 X1 1/2 1 EA 124 80019006 ITLW 1/4 4 EA 125 …
Page 16
T46230811 Rev. J DH Positioning System Assembly, Non P/T
This Document Supports Assembly 46230811 Rev J
DET
NO.
ITEM NO. DESCRIPTION QTY U/M
93 30587602 BRACKET,LOCKING 8 EA
94 30780801 SPACER 8 EA
95 80001606 SBHS 10-24 X 7/8 8 EA
96 80002503 SFHS 8-32 X 5/8 6 EA
97 30648002 DRIVE ASSY 2 EA
98 80002612 SFHS 10-32 X 1 4 EA
99 80023508 HEX NUT-MS 10-32 4 EA
100 BLKE01073 CABLE CLAMP,5/16,BLACK 2 EA
101 80008602 PHMS 8-32 X 1/4 2 EA
102 42372703 X FRAME 2 EA
103 15055000 BUSHING,BALL 8 EA
104 30013000 PLUNGER, SPRING 8 EA
105 18388000 RETAINER 8 EA
106 46194802 BLOCK,SUPPORT 1 EA
107 80000606 SHCS 1/4-20 X 7/8 2 EA
108 48253601 BELLOW,DUST 1 EA
109 80010003 DOWEL 3/16 DIA X 3/4 1 EA
110 80000603 SHCS 1/4-20 X 1/2 10 EA
111 80000110 SHCS 4-40 X 5/16 8 EA
112 48240101 PLATE,MOTOR 1 EA
113 80001610 SBHS 10-32 X 1/2 12 EA
114 42372601 TROLLEY,ROT 2 EA
115 46587901 GEAR BELT 2 EA
116 17615000 CAM 2 EA
117 18058000 LOCK ASSY 2 EA
118 40395901 MECH SLOWDOWN ASSY 1 EA
119 80007601 HHCS 1/4-20 X 1/2 3 EA
120 80015001 HEX NUT 1/4-20 1 EA
121 40395902 MECH SLOWDOWN ASSY 1 EA
122 40395803 PULSE VALVE ASSY 1 EA
Page 17
DH Positioning System Assembly, Non P/T T46230811 Rev. J
This Document Supports Assembly 46230811 Rev J
DET
NO.
ITEM NO. DESCRIPTION QTY U/M
123 80000609 SHCS 1/4-20 X1 1/2 1 EA
124 80019006 ITLW 1/4 4 EA
125 40395802 PULSE VALVE ASSY 1 EA
126 80000409 SHCS 8-32 X 1 1/2 1 EA
127 30902801 BUSHING 8 EA
128 80032701 EXT TOOTH L/W CSK 8 EA
129 80001503 SBHS 8-32 X 1/2 2 EA
130 20981000 BUSHING,ADAPTER 8 EA
131 18164000 WHEEL, GUIDE 8 EA
132 47540603 STUD 8 EA
133 17597001 Y FRAME 1 EA
134 14339000 SHAFT, X AXIS 2 EA
135 80000519 SHCS 10-32 X 1 14 EA
136 80004704 SOC,SET SCR, FL,PT 6-32 X 3/8 4 EA
137 20189000 ACTUATOR 2 EA
138 48240001 SPACER 2 EA
139 15118000 BUSHING 2 EA
140 80000517 SHCS 10-32 X 3/4 4 EA
141 80000302 SHCS 6-32 X 3/8 31 EA
142 45292801 RAIL, ACTUATOR BRKT 1 EA
143 80002403 SFHS 6-32 X 1/2 3 EA
144 80001502 SBHS 8-32 X 3/8 6 EA
145 30395801 STOP, Y 1 EA
146 14330002 RETAINER,BEARING 1 EA
147 80000403 SHCS 8-32 X 1/2 4 EA
148 14340000 SUPPORT,BRG 1 EA
149 80000608 SHCS 1/4-20 X 1 1/4 3 EA
150 17802000 PLATE, MTG 1 EA
151 17595002 COVER 1 EA
152 48216301 MOTOR,ASSY BRUSHLESS,DC,ENCODER 2 EA
Page 18
T46230811 Rev. J DH Positioning System Assembly, Non P/T
This Document Supports Assembly 46230811 Rev J
DET
NO.
ITEM NO. DESCRIPTION QTY U/M
153 17258002 INSULATION .50 1 EA
154 22243002 VINYL, DAMPING 3 EA
155 44973301 BRACKET, SENSOR 2 EA
156 44460003 PROXIMITY SWITCH 2 EA
157 48236201 RETAINER, BEARING 2 EA
158 BLKM06320 RETAINING RING 2 EA
159 15179000 CLAMP,ENCODER 1 EA
160 48237501 BEARING,BALL,DOUBLE ROW 2 EA
161 48226801 PLATE,ENCODER 1 EA
162 80000407 SHCS 8-32 X 1 5 EA
163 80009904 DOWEL 1/8 DIA X 3/4 2 EA
164 46910201 ROTARY ENCODER ASSY 2 EA
165 45121802 COUPLING,FLEX 2 EA
166 80015104 HEX JAM NUT,5/16-24 2 EA
167 48236102 RETAINER, BELLOW 2 EA
168 46564806 PULLEY,GEARBELT 2 EA
169 47527101 LOCKING ELEMENT 4 EA
170 48226601 PLATE, MOTOR 1 EA
171 48257401 BRACKET 1 EA
172 30959204 DH ROT DISC ASSY 2 EA
173 80000402 SHCS 8-32 X 3/8 10 EA
174 50683801 STOP, CLAMP ASSY 2 EA
178 10249101 SPRING 4 EA
179 80010407 SDP 7/16 X 1/2 4 EA
180 80010403 SDP 7/16 X 1 1/2 2 EA
181 80000607 SHCS 1/4-20 X 1 3 EA
182 BLKE01071 CABLE CLAMP, 3/16, BLACK 2 EA
183 BLKE01079 CABLE CLAMP, 1 1 EA
184 48213801 PULLEY, MOTOR 2 EA
185 10457013 CLAMP, COLLAR 2 EA
