The extremely compact high-resolution systems YXLON FF20 CT and FF20 CT Metrology are designed for fine to very fine parts like - Electronic components incl. SMD - Semiconductor packages - Products made from new materials …
Do you want to improve the material testing procedures
in your R&D department? Do you want to optimize your
process control and small series inspection?
Benefit from precise inspection results of YXLON FF20 CT.
The extremely compact high-resolution systems
YXLON FF20 CT and FF20 CT Metrology are designed
for fine to very fine parts like
- Electronic components incl. SMD
- Semiconductor packages
- Products made from new materials or new
manufacturing methods, e.g. additively manufactured
components, fiber-reinforced plastics
- Microsystems (MEMS, MOEMS)
- Medical objects, e.g. cannulas
With comparatively high energy of 190 keV, even larger or
denser parts can be inspected to the finest detail.
Experience a structured
CT inspection workflow
Typical applications for computed tomography are
- Research and development
- Failure analysis
- Process control
- Inspection of small serial productions
- Quality assurance and material analysis
- Assembly checking
- Combined DR (digital radiography) and CT inspection
3D-CT volume of a microchip
with pillar array
Based on the Yxlon system software Geminy which offers
easy, intuitive operation with touch screens and graphical
user interface, the FF20 CT / FF20 CT Metrology provide
numerous special features. The users benefit from
unrivaled image quality, utmost flexibility regarding the
bandwidth of applications, and compact cabinet design.
Various automated functions help to save time. Different
user levels support unskilled operators as well as
experienced experts to achieve optimum results in their
inspection tasks. Health monitor and push messages keep
the user informed about system status and inspection
progress.
A detailed description of the software platform Geminy is
available in a separate brochure.
It’s the inside
that matters
1
2
3
4
6
7
8
5
