InJet
®
388 CRRD
TECHNICAL DATA SHEET
5
www.dct.cleaning
Power supply 400V, 32A, 50Hz (3+N+PE) UL 400V, 32A, 60Hz* (3+N+PE)
Pmax 13 kW 13 kW
Compressed air connection Pipe Ø 6 mm Pipe ID 0.24 in
Recommended working pressure 4,5 – 6 Bar 65.25 – 87 PSI
Compressed air quality 3. Class ** 3. Class **
Exhaust pipe diameter Ø 100 mm ID 3.94 in
Exhaust pipe capacity 380 m
3
/h 13400 ft
3
/h
Minimum liquid for  rst run 3 x 50 l 3 x 13.2 gal
Service space required around the device 600 mm 23.6 in
* When using frequency convertor
** According to the norm ISO 8573-1
INSTALLATION REQUIREMENTS
BACK
VIEW
RIGHT
VIEW
RIGHT
VIEW
1600 mm
63 in
Ø 100 mm
ID 3.94 in
1390 mm
54.7 in
1850 mm
72.8 in
760 mm
29.9 in
discharge of the fluids G 1“
input el. power 400/230 V
input air pressure Ø 10 mm, Ø 6 mm
input air pressure ID 0.39 in, ID 0.24 in
245 mm
9.65 in
250 mm
9.84 in
metric units imperial units
InJet
®
388 CRRD
TECHNICAL DATA SHEET
6
www.dct.cleaning
1 process chamber – fully automatted solution
100% closed loop uid system
2 arm rotation – uid powered - cleaning
2 arm rotation – uid powered - rinsing
Cleaning and rinsing uid heating
Mechanical ltration
2 hot air blowers – drying
Chimney ap – electronically controlled
Pneumatic door lock
Emergency stop button
Manipulation wheels – lockable
PLC controller + 8,4“ touchscreen display
Spare parts (base kit)
STANDARD HARDWARE EQUIPMENT
Electronic monitoring of uid level
Electronic process cycle counter
3 levels of logging – operator, maintenance, engineer
Spraying uid pressure – continuous measurement
Standard software language mutation – CZ, ENG
Liquid and lter replacement notication – cycle counting
Possibility of 5 programs – setting option
Smart warning – low or high pressure level
Smart warning – low uid level
STANDARD SOFTWARE EQUIPMENT
InJet
®
388 CRRD
TECHNICAL DATA SHEET
7
www.dct.cleaning
SW for CVA calculation (android, machine)
Adjustable timer of cleaning uid heating
Upgrade machine for PROTON
Language mutation (CZE, ENG, GER, POL, CHI, RUS, ITA, SPA, MAY, HUN)
ONLINE access to cleaning device
OPTIONAL SOFTWARE EQUIPMENT
Common uids draining – manual control
Automatic uids relling (without pump)
Automatic uids discharging (without pump)
Tanker 200 l or 400 l – cleaning/rinse uid
Filtration 1PR sandwich – integrated
Filtration sandwich – external
Air knife – swinging – drying chamber
Conductivity measurement – pre-rinse / rinse 0–2000 µS – blocking optional
Other optional equipment - the complete list of optional accessories will provide you DCT or the local distributor.
OPTIONAL HARDWARE EQUIPMENT
Mechanical carrier frame – PCB
Mechanical carrier frame – frameless stencils
Mechanical carrier frame – frame stencils
Mechanical carrier frame – VectorGuard stencils
Mechanical carrier frame – squeegees
Mechanical carrier frame – frame and VG stencils (reduction)
Other optional equipment - the complete list of optional accessories will provide you DCT or the local distributor.
Traceability OFF line, CSV to SD card
Traceability OFF line, Reader, CSV to SD card
Traceability ON line, PC WIN, le
Traceability ON line, READER, PC WIN, le
Traceability ON line, PC WIN, OPC Server CD, no le
Traceability ON line, PC WIN, READER, OPC Server CD, no le
OPTIONAL ACCESSORY – FRAMES AND OTHERS
OPTIONAL TRACEABILITY
