6 MDF51 Series ● High V oltage Wire-to-Board Connectors ■ Header (Contact pitch : 13 mm) ● Straight, through-hole 19.1 1.2 Contact No.1 mark 18.2 24.1 P=13 6.75 2.8 2.8 1.2 t=0.3 6.85 1.8 2 +0.1 0 0.9 (1.8) 6.85±0.1 +0.1…

100%1 / 12
5
MDF51 Series●High V oltage Wire-to-Board Connectors
■ Header (Contact pitch : 13 mm)
●Straight, surface mount
●Packaging Specification
0.2±0.05
R0.75
(24.5)
(44.5)
(Ø80)
(Ø380)
50.4MAX
(7.7)
Unreeling direction
Unreeling direction
20±0.1
B
B
A
A
A-A
B-B
(14.5)
20.2±0.1 1.75±0.1
40.4±0.1
44±0.3
4±0.1
Ø1.5
(2)
+0.1
0
+0.1
0
Ø13±0.2
(4.45)
0.1
24.1
18.2
18.2
14.1
6.512.1
14.1
P=13
3.5mm dia. flat surface,
for placement with
automatic equipment.
t=0.3
Contact No.1 mark
+0.1
0
+0.1
0
0
18.2±0.05
18.2±0.05
2±0.05
3
8±0.05
2±0.05
2.6
(3.85)
Recommended PCB la y out dimensions
Unit : mm
Part No. HRS No.
No. of
contacts
Insulator
Color
Packaging
MDF51SU-2P-13V(23)
547-2016-6 23
2
Beige
600 pcs/reel
Please place orders in full reel increments.
Jun.1.2023Copyright2023HIROSEELECTRICCO.,LTD.AllRightsReserved.
6
MDF51 Series●High V oltage Wire-to-Board Connectors
■
Header (Contact pitch : 13 mm)
●Straight, through-hole
19.1
1.2
Contact No.1 mark
18.2
24.1
P=13
6.75 2.8
2.8
1.2 t=0.3
6.85
1.8
●Packaging Specification
Recommended PCB la y out dimensions
PCB thic kness : 1.6mm
()% &+#+*
E2((
'+%
E2((
Unit : mm
Unit : mm
12.75
4.451.45
27.8
13
Contact No.1 indicator
Part No. HRS No.
No. of
contacts
Insulator
Color
Packaging
MDF51SY-2P-13DSA(21)
547-0920-3 21 2
Black 120 pcs/tray
Please place orders in full tray increments.
Part No. HRS No.
No. of
contacts
Insulator
Color
Packaging
MDF51SU-2S-13C(03)
547-2018-1 03 2
Gray
100 pcs/pack
Please place orders in full pack increments.
■ Crimp socket (Contact pitch : 13 mm)
Jun.1.2023Copyright2023HIROSEELECTRICCO.,LTD.AllRightsReserved.
7
MDF51 Series●High V oltage Wire-to-Board Connectors
Part No. HRS No. Packaging
Finish
MDF51-24SCF(40) 547-2005-0 40 10,000 / reel Tin plating
Please place orders in full reel increments.
2.25 3.1
1.4
1.4
0.8
1
t=0.2
8.1
3
4.1
●
UL style : UL3239
●
Strip length
1.8 to 2.6mm
Tools
●
Applicable wire (Tin plated, annealed copper wire)
Unit : mm
Crimp contact
Usage Recommendations
Type Part No. HRS No. Applicable contact
Applicator AP105-MDF51-24S 901-4607-9 00 MDF51-24SCF
Press CM-105 901-0005-4 00
-----------------
Contact extraction tool DF-C-PO (B) 550-0179-2 00
MDF51-24SCF
1.Recommended temperature profile
Note 1 : Up to 2 cycles of Reflow soldering are possible under the same
conditions, provided that there is a return to normal temperature
between the first and second cycle.
Note 2 : The temperature profile indicates the board surface temperature at
the point of contact with the connector terminals.
2.Reccomended flow temperature Peak temperature : 260ç for 10 seconds max.
3. Recommended manual soldering Manual soldering : 350ç for 3 seconds max.
4. Recommended screen thickness
and open area ratio
(Pattern area ratio)
Thickness : 0.15mm
Open area ratio : 100%
5. Board warpage
Maximum of 0.03mm at the connector center, with both ends of the connector as
reference points.
6. Cleaning conditions Refer to "Board to cable connectors Use Handbook".
7. Wire preparation and contact
crimping
Refer to “Board to cable connectors Use Handbook”.
The crimp contact termination must be performed using specified tools.
All dimensions and crimp conditions are listed in applicable Crimp Condition
Table and Crimping Quality Standards Manual.
Wire size (Stranded wire conductor) Jacket diameter
AWG#24 (19 / Ø0.127mm) Ø1.74mm
Note : When using other than the recommended wire, contact your nearest
Hirose sales representative.
10sMAX
30
~
60sec
60~120sec
255
çMAX
180
ç
100
150
200
250
230
ç
Time (Seconds)
Temperature (ç)
