E-by SIPLACE Smart Feeder
44 mm E
Fitting the Tamp Wheel for Rocker
Part Exchange
3/4
CAUTION! Refer to safety instructions in user manual before working on the machine.
ESD guidelines are to be followed
Tool:
T1,T3
Part No.: 03042487-xx (<=-0.6)
03117053-xx (<=-0.7)
1. Fit in the tamp wheel for rocker. 2. Push in the bearing shaft. 3. Tighten the bearing shaft with T1.
4. Fit in the rocker cover. 5. Tighten the 2 screw with T3. 6. Tighten the 2 screw with T3.
E-by SIPLACE Smart Feeder
44 mm E
Fitting the Tamp Wheel for Rocker
Part Exchange
4/4
CAUTION! Refer to safety instructions in user manual before working on the machine.
ESD guidelines are to be followed
Tool:
T1
Part No.: 03042487-xx (<=-0.6)
03117053-xx (<=-0.7)
7. Fit in the rocker. 8. Insert the rocker axle. 9. Tighten the rocker axle with T1.
.
