T o support our customers’ success, we created our Service Engine 4.0: first-class technical problem solver combined with high economic efficiency . This engine drives our service, our processes and our partners to detect …
ONE CLICK PHILOSOPHY
One-click solutions make it easy to perform the advanced
manipulations required for fast and reliable X-ray inspec-
tion. Such as:
- Click & Center
- Frame & Zoom
- PowerDrive
- Zoom+
These functions guarantee constant-intensity magnifica-
tion without tube adjustments or software interpolation,
and can be carried out with one simple click.
EXTENDED BGA INSPECTION
With Cougar EVO, you can quickly select and index
individual balls, either manually or using automatic grid
detection. A wizard guides you step-by-step through the
workflow and ensures perfect accurate and repeatable
results. Plus, the feature allows multiple operators to run
the same inspection routines.
EXTENDED ADR INTERFACE
Cougar EVO software can be tailored to individual
requirements, with operators free to define their own
specific analysis. This also includes customized algo-
rithms.
eHDR-INSPECT
To ensure highest product quality, the eHDR filter
highlights complex structures with just one click. Thanks
to our advanced software and enhanced 16-bit gray scale
values, it detects even the slightest variances in gray
scale, so that no defect will be missed. This allows you
to easily see faults that were invisible before.
2D MULTI AREA VOID CALCULATION (MAVC)
QFNs and other bottom-terminated devices without
overlapping can also be inspected with 2D digital
radioscopy. Faulty or missing solder joints and large areas
of voiding are reliably detected, and MAVC helps analyze
voids in complex soldering designs. With just four
parameters to adjust, setup is quick, simple, and cost-
efficient. Precise void analysis of multi-layer components
needs computed laminography and VoidInspect.
Functions that
bring you forward
6
Using eHDR for Regions of Interest ROI with details (voiding in a BGA ball)
THT with voiding
77
YXLON COUGAR EVO
Check out these facts
X-ray inspection system
Dimensions (w x d x h) 1,000 x 1,050 x 2,200 mm
Weight 1,450 kg
Mains connections
230 V ± 10% AC, 50/60 Hz, 1 Phase,
neutral and ground conductor
Fuse protection 16 A
Max. power consumption 2.5 kVA
Max. dose rate* < 1µSv/h
* at 100 mm distance to the cabinet surface
Inspection parts
Max. part size 440 mm x 550 mm (17” x 21”)
Max. radiographic area 310 mm x 310 mm (12” x 12”)
Max. part weight (standard) 5 kg
Max. part weight rotation and tilt 2 kg
X-ray source FXT-160.50 Microfocus FXT-160.51 Multifocus
Target transmission
Voltage range 20 – 160 kV
Current range 0.001 – 1.0 mA
Tube power max. 64 W
Target power max. 15 W
Target material Tungsten
Detail detectability 0.75 µm < 0.3 µm
X-ray intensity control TXI
Image Chain
Geometric magnification ~ 2,000 x
Total magnification ~ 256,000 x
Spatial Resolution 1.5 µm 0.6 µm
General Product Features
Time to first image (typ.) ~ 10 s
Reconfiguration time (typ.) < 60 s
Acquisition time (Quick Scan)
for 2000 projections
~ 3.15 min
Reconstruction time (Quick Scan)
for 2000 projections
~ 1.55 min
Acquisition time (micro3Dslice
Semicon) for 120 projections
~ 1.45 min
Reconstruction time (micro3Dslice
Semicon) for 120 projections
~ 0.30 min
Access for sample loading manual
Cabinet window 380 mm x 200 mm
Monitor 27” Ultrasharp, wide viewing angles
Zoom+ yes
Manipulation
Manipulation control via mouse or joystick
Manipulation axes X, Y, Z(D)*
Oblique viewing +/-70° (140°)
* Manipulation options for horizontal and vertical rotation and tilting available
Detector Y.Panel 1308 Y.Panel 1313 ORYX 1616
Max. resolution Pixel 1004 x 620 1004 x 1004 1276 x 1276
Pixel size 127 µm²
Pixel area 128 mm x 79 mm 128 mm x 128 mm 162 mm x 162 mm
A/D transformer 16 bit
Please note that not all components and features described in this brochure belong to the standard configurations but are part of an optional selection.
To support our customers’ success, we created our Service Engine
4.0: first-class technical problem solver combined with high economic
efficiency. This engine drives our service, our processes and our
partners to detect and correct failures quickly and reliably by remote
access and during on-site visits. Our service centers and our service
partners worldwide are at your disposal and can be contacted by
phone, e-mail or via our website.
BENEFIT FROM:
- Guaranteed operational safety
- Maximized system availability
- Minimized repair times
- Full cost control of life cycle costs
- Extended product lifetime
Our module-based approach, such as performance and feature
upgrades, enable you to adapt to future requirements and safeguard
your initial investment by extending the product’s lifetime. With our
Service Engine 4.0, fast support is provided by the way we network
all service activities with our organization. We do not only see your
immediate need but are predictive of your future needs.
YXLON Service Engine 4.0
Would you like to learn more about our systems?
Interested in a test inspection? Please contact us
by phone or e-mail.
We look forward to hearing from you.
YXLON LIFECYCLE SERVICES
Academy full performance from day one through
tailored training solutions
SmartExchange direct replacement of defective or worn-out
components to minimize unscheduled
system downtime
SpareParts 100% compatibility and safety through Yxlon
qualified spare parts
WarrantyPass full cost control through our customizable
warranty extension program
ServicePass predictive maintenance and servicing,
tailored to your requirements
SmartPass maximum system uptime for customers
with particularly high demands
LifeCyclePass all-inclusive concept for full cost control over
the entire product lifetime
Support fully digitalized 1st-line support organized in
a worldwide expert network, available
remote or on-site
Upgrades performance increase and new features for
your Yxlon system portfolio
YXLON International reserves the right
to make changes in specifications and/or
to discontinue any product at any time
without notice or obligation and will not
be liable for any consequences resulting
from the use of this publication.
