MEMO

Key No. PART No. PART NAME Q’ty

REMARKS

NOTE

101 4B111614 PCB_MOUNT(CPU) 1 1091401400-001

102 4B111620 PCB_MOUNT 1

1091401400-002

103 4B111572 P.C.B,MOUNT 1

1091401400-003

104 4B111484 P.C.B,MOUNT 1

1091401400-004

105 0914B404 UNIT_IO(DOM4G) 1

1091401400-005

106 4W204861 CORD 1

1091401400-006

107 4W204580 CORD 1

1091401400-007

108 4W100068 CORD_POWER 1

1091401400-008

110 23L10107 ACCESSORY_P_C_B 2

1091401400-010

111 23L10108 ACCESSORY_P_C_B 1

1091401400-011

112 23N30725 ACCESSORY_WIRING 1

1091401400-012

113 23N30719 ACCESSORY_WIRING 1

1091401400-013

114 211B1508 BOX 1

1091401400-014

115 211C1508 PANEL 1

1091401400-015

116 211C1509 PANEL 1

1091401400-016

117 211C1557 PANEL 1

1091401400-017

118 211FE359 BRACKET 1

1091401400-018

120 211C1520 PANEL 1

1091401400-020

121 211C1519 PANEL 1

1091401400-021

122 211J1631 STAY 1

1091401400-022

123 211J1632 STAY 1

1091401400-023

125 211C1556 PANEL 1

1091401400-025

126 211FE358 BRACKET 1

1091401400-026

127 211FE058 BRACKET 3

1091401400-027

128 211FD903 BRACKET 1

1091401400-028

129 24100033 PROGRAM,FLOPPY DISK 1 1091401400-029

151 221DA105 MACHINE SCREW 6

1091401400-051

152 221DA108 MACHINE SCREW 6

1091401400-052

153 221AA007 ROHS:BOLT_HEX-SCT 1

1091401400-053

154 221AA095 ROHS:BOLT_HEX-SCT 2

1091401400-054

155 221DA056 MACHINE SCREW 26

1091401400-055

156 221DA057 MACHINE SCREW 6

1091401400-056

0912-002

Fig. D2-2

UNIT-3

Fig. D2

CPU

SIGMA-G4DA

SIGMA-G4DB

SIGMA-G4DC

MEMO

CONTENTS

Fig. D3

電装部２

ELECTRICAL SECTION 2

Fig. D3-A1

全体図１

PARTS LAYOUT-1

Fig. D3-A2

全体図２

PARTS LAYOUT-2

Fig. D3-1

パネル２

Panel 2

Fig. D3-2

パネル１、３

Panel 1, 3

Fig. D3-3

ドライバ、基板

Driver, PCB

Fig. D3-4

照明基板、

LAN

パネル

Lighting PCB, LAN Panel

Fig. D3-5

中継パネル

Relay Panel

Fig. D3-6

ドライバケーブル

Driver Cable

Fig. D3-7 I/O

ケーブル

I/O Cable

Fig. D3-8 CPU2

ケーブル

CPU2 Cable

Fig. D3-9 CPU1

ケーブル

CPU1 Cable

0912-002

Fig. D3

UNIT-3

Fig. D3

ELEC2
