Main standard features □ Adjustable DI / DM water mixing and blending unit □ Automatic detergent concentration measurement / control □ Automatic monitoring of ionic residues contamination and gauging of rinse water quali…
Main standard features
□ PowerSpray
®
technology bundle: magnetically coupled X-Power (tank A) and S-Power (tank b) pump units, twofold
ASYNCHRO
®
volume-spray rotorsystem with PUSHFORCE
®
nozzles, "Option100" softwareprogram (100 freely
selectable programs)
□ EATON Programmable Logic Controller (PLC)
□ HT model for high temperature cleaning up to 80° Celsius
□ High resolution 7" (1,024 x 600 mm) display with capacitative multi-touch
□ PolyPower pump-nozzles configuration (up to three times more pressure power and up to 30% less cycle time)
□ Full flow coarse filter (process chamber)
□ Fine filters for both circuits
□ Sediment filters for both tanks
□ VMH
®
XL hot air evaporative drying (control range approx. 45° - 90° C / 113 and 194 °F)
□ ClosedLoop reprocessing of cleaning and rinsing fluids
□ Spare space for resin cartridge to be integrated into the system
□ Safety features: safety interlock on the process chamber door, overflow alarm for all tank sections, overheating protection for
all heating and drying elements, end switches for all motor-driven valves and drives, personnel protection insulation
□ Machine body made of stainless steel
□ Process sections made of electrolysis resistant elements
Page 3 of 6
Part number: 0905PSE32HY2-2
Fully automatic PowerSpray
®
triple hybrid system for ultra fine,
fine and maintenance cleaning of smaller quantities
01/21
PSE 300 2HY
Made in Germany
CLEANING TECHNOLOGY
kolb Cleaning Technology GmbH ▪ Karl-Arnold-Str.12 ▪ D - 47877 Willich ▪ Phone: +49 (0) 2154 9479 - 38 ▪ Fax: +49 (0) 2154 9479 - 47 ▪ e-mail: info@kolb-ct.com ▪ www.kolb-ct.com
All rights for changes reserved that lead to technical improvement. © kolb GmbH 2021
Main standard features
□ Adjustable DI / DM water mixing and blending unit
□ Automatic detergent concentration measurement / control
□ Automatic monitoring of ionic residues contamination and gauging of rinse water quality
□ Automatic re-dosage unit for 25 l detergent and 5 l additive container
□ Automatic water change for cleaning circuit
□ DeSealing filter insert for coating cleaning / paint stripping processes
□ Descaling unit to reduce the lime content in the rinsing water
□ Drip & storage reservoir
□ Exchange for rinse water and pump out unit
□ Exhaust unit
□ Heater for tank A (cleaning)
□ HMA filter (Heavy Metal Adsober) unit for the cleaning cicuit
□ MB- / DI-cartridge for deionized (DI) and demineralized (DM) water
□ MediumWipe
®
unit for further optimization of detergent and rinsing fluid use
□ PolyPower XL configuration with XL-PolyPower pump unit
□ Remote Control (remote monitoring, mailing, etc.)
□ Status light fivefold to display the current process state
□ Traceability "Basic" (SPC data scanner, data backup in CSV file, backup via WiFi SD card via slot in the PLC)
□ XL-Power pump unit for tank A
□ X-Power pump unit for tank B
Page 4 of 6
Part number: 0905PSE32HY2-2
Fully automatic PowerSpray
®
triple hybrid system for ultra fine,
fine and maintenance cleaning of smaller quantities
01/21
PSE 300 2HY
Made in Germany
CLEANING TECHNOLOGY
kolb Cleaning Technology GmbH ▪ Karl-Arnold-Str.12 ▪ D - 47877 Willich ▪ Phone: +49 (0) 2154 9479 - 38 ▪ Fax: +49 (0) 2154 9479 - 47 ▪ e-mail: info@kolb-ct.com ▪ www.kolb-ct.com
All rights for changes reserved that lead to technical improvement. © kolb GmbH 2021
Tank A
Cleaning
Tank B/C
Rinsing
Rinsing cycleCleaning cycle
Cleaning System
Fresh / recycled rinse water
Usable rinse water
Contaminated rinse water
Tank C
DI / DM
Water
ClosedLoop
ClosedLoop
TA
HMA-Filter
Filter
Filter
Filter
Filter
Filter
(Option)
Page 5 of 6
* Operating companies of industrial cleaning systems are responsible for proper disposal of wastewater / rinse water
and (wasted) cleaning detergent. Further information on wastewater management at www.kolb-ct.com/systems/water-
management/, consulting requests to info@kolb-ct.com
01/21
Part number: 0905PSE32HY2-2
Fully automatic PowerSpray
®
triple hybrid system for ultra fine,
fine and maintenance cleaning of smaller quantities
PSE 300 2HY
Internal rinse water processing (standard) Options* for water management
AOSelection
®
unit
separates mandatory disposable sewage water from rinse
water which can be discharged into a plublic sewage network.
