ZSfdr_KLJ_rev05_MaintePartsList_1904_OK.pdf - 第10页
3 14 18 3 38 20 16 15 31 30 1 32 19 33 34 35 22 6 17 36 24 23 2 37 29 21 37 11 9 37 12 10 13 13 5 7 27 25 26 8 28 4 4-1 KLJ-1901 Guide / Lever 32mm OPTION 3 14 18 3 38 20 16 15 31 30 1 32 19 33 34 35 22 6 17 36 24 23 2 3…
13
28
28
14
30
22
29
23
26
19
5
27
11,12
15
16
18
17
3
4
20
25
21
14
24
14
6,7,8,9,10
1
2
3-2
KLJ-1707
Clamp / Block
24mm
13
28
28
14
30
22
29
23
26
19
5
27
11,12
15
16
18
17
3
4
20
25
21
14
24
14
6,7,8,9,10
1
2
<Note-1> "Q'ty" becomes 0,1,2,3...
「Q'ty」は、0・1・2・3・・・になります。
<Note-2> "Q'ty" becomes 0,2,4,6...
「Q'ty」は、0・2・4・6・・・になります。
NO
Parts_No.
Parts_Name
Q'ty
Remarks
1
KLJ-MC10W-00
FRONT BLOCK ASSY.
1
2
91317-03008
BOLT,HEX.SOCKET HEAD
2
standardized
3
KHJ-MC105-00
PIN,TAIL
1
4
91312-03008
BOLT,HEX.SOCKET HEAD
2
5
KHJ-MC406-00
PLATE,UNDER
1
6
KHJ-MC107-00
SHIM,FRONT BLOCK 1
1
T0.01 <Note-1>
7
KHJ-MC108-00
SHIM,FRONT BLOCK 2
1
T0.05 <Note-1>
8
KHJ-MC10G-00
SHIM,FRONT BLOCK 3
1
T0.10 <Note-1>
9
KHJ-MC10U-00
SHIM,FRONT BLOCK 4
1
T0.03 <Note-1>
10
KHJ-MC10V-00
SHIM,FRONT BLOCK 5
1
T0.02 <Note-1>
11
KHJ-MC109-00
SHIM,PLATE UNDER 1
2
T0.01 <Note-2>
12
KHJ-MC10A-00
SHIM,PLATE UNDER 2
2
T0.05 <Note-2>
13
KLJ-MC2F3-00
BRKT. W,REEL HOLDER
1
14
90990-09J008
SCREW,FLAT HEAD
11
15
KHJ-MC183-00
SPACER,TENSION 1
1
16
KHJ-MC184-00
SPACER,TENSION 2
1
<Note-1>
17
KLJ-MC186-00
WIRE,UNCLAMP
1
18
KHJ-MC187-00
SPRING,TENSION
1
19
KLJ-MC18H-00
CLAMP LEVER ASSY.
1
20
KHJ-MC139-00
SHAFT,IDLE GEAR 1
1
21
KHJ-MC289-00
PIN,CLAMP
1
22
90440-01J030
CIRCLIP
1
23
KHJ-MC18A-00
SPRING,CLAMP
1
24
KLJ-MC18B-00
COVER,WIRE 1
1
25
KLJ-MC28C-01
COVER W,WIRE 2
1
26
KLJ-MC18K-00
LEVER,UNCLAMP ASSY.
1
27
KLJ-MC18L-00
PIN,LEVER UNCLAMP
1
28
90990-14J001
CIRCLIP
2
29
98707-03006
SCREW,FLAT HEAD
2
30
92A08-03306
SCREW,SET
1
3
14
18
3
38
20
16
15
31
30
1
32
19
33
34
35
22
6
17
36
24
23
2
37
29
21
37
11
9
37
12
10
13
13
5
7
27
25
26
8
28
4
4-1
KLJ-1901
Guide / Lever
32mm
OPTION
3
14
18
3
38
20
16
15
31
30
1
32
19
33
34
35
22
6
17
36
24
23
2
37
29
21
37
11
9
37
12
10
13
13
5
7
27
25
26
8
28
4
<Note-1> In case of your parts order, the concerned feeder's serial number is required.
部品発注の際には、該当するフィーダーのシリアル番号が必要です。
NO
Parts_No.
Parts_Name
Q'ty
Remarks
1
99480-03010
PIN,PARALLEL
3
2
KHJ-MC104-00
RAIL,UNDER
1
3
KLJ-MC50C-S0
SEAL,MAIN LABEL
1
<Note-1> "QR code" added : MP50061
4
KLJ-MC541-01
TAPE GUIDE ASSY. 32
1
H025412
5
KHJ-MC244-00
LEVER,TAPE GUIDE R
1
6
99480-04028
PIN,PARALLEL
1
7
KLJ-MC545-00
LEVER,TAPE GUIDE F
1
8
KHJ-MC54E-00
SHAFT,LEVER
1
9
KHJ-MC146-02
SPRING,TAPE GUIDE R
1
10
KLJ-MC547-00
SPRING,TAPE GUIDE F
1
11
KLJ-MC54Y-00
PLATE,STOPPER
1
12
KLJ-MC1H1-00
COLLOR,STOPPER R
1
13
91312-03006
BOLT,HEX.SOCKET HEAD
2
14
KLJ-MC562-S0
PARTS,BOX COVER
1
<Note-1> MP90025
15
KLJ-MC562-00
COVER, TOP TAPE BOX
1
16
91317-03020
BOLT,HEX.SOCKET HEAD
6
17
91317-03030
BOLT,HEX.SOCKET HEAD
1
18
KLJ-MC563-S0
PARTS,TAIL COVER
1
<Note-1> MM60163
19
KLJ-MC563-00
COVER,TAIL
1
20
KLJ-MC575-00
PIN,TAIL COVER
1
21
KHJ-MC56V-00
P/O LEVER ASSY.
1
22
99480-05030
PIN, PARALLEL
1
23
KHJ-MC26E-00
SPRING,P/O LEVER
1
24
90990-09J008
SCREW,FLAT HEAD
2
25
KLJ-MC281-01
HANDLE W
1
MK40111
26
KHJ-MC58G-00
SHAFT,HANDLE SUPPORT
1
27
KHJ-MC53N-00
PIN,DOWEL
1
28
91317-05016
BOLT,HEX.SOCKET HEAD
1
29
91317-04012
BOLT,HEX.SOCKET HEAD
1
30
99480-05014
PIN, PARALLEL
1
31
KLJ-MC5F4-00
PLATE,SUPPORT
1
32
98902-03005
SCREW, BINDING HEAD
2
33
KHJ-MC1A9-00
CONNECTOR,BOARD
1
34
90166-02JA06
SCREW,PAN HEAD
2
35
KLJ-MC1AM-00
SHIELD,CONNECTOR
1
36
92A08-03306
SCREW, SET
1
M3*L6
37
92A08-03303
SCREW, SET
3
M3*L3
38
KLJ-MD904-00
REEL HOOK,32MM
1
<OP> 15 inch reel applicable : MK90051
15
30
30
16
31
23
7
7
21
25
28
5
29
6
17
18
13,14
20
19
24
3
4
27
22
16
26
16
8,9,10,11,12
1
2
4-2
KLJ-1708
Clamp / Block
32mm
<Note-1> "Q'ty" becomes 0,1,2,3...
<Note-2> "Q'ty" becomes 0,3,6,9...
「Q'ty」は、0・1・2・3・・・になります。
「Q'ty」は、0・3・6・9・・・になります。
15
30
30
16
31
23
7
7
21
25
28
5
29
6
17
18
13,14
20
19
24
3
4
27
22
16
26
16
8,9,10,11,12
1
2
NO
Parts_No.
Parts_Name
Q'ty
Remarks
1
KLJ-MC10W-00
FRONT BLOCK ASSY.
1
2
91317-03008
BOLT,HEX.SOCKET HEAD
2
3
KHJ-MC105-00
PIN,TAIL
1
4
91312-03008
BOLT,HEX.SOCKET HEAD
2
5
KHJ-MC106-00
PLATE,UNDER
1
6
KHJ-MC206-00
PLATE,UNDER
1
7
98707-03006
SCREW,FLAT HEAD
4
8
KHJ-MC107-00
SHIM,FRONT BLOCK 1
1
T0.01 <Note-1>
9
KHJ-MC108-00
SHIM,FRONT BLOCK 2
1
T0.05 <Note-1>
10
KHJ-MC10G-00
SHIM,FRONT BLOCK 3
1
T0.10 <Note-1>
11
KHJ-MC10U-00
SHIM,FRONT BLOCK 4
1
T0.03 <Note-1>
12
KHJ-MC10V-00
SHIM,FRONT BLOCK 5
1
T0.02 <Note-1>
13
KHJ-MC109-00
SHIM,PLATE UNDER 1
3
T0.01 <Note-2>
14
KHJ-MC10A-00
SHIM,PLATE UNDER 2
3
T0.05 <Note-2>
15
KLJ-MC2F3-00
BRKT. W,REEL HOLDER
1
16
90990-09J008
SCREW,FLAT HEAD
11
17
KHJ-MC183-00
SPACER,TENSION 1
1
18
KHJ-MC184-00
SPACER,TENSION 2
1
<Note-1>
19
KLJ-MC186-00
WIRE,UNCLAMP
1
20
KHJ-MC187-00
SPRING,TENSION
1
21
KLJ-MC18H-00
CLAMP LEVER ASSY.
1
22
KHJ-MC289-00
PIN,CLAMP
1
23
90440-01J030
CIRCLIP
1
24
KHJ-MC139-00
SHAFT,IDLE GEAR 1
1
25
KHJ-MC18A-00
SPRING,CLAMP
1
26
KLJ-MC18B-00
COVER,WIRE 1
1
27
KLJ-MC28C-01
COVER W,WIRE 2
1
28
KLJ-MC18K-00
LEVER,UNCLAMP ASSY.
1
29
KLJ-MC18L-00
PIN,LEVER UNCLAMP
1
30
90990-14J001
CIRCLIP
2
31
92A08-03306
SCREW,SET
1
