9 DEK FLEX NeoHorizon P PiX Machine S t andard C onf igurati on Services Specification Voltage 100 Volts to 240 Volts ± 10%. Single phase 50/60 Hz Maximum Curr ent at 11 5V 15 Amps wit h vacuum pu mp 6 Amps w ithou t vac…
8
DEK FLEX NeoHorizon LPiX
Machine Standard Configuration
Vision
Specification
Vision System
SFF
Fiducial Recognition
Automatic fiducial teach and find incorporating 0.3mm
fiducial capture
Fiducials
2 or 3
Fiducial Types
Synthetic fiducial library or unique pattern recognition
Fiducial Size
0.3mm to 3mm*
Fiducial Locations
Anywhere on substrate
Fiducial Error Recovery
Auto lighting adjustment
Auto fiducial search
Camera Lighting
Software controlled programmable LED lighting
*0.1mm to 3mm available via RFQ
Chase
Specification
Screen Frame Size (maximum)
736mm x 736mm (29” x 29”)
Screen Frame Thickness
25mm to 38mm (1” to 1.5”)
Image Position
Front
Centre
Custom
Operating Environment*
Specification
Temperature
10° to 35°C (50° to 95°F)
Humidity
30% to 70% relative humidity (non-condensing)
Altitude
Maximum 2,000 metres (6,500 feet)
Location
Internal only, not suitable for wet locations
*as described in the IPC Standard J-STD-001G-Reqirements for Soldered Electrical and Electronic
Assemblies Section 4 with respect to the following:
• Facilities - Cleanliness and ambient environments in all work areas be maintained at levels that
prevent contamination or deterioration of tools, materials, and surfaces to be soldered or
conformally coated. Eating, drinking, smoking, including use of e-cigarettes, and/or use of
tobacco products be prohibited in the work area.
• Environmental Controls - The soldering facility (controlled work area) be enclosed, temperature
and humidity controlled, and maintained at a positive pressure.
• Controlled Work Area (CWA) For the purpose of this statement, a Controlled Work Area
(CWA) is defined as an enclosed assembly / processing area maintained to a high degree of
shop cleanliness, environmental control, and foreign object debris (FOD) mitigation, either by
process or procedure, to limit the entry of contamination.
9
DEK FLEX NeoHorizon PPiX
Machine Standard Configuration
Services
Specification
Voltage
100 Volts to 240 Volts ±10%. Single phase 50/60 Hz
Maximum Current at 115V
15 Amps with vacuum pump
6 Amps without vacuum pump
Maximum Current at 230V
8 Amps with vacuum pump
3 Amps without vacuum pump
Over Current Protection
An external circuit breaker ≤20 Amps is required to be
fitted in line with the machine supply
Air Supply
To ISO 8573.1 Standard Quality Class 2.3.3
Pressure 5 bar to 8 bar
General usage 5 litres/minute at 5 bar to 8 bar
Maximum usage 226 litres/minute at 6 bar
Shipping Information
Specification
Approximate Weight
862kg boxed (dependent upon configured options
selected with machine)
7120kg unboxed (dependent upon configured options
selected with machine)
Approximate Dimensions
2080mm x 1500mm x 1590mm High
(81.9” x 59” x 62.6”) Boxed
Certification
Specification
CE
98/37/EC
89/336/EEC
73/23/EEC
Subsequent amendments
Acoustic Noise Level
Less than 70dB 2003/1/EC
10
DEK FLEX NeoHorizon PPiX
Machine Productivity Package (included)
Process
Specification
Paste Control
Paste Dispenser (APDII or Jar Dispenser)
Paste Roll Height Monitor (PRHM 2)
Under Stencil Cleaning
Typhoon Standard or iUSC. Specify length (300mm,
400mm, 520mm)
Transport
Specification
Substrate Support
Vacuum tooling capability
Vacuum tooling sensor
Vacuum cups
Data Capture
Specification
Product Data Capture
Verification & Traceability (Software only)
ProDEK closed loop (Software only)
Software & Communications
Specification
Software & Communications
Network files
Statistical Process Control
On board, reported via operator interface (QC-CALC)
Vision & Verfication
Specification
HawkEye® 1700 Paste on Pad
Verification
Enabled
