Model DECAN Series Company SAMSUNG TECHWIN Module 1. 设备概述 V ersion 01 Tit le 设备选项 (L2) Page 1-10 Note [ 设备选项 (L2)] 设备选项及布局为如下。 Dual Lane Single Lane
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
1. 设备概述
Version
01
Title
设备选项(F2)
Page
1-9
Note
[设备选项(F2)]
设备选项及布局为如下。
Dual Lane
Single Lane
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
1. 设备概述
Version
01
Title
设备选项(L2)
Page
1-10
Note
[设备选项(L2)]
设备选项及布局为如下。
Dual Lane
Single Lane
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
1. 设备概述
Version
01
Title
维修工具
Page
1-11
Note
[维修工具]
No. Name Remark Image
1
CALIBRATION
NOZZLE
SM471,DECAN, CN400 NOZZLE
2
LIGHT MAPPING
TOOLASSY-FLY-ODD
SM32X,SM41X,SM42X,DECAN
3
LIGHT MAPPING
TOOL ASSY-FIX
SM48X,SM421,SM411F,SM451,
DECAN
4
NOZZLE HOLDER
SLOT SETTING JIG
SM421, SM482, DECAN L2
5
NOZZLE HOLDER
SLOT SETTING JIG
SM471,DECAN F2
6
SONIC TENSION
METER
ALL MACHINE
7
BLOW SETTING
MEASUREMENT
ALL MACHINE
