Model DECAN Series Company SAMSUNG TECHWIN Module 1. 设备概述 V ersion 01 Tit le 维修工具 Page 1-13 Note No. Name Function Image 14 LINEAR SCALE HEAD SETTING CABLE CONVERTER EXCEN PRO, EXCEN FLEX, DECAN 15 Y SHAFT ORIGIN SETTING…
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
1. 设备概述
Version
01
Title
维修工具
Page
1-12
Note
No. Name Function Image
8
FEEDER STATION
ALIGNMENT FOR
SM FEEDER
SM32X, SM310, SM41X, SM42X,
DECAN
9
Z AMP PARAMETER
DOWNLOAD CABLE
SM471, SM481, SM482, DECAN
10
Y SHAFT LINEAR
MOTOR COIL
ASSEMBLY JIG
DECAN
11
FIDUCIALMAPPING
CHART
ALL MACHINE
12
PARASONIC AMP
DATA CABLE
DECAN
13
LINEAR SCALE
HEAD
SETTING CABLE
EXCEN PRO, EXCEN FLEX, DECAN
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
1. 设备概述
Version
01
Title
维修工具
Page
1-13
Note
No. Name Function Image
14
LINEAR SCALE
HEAD
SETTING CABLE
CONVERTER
EXCEN PRO, EXCEN FLEX, DECAN
15
Y SHAFT ORIGIN
SETTING JIG
DECAN
16
FIDUCIAL CAMERA
OFFSET
CALIBRATION PLATE
SM SERIES
17
FLY CAM SCALE
(OFFSET)
CALIBRATION TOOL
SM SERIES
18
自己安装程度测定用
玻璃杯
SM471, 481, DECAN, EXCEN
EXCEN PRO, EXCEN FLEX
19
FIDUCIAL CAM
偏光过滤器
SM471, 481, DECAN, EXCEN
EXCEN PRO, EXCEN FLEX
Model
DECAN Series
Company
SAMSUNG TECHWIN
Module
1. 设备概述
Version
01
Title
气动图
Page
1-14
Note
[气动图]
设备整个气动图
