20.04.2017 Page 3
General
Placement of Tall and Odd Shaped Components 40 mm & 70 N (Twin VHF)
Die new option Twin Very High Force 40mm components 70Nm displace the VHF P&P
30mm components and 70Nm from the SuP50. This option is available for SX1,
SX1prepared and SX2 machines.
Preconditions:
- Improved machine frame with an higher input and output section
(New machine-serial number started with Mxxxx).
- Station Software 707.0x / Siplace Pro11.1
General description:
The option need a complete new gantry which is higher as the standard gantry. The
machine recognize the gantry automatically via the head ID. This new gantry can be
use only for the Twin VHF head, no other heads.
The option Smart Pin Support is possible, with a updated Pin Picker-new part-number!
20.04.2017 Page 4
- improved mineral frame SX
- new Gantry for 40mm components, SW-identification via headtype
- new head holder
- new PCB camera
- update WPC5/6 45mm (40mm components + 5mm tray)
- changed position for the X - axis incremental scale
- updated service tool to change the incremental scale
“Set splicing equipment X-scale SIP.SX 03079041-02“
- new front cover for this option is necessary, if an WPC mounted.
New or updated parts for the Option Twin VHF
20.04.2017 Page 5
Configuration packages
Sales Number: 00519986 Option pack Twin VHF 40mm70N with gantry
Content:
1. 03105049-xx “GR gantry 40 mm w/ VHF-Twin module“
2. 03105335-xx “Reconfig. kit VHF Twin module”
Configurable packages via SAP:
1. 00519902-xx Stationary IC-Camera (00519918-xx Stationary FC-Camera Type 25)
2. 00519845-xx Nozzle changer TH for SX machine
3. 00519988-xx Option SPS (include 03104671-01SPS Pin Picker 40mm machine)
4. 00119827-xx WPC 5 Standard
5. 00119828-xx WPC 6 Non Stop module Option WPC 5/6
Ma-Type
SX1 SX2 SX2 SX2 SX2 SX2
Gantry 1
Twin VHF CPP_H Twin VHF Twin Head Twin VHF Twin VHF
Gantry 2
--
Twin VHF CPP_H Twin VHF Twin Head Twin VHF
