YAMAMAMOTORCO.,LTD IMOperations ReleaseNote(Eng lish) 2014/10/17 3.43 1.000 Bug Mounter ASF Whenanadjustablestickfeederwasdettachedan dattachedafterthemachinewas poweredon,therewasabugthatfeeding…

YAMAMAMOTORCO.,LTD

IMOperations

ReleaseNote(English) 2014/10/17

3.43 1.000 Mounter Boarddata

NumberofLocalFiducialDataandLocalBadmarkDatahasbeenexpandedfrom512to

12,800.

*Y.FacTissupportedinV1.45STDR1.000orlater.

Modified

3.43 1.000 Mounter Mount

Onmounter,themaximumnumberofmountingpoints×blocknumberhasbeen

expandedfrom20,480to32,000points.

*Y.FacTissupportedinV1.45STDR1.000orlater.

Modified

3.43 1.000 YSP20 Cleaning

Whentestprintingorrollingwasexecutedonalanejustbeforetheotherlanestarted

cleaning,therewasabugthattheconveyor(Y-axis)interferedwiththemask(MZ-axis).

Fixed

3.43 1.000 Add

YSSeries

Mounter

ASF

Forsafetyreasons,ithasbeenmodifiedtostopASFassoonasthemachinemakesan

emergencystop.

Modified

3.43 1.000 Add

YSSeries

Mounter

Feeder

FeederMaintenanceStophasbeenaddedtoFeederMaintenanceNotice.

Itnotifiesthatafeederrequiresmaintenance,whencertaintimesoffeedinghavebeen

donesincelastmaintenance.

Modified

3.43 1.000 Add YSP Cleaning

AnothertimingtodocleaninghasbeenaddedonYSP.

Existingtiming:

1.Aboardexistsattheexitandtheprintposition,waitingforboardcarry-outtothe

downstreammachine

2.Whenaboardcarriedintotheprintposition



Additionaltiming:

1.Duringcarry-outtothedownstreammachineorthereisnoboardinthemachine,

waitingforboardcarry-infromtheupstreammachine



Modified

3.43 1.000 Add YSP20

Conveyor

width

IthasbeenmodifiedtodisplayPU-axisinterlockerrorwhentheaxisgoesovertheorigin

atmovingW-axis.Also,whenthePU-axisgoesovertheoriginatconveyorwidthchange,

ithasbeenmodifiedtomovedownPU-axistotheorigin.

Modified

3.43 1.000 Add Machine GUI

Onthefollowingscreen,ithasbecomepossibletore-displayhiddenwarningdialogs.

[Setup]-[SoftwareSetting]-[History]-[DetailHistorysetting].



Modified

3.43 1.000 Add Printer Printer

PrintObservationFunctionhasbeenadded.

Itcheckssqueegeepressureduringprinting.Ifit'soverthespeficicatin,anerroroccurs

aftertheprintingiscompleted.

*OnY.FacT,thisfunctionisavailableinV1.46STD_R1.000orlater.



Modified

3.43 1.000 Change YC8,YSC1 Mark

When[MachineSetting]-[FactorySetting]-[MountingInformationMode]is[V2.0

compatibleMode],ithasbeenimprovedtoset[Mark]-[Vision]-[Height(mm)]tab.

Modified

3.43 1.000 Change YSP20 HistoryLog

"Ea8288:CLEANERVACUUMUPCHECKERROR"hasbeendevidedintothefollowing

errorsdependingoncauses.

1.Ea8299:VacuumPathChangeError

2.Ea8420:CleanerVacuumONStateChangeError

Modified

3.43 1.000 Change Machine GUI

Ithasbeenmodifiedlayoutofscreen.

[Setup]-[SoftwareSetting]-[Network]-[Networksetting]

Modified

3.43 1.000 Change Machine Monitor

Thecalculationmethodof[Monitor]-[Detail]-[EstimatedEndTime]hasbeenchanged

asfollows.



Before:

currenttime＋（planningproductioncount－productioncount）×（（currenttime－

productionstarttime）÷（productioncount－productionstartcount））



After:

currenttime＋（planningproductioncount－productioncount）×（（currenttime－

operationstarttime）÷（productioncount－productionstartcount））



Modified

3.43 1.000 Bug Mounter ASF

WhenanovercurrentoccurredatthefeederpartofASF,therewasabugthat

"Ea30120:FeederDataReadError"occurredandauto-runningcouldn'tstartafterthat.



Fixed

MDOCV30-00001 9/14

YAMAMAMOTORCO.,LTD

IMOperations

ReleaseNote(English) 2014/10/17

3.43 1.000 Bug Mounter ASF

Whenanadjustablestickfeederwasdettachedandattachedafterthemachinewas

poweredon,therewasabugthatfeedingpartofASFdidn'tworksothatpartswerenot

carriedtothepickupposition.

Fixed

3.43 1.000 Bug Mounter ASF

Whenauto-runningwasstartedafterASFattachedcartOFF->ON,therewasabugthat

thepartswerenotpickupatpickuppositionandslept.



Fixed

3.43 1.000 Bug Mounter CTEstimation

Underthefollowingconditions,therewasacasethattheamountoftimeforthehead

ascent/descentofpickupandmountingoperationscalculatedlessthanactual.

1.AnyoneofYS24(X),YS12orYG12series

2.Intheboarddata,selectanozzletypewith[SpecInfo]-[MountingNozzleSpec]-

[NozzleData]-[Buffing]setto"nothing".

*Y.FacTissupportedinV1.45STDR1.000orlater.

Fixed

3.43 1.000 Bug Mounter GUI

”3DRecognitionResult"stringwasnotcompletelydisplayedonthe[SoftwareSetting]-

[Basic]-[VisionImageSave]Dialog.



Fixed

3.43 1.000 Bug Mounter Warmup

Whenanoperatorputapalletonthehookstagebyhandandstartedwarm-up,therewas

abugthatthehookclumpinterferedwiththepallet.

Ithasbeenmodifiedtodisplay"Ea29140:AutoTrayChanger:PalletSetError"insucha

case.



Fixed

3.43 1.000 Bug Mounter ErrorMessage

Therewasabugthatnoaxisnamewasdisplayedinthefollowingerrors.

1.Es00069:EncoderBreakA/B/C

2.Es00503:SERIALENCODERCOMMUNICATIONERROR

3.Es00505:SERIALENCODERINITIALIZEERROR

4.Es00523:MotorEncoderCom.Err.2

5.Es00525:MotorEncoderCom.Err.3

6.Es00527:MotorEncoderCountError

7.Es00535:MotorEncoderPulseLoss



Fixed

3.43 1.000 Bug Mounter ErrorMessage

When[Parts]-[Basic]-[RetryTimes]issetto"NORETRY",therewasabugthat

another"Ea36:VACUUMLEVELERROR"wasunnecessarilydisplayed.



Fixed

3.43 1.000 Bug Mounter

Conveyor

width

Although"Yes"wasselectedon"Ea12522:Doyouwishtoenforceconveyorwidth

change?"thatisdisplayedafter"Ea3211:W-AXISINTERLOCKERROR"cleared,there

wasabugthat"Ea12051:Machinecontrolstopped."alwaysoccurred.



Fixed

3.43 1.000 Bug Mounter Tray

Underthefollowingconditions,therewasabugthatthepartsweredumpednoton

RecoveryPallet.

1.[Machine]-[InstallationSetting]-[RecoveryPallet]issetto"EXIST"

2.[Machine]-[TrayChanger]-[Position]-[RecoveryPalletNumber]-[Magazine1]or

[Magazine2]issetto"0"

3.Usesuchthepartsdatatopickupfromthemagazinethat[Parts]-[Tray]-[Pallet

Number]hasbeensetto"0"at2.

4.Afterstartauto-running,andthemachineisresetduringthetimewhenpartsare

pickedanduntilmounted.



Fixed

3.43 1.000 Bug Mounter Vision

Underthefollowingsettingonthe[Parts]-[Shape]screen,therewasabugthat[Min.

BrightnessDifference]wasnotdisplayedinpartsdata.

1.[AlignmentGroup]：Special

2.[AlignmentType]：Special

3.[Algorithm]：9:Insertion-Component

4.[CheckDirectionEnable]：ON



Fixed

3.43 1.000 Bug Mounter Feeder

Whenitfailedinthesettingofpartsfeedtimerbyafeederfailureorcontactfailure,

therewasabugthat"Ea0:NOERRORMESSAGEREGISTRATION"wronglyoccurred,so

thattheoperatorcouldn'tfindthecause.

*Originally,itdisplays"Ea30141:Updatefailureoffeedertimer".



Fixed

3.43 1.000 Bug Mounter

Mark

Recognition

Onamachineequippedwithtwin-fiducialcamera,therewasacasethat"Es305:Soft

LimitOver"occurredatmarkrecognitionalthoughthecamerawasactuallyattheright

position.

Fixed

3.43 1.000 Bug Mounter Monitor

Onasingle-tablemachineor__YSH20__,whentheerroroccurredatrearsideofmachine

closedby[Close]button,therewasabugthattheerrorhasnotbeendisplayedat[Work

Instruction]areaof[Monitor]-[Production]screen.

Fixed

3.43 1.000 Bug Mounter

PickPosition

Correction

Underthefollowingconditions,therewasacasethatpickupwasperformedatawrong

position,andapickuperrororovercurrentoccuured.

1.Set[Parts]-[Options]-[PickupPositionOffset]to"Use"

2.Set[Machine]-[PickPositionSpecification]tootherthan"NotUse"



Fixed

MDOCV30-00001 10/14

YAMAMAMOTORCO.,LTD

IMOperations

ReleaseNote(English) 2014/10/17

3.43 1.000 Bug Mounter Optimization

Therewasabugthatestimatedcycletimewasmuchlongerthanactual,becausehigh-

speedsmartrecognitionparts(*)werewronglytreatedwith1by1mounting.

Therefore,boarddatawithimproperlinebalancecouldhavebeenmade.

*SmartrecognitionpartscreatedinV4.42STD_R1.000orlater.

*Y.FacTissupportedinV1.45STDR1.000.



Fixed

3.43 1.000 Bug Mounter Axis

Whenthemachinestoppedduringagatemotion,therewasabugthattheheadmovedin

100%ofspeed,ignoringthesettingatstopdelayoratrestarting.

Therefore,theheadcouldhavedroppedparts.



Fixed

3.43 1.000 Bug Mounter

Vaccum

Checking

Underthefollowingconditions,whenauto-runninganddisposaloperationwere

performed,therewasabugthat"Ea3269:VacuumCheckErrorBeforeDump"often

occurred.

1.[Machine]-[MachineData]-[Mechanical]-[Position]-[Vacuumcheckbefore

dump]issetto"Enable".

2.[Machine]-[MachineData]-[Mechanical]-[Position]-[InvalidVacuumDifference]

issetto"0".



Fixed

3.43 1.000 Bug Mounter Partadj

Therewasabugthat[FindBest]wasnotperformedwithproperlightlevel,sothat

"Comp.Threshold"wascalculatedproperlyandrecognitionerroroccurredandcorrect

partsweredumped.

Fixed

3.43 1.000 Bug Mounter PartsInfo

Ithasbeenmodifiedtodisplay[Cntr.OffsetX],[Cntr.OffsetY]and[Cntr.OffsetR]onthe

[Parts]-[Shape]screenunderthefollowingconditions.

1.[AlignmentGroup]:Special

2.[AlignmentType]:Special

3.[Algorithm]:9:Insertion-Component

4.[EditMode]:Simplicity

Fixed

3.43 1.000 Bug Mounter Recognition

Underthefollowingconditions,therewasacasethat"Ea31:PICKUPERROR"occurred

thoughpickinguptheparts.



1.[Parts]-[Shape]-[AlignmentGroup]and[AlignmentType]arefallingunderanyof

following.

1)[AlignmentGroup]issetto"IC"and[AlignmentType]oneof"SOP","SOJ",

"PLCC","QFP","OffLead"

2)[AlignmentGroup]issetto"Connector"and[AlignmentType]oneof"Con-E",

"Con-NSEW","Sp.Con"

3)[AlignmentGroup]issetto"Special"and[AlignmentType]issetto"Special"

2.[Parts]-[Shape]-[LeadNumber]issetto"1"



Fixed

3.43 1.000 Bug Mounter HistoryLog

When[SoftwareSetting]-[History]-[DetailHistory]-[RemembertheLotlog]isused,

therewasacasethat"Ea2874：BOARDAUTOSWITCHINGFAILURE"occurredonthe

machinestartup.



Fixed

3.43 1.000 Bug YS12Series HistoryLog

Withthefollowingboarddata,therewasabugthat[MIS]-[Boardlog]-[Mounted

Blocks]wasalwaysindicatedwith"0",whenthemachinewasresetafterCYCLESTOP.

1.On[Board]-[Offset],onlyoneoffsetiscreated.

2.The[Board]-[Badmark]-[Edit]-[Local]checkboxischecked.



Fixed

3.43 1.000 Bug

YS24(X)

Series

NozzleChange

Duringauto-running,therewasacasethatatablewasmovedupwhiletheotheris

workingnozzlebuffingcheck.

Inthatcase,”Ea201:NOZZLECHANGEERROR"occurred.



Fixed

3.43 1.000 Bug

YS24(X)

Series

Axis

Therewasabugthatmachinemighthavesleptwhen"Ea7409:AXISMOVEPOSITION

INTERFEREALARM"occurred.



Fixed

3.43 1.000 Bug

YS24(X)

Series

CleaningBlow

Therewasabugthatcontainstheunnecessarywords"TABLE-B"intheexplanationof

BLOWSTATIONUNITofI/Omonitor.



Fixed

3.43 1.000 Bug YS24DS Monitor

Therewasabugthataboardlargerthan330mmwasdisplayedonthewrongpositionof

thefollowingmonitorscreens.

1.[Monitor]-[Production]

2.[Monitor]-[Production]-[BoardIDMonitor]

Fixed

3.43 1.000 Bug YC8 Partadj

WhenMultiMACSwasperformedonthe[PartAdj]screen,therewasabugthat

unnecessaryrecognitionwasperformedafterthat,"Ea21419:OCRPARTS

RECOGNITIONERROR"occurred.



Fixed

MDOCV30-00001 11/14
