YAMAMAMOTORCO.,LTD
IMOperations
Cover 2014/10/17
※Thecolumnof[Type]inthereleasenoteisdefinedasfollows
Line
Category
YG12
Series
YG300 YS12
Series
YS24
Series
YS24X
Series
YS100 YS88 YSH20 YC8 YSP YSP20
YG12 YG300 YS12 YS24SL YS24XSL YS100 YS88 YSH20-FF YC8 YSP YSP20
YG12F YS12P YS24DL YS24XDL YSH20-4M
YS12F YS24DS YS24XDS
Printer
Type
AllMachine
Series
YGSeries YSSeries
Mounter
MDOCV30-00001 8/14
YAMAMAMOTORCO.,LTD
IMOperations
ReleaseNote(English) 2014/10/17
3.43 1.000 Mounter Boarddata
NumberofLocalFiducialDataandLocalBadmarkDatahasbeenexpandedfrom512to
12,800.
*Y.FacTissupportedinV1.45STDR1.000orlater.
Modified
*
3.43 1.000 Mounter Mount
Onmounter,themaximumnumberofmountingpoints×blocknumberhasbeen
expandedfrom20,480to32,000points.
*Y.FacTissupportedinV1.45STDR1.000orlater.
Modified
3.43 1.000 YSP20 Cleaning
Whentestprintingorrollingwasexecutedonalanejustbeforetheotherlanestarted
cleaning,therewasabugthattheconveyor(Y-axis)interferedwiththemask(MZ-axis).
Fixed
3.43 1.000 Add
YSSeries
Mounter
ASF
Forsafetyreasons,ithasbeenmodifiedtostopASFassoonasthemachinemakesan
emergencystop.
Modified
3.43 1.000 Add
YSSeries
Mounter
Feeder
FeederMaintenanceStophasbeenaddedtoFeederMaintenanceNotice.
Itnotifiesthatafeederrequiresmaintenance,whencertaintimesoffeedinghavebeen
donesincelastmaintenance.
Modified
*
3.43 1.000 Add YSP Cleaning
AnothertimingtodocleaninghasbeenaddedonYSP.
Existingtiming:
1.Aboardexistsattheexitandtheprintposition,waitingforboardcarry-outtothe
downstreammachine
2.Whenaboardcarriedintotheprintposition
Additionaltiming:
1.Duringcarry-outtothedownstreammachineorthereisnoboardinthemachine,
waitingforboardcarry-infromtheupstreammachine
Modified
3.43 1.000 Add YSP20
Conveyor
width
IthasbeenmodifiedtodisplayPU-axisinterlockerrorwhentheaxisgoesovertheorigin
atmovingW-axis.Also,whenthePU-axisgoesovertheoriginatconveyorwidthchange,
ithasbeenmodifiedtomovedownPU-axistotheorigin.
Modified
3.43 1.000 Add Machine GUI
Onthefollowingscreen,ithasbecomepossibletore-displayhiddenwarningdialogs.
[Setup]-[SoftwareSetting]-[History]-[DetailHistorysetting].
Modified
3.43 1.000 Add Printer Printer
PrintObservationFunctionhasbeenadded.
Itcheckssqueegeepressureduringprinting.Ifit'soverthespeficicatin,anerroroccurs
aftertheprintingiscompleted.
*OnY.FacT,thisfunctionisavailableinV1.46STD_R1.000orlater.
Modified
*
3.43 1.000 Change YC8,YSC1 Mark
When[MachineSetting]-[FactorySetting]-[MountingInformationMode]is[V2.0
compatibleMode],ithasbeenimprovedtoset[Mark]-[Vision]-[Height(mm)]tab.
Modified
3.43 1.000 Change YSP20 HistoryLog
"Ea8288:CLEANERVACUUMUPCHECKERROR"hasbeendevidedintothefollowing
errorsdependingoncauses.
1.Ea8299:VacuumPathChangeError
2.Ea8420:CleanerVacuumONStateChangeError
Modified
3.43 1.000 Change Machine GUI
Ithasbeenmodifiedlayoutofscreen.
[Setup]-[SoftwareSetting]-[Network]-[Networksetting]
Modified
3.43 1.000 Change Machine Monitor
Thecalculationmethodof[Monitor]-[Detail]-[EstimatedEndTime]hasbeenchanged
asfollows.
Before:
currenttime＋（planningproductioncount－productioncount）×（（currenttime－
productionstarttime）÷（productioncount－productionstartcount））
After:
currenttime＋（planningproductioncount－productioncount）×（（currenttime－
operationstarttime）÷（productioncount－productionstartcount））
Modified
3.43 1.000 Bug Mounter ASF
WhenanovercurrentoccurredatthefeederpartofASF,therewasabugthat
"Ea30120:FeederDataReadError"occurredandauto-runningcouldn'tstartafterthat.
Fixed
MDOCV30-00001 9/14
YAMAMAMOTORCO.,LTD
IMOperations
ReleaseNote(English) 2014/10/17
3.43 1.000 Bug Mounter ASF
Whenanadjustablestickfeederwasdettachedandattachedafterthemachinewas
poweredon,therewasabugthatfeedingpartofASFdidn'tworksothatpartswerenot
carriedtothepickupposition.
Fixed
3.43 1.000 Bug Mounter ASF
Whenauto-runningwasstartedafterASFattachedcartOFF->ON,therewasabugthat
thepartswerenotpickupatpickuppositionandslept.
Fixed
3.43 1.000 Bug Mounter CTEstimation
Underthefollowingconditions,therewasacasethattheamountoftimeforthehead
ascent/descentofpickupandmountingoperationscalculatedlessthanactual.
1.AnyoneofYS24(X),YS12orYG12series
2.Intheboarddata,selectanozzletypewith[SpecInfo]-[MountingNozzleSpec]-
[NozzleData]-[Buffing]setto"nothing".
*Y.FacTissupportedinV1.45STDR1.000orlater.
Fixed
3.43 1.000 Bug Mounter GUI
”3DRecognitionResult"stringwasnotcompletelydisplayedonthe[SoftwareSetting]-
[Basic]-[VisionImageSave]Dialog.
Fixed
3.43 1.000 Bug Mounter Warmup
Whenanoperatorputapalletonthehookstagebyhandandstartedwarm-up,therewas
abugthatthehookclumpinterferedwiththepallet.
Ithasbeenmodifiedtodisplay"Ea29140:AutoTrayChanger:PalletSetError"insucha
case.
Fixed
3.43 1.000 Bug Mounter ErrorMessage
Therewasabugthatnoaxisnamewasdisplayedinthefollowingerrors.
1.Es00069:EncoderBreakA/B/C
2.Es00503:SERIALENCODERCOMMUNICATIONERROR
3.Es00505:SERIALENCODERINITIALIZEERROR
4.Es00523:MotorEncoderCom.Err.2
5.Es00525:MotorEncoderCom.Err.3
6.Es00527:MotorEncoderCountError
7.Es00535:MotorEncoderPulseLoss
Fixed
3.43 1.000 Bug Mounter ErrorMessage
When[Parts]-[Basic]-[RetryTimes]issetto"NORETRY",therewasabugthat
another"Ea36:VACUUMLEVELERROR"wasunnecessarilydisplayed.
Fixed
3.43 1.000 Bug Mounter
Conveyor
width
Although"Yes"wasselectedon"Ea12522:Doyouwishtoenforceconveyorwidth
change?"thatisdisplayedafter"Ea3211:W-AXISINTERLOCKERROR"cleared,there
wasabugthat"Ea12051:Machinecontrolstopped."alwaysoccurred.
Fixed
3.43 1.000 Bug Mounter Tray
Underthefollowingconditions,therewasabugthatthepartsweredumpednoton
RecoveryPallet.
1.[Machine]-[InstallationSetting]-[RecoveryPallet]issetto"EXIST"
2.[Machine]-[TrayChanger]-[Position]-[RecoveryPalletNumber]-[Magazine1]or
[Magazine2]issetto"0"
3.Usesuchthepartsdatatopickupfromthemagazinethat[Parts]-[Tray]-[Pallet
Number]hasbeensetto"0"at2.
4.Afterstartauto-running,andthemachineisresetduringthetimewhenpartsare
pickedanduntilmounted.
Fixed
3.43 1.000 Bug Mounter Vision
Underthefollowingsettingonthe[Parts]-[Shape]screen,therewasabugthat[Min.
BrightnessDifference]wasnotdisplayedinpartsdata.
1.[AlignmentGroup]：Special
2.[AlignmentType]：Special
3.[Algorithm]：9:Insertion-Component
4.[CheckDirectionEnable]：ON
Fixed
3.43 1.000 Bug Mounter Feeder
Whenitfailedinthesettingofpartsfeedtimerbyafeederfailureorcontactfailure,
therewasabugthat"Ea0:NOERRORMESSAGEREGISTRATION"wronglyoccurred,so
thattheoperatorcouldn'tfindthecause.
*Originally,itdisplays"Ea30141:Updatefailureoffeedertimer".
Fixed
3.43 1.000 Bug Mounter
Mark
Recognition
Onamachineequippedwithtwin-fiducialcamera,therewasacasethat"Es305:Soft
LimitOver"occurredatmarkrecognitionalthoughthecamerawasactuallyattheright
position.
Fixed
3.43 1.000 Bug Mounter Monitor
Onasingle-tablemachineor__YSH20__,whentheerroroccurredatrearsideofmachine
closedby[Close]button,therewasabugthattheerrorhasnotbeendisplayedat[Work
Instruction]areaof[Monitor]-[Production]screen.
Fixed
3.43 1.000 Bug Mounter
PickPosition
Correction
Underthefollowingconditions,therewasacasethatpickupwasperformedatawrong
position,andapickuperrororovercurrentoccuured.
1.Set[Parts]-[Options]-[PickupPositionOffset]to"Use"
2.Set[Machine]-[PickPositionSpecification]tootherthan"NotUse"
Fixed
MDOCV30-00001 10/14
