00196086-01_IM_Siplace_Pro_5.2_EN.pdf - 第19页
Installation manual SIPLACE Pro 4 Installati on of SIPLACE Pro and possible Setup Types Edition 07/2008 US 17 The "Choose Destinat ion Location" dialog box prompts you to enter the name of the fo lder in which …
4 Installation of SIPLACE Pro and possible Setup Types Installation manual SIPLACE Pro
Edition 07/2008 US
16
Step 4
4
Fig. 4 - 4 "Customer Information" dialog box
Æ Enter your User Name and Company Name in the "Customer Information" dialog box.
Æ Both boxes must be filled in before the installation process can be continued.
Æ Click Next.
Step 5
4
Fig. 4 - 5 "Choose Destination Location" dialog box
Installation manual SIPLACE Pro 4 Installation of SIPLACE Pro and possible Setup Types
Edition 07/2008 US
17
The "Choose Destination Location" dialog box prompts you to enter the name of the folder in
which SIPLACE Pro should be installed. The system suggests a default destination folder for you.
However, you can click the Browse button to open a dialog box in which you can enter or select
the path you want to use. If the folder you specify does not exist, it is created after having accepted
a confirmation dialog. 4
Æ Click Next.
Step 6
The Setup Type dialog box displays the SIPLACE Pro components you can choose for installa-
tion. 4
4
Fig. 4 - 6 "Setup Type" dialog box
In the "Setup Type" dialog box, 4
Æ Select the setup type you want to install.
Æ Click Next.
A short description of the setup type in question appears in the Description box when you select
a type. 4
Note
After choosing a setup type which includes a database installation, the setup program immediately
checks if SQL server or MSDE (Microsoft Data Desktop Engine) and the proper Service Pack are
installed on the computer. 4
4 Installation of SIPLACE Pro and possible Setup Types Installation manual SIPLACE Pro
Edition 07/2008 US
18
Note
If a database already exists. Setup performs an Integrity Check. If the Integrity Check fails, you
might need to cancel Setup. More information in Chapter 6. 4
