1 Introduction Installation Manual Edition 01/2011 SIPLACE Pro 9.2 5 Note: Further instructions on installin g operating systems, databases, networks and on backing up data can be found in the ".\SIPLACE NET\NA VIGA…
Installation Manual 1 Introduction
SIPLACE Pro 9.2 Edition 01/2011
4
1.2 Scope of Delivery
The Basic Software Package SIPLACE Pro 9.x (Item No. 00116512-xx) includes:
– 1 SIPLACE Pro Factory License (without the connection to SIPLACE stations)
– Media Package 9.x
The Media Package 9.x (Item No. 00116511-xx) consists of the following data storage media:
– 1 CD-ROM "SIPLACE Pro 9.2
– 1 CD-ROM with OIS application version 9.1 (Item No. 0038867-xx)
– Support Media version 1.11, which contains 1x DVD 1 and 1x DVD 2
The Upgrade Software Package SIPLACE Pro 9.x (Item No. 00116513-01) consists:
– 1 Upgrade License (without the connection to SIPLACE stations). To install the upgrade suc-
cessfully, a valid license of the previous version 8.x is mandatory.
Note:
On the first Support Media DVD you will find the programs necessary for installing SIPLACE Pro,
such as ErrorReporting, License Manager. 1
Basic Documents 1
– Software Version Description SIPLACE Pro 9.2 (German/English: Item-no. 00196803-01)
– Getting Started with SIPLACE Pro 9.2 (German: Item-no. 00196802-01, English: Item-no.
00196801-01)
– This Installation Manual of SIPLACE Pro 9.2 (in English only: Item-no. 00196804-01)
– User Manual "Random Setup" (German/English: Item-no.00196838-01)
– User Manual "Alternative Components" (German/English: Item-no. 00196839-01)
Detailed Installation Manuals 1
– Guideline for XML Import / Export (in English only: Item-no. 00193789-xx)
– Standard Component Shape Library Handling (in English only: Item-no. 00194625-xx)
– Recipe Analyzer API Manual (in English only: Item-no. 00196138-xx)
– Software Version Description SIPLACE CAD V4.1 SP2 (in English only: Item-no.
00194678-xx)
1 Introduction Installation Manual
Edition 01/2011 SIPLACE Pro 9.2
5
Note:
Further instructions on installing operating systems, databases, networks and on backing up data
can be found in the ".\SIPLACE NET\NAVIGATION GUIDE" directory on the Support Media DVD
no.1. 1
1.3 System requirements
Notes:
– SIPLACE Pro requires an NTFS partition to be installed on. FAT or FAT32 file systems
are not supported.
– SIPLACE Pro 9.2 requires the license manager 2.2 SP1 for its operation.
– SIPLACE Pro 9.2 requires new licenses for its operation.
– The Microsoft .NET Framework 3.5 SP1 is required.
– With the installation of SIPLACE Pro it is not possible to use operating systems or data-
base versions that are no longer supported:
Windows 2000 Server/ Windows 2000 Professional and former versions,
Microsoft SQL Server 2000 SP4/ MSDE SP4 and former versions.
– A mixed operation of different SQL server versions (2005 / 2008) is not supported.
– SQL Server 64 Bit versions are only supported on Windows 64 Bit operating systems.
– The Support Media DVD included in the installation package checks the necessary sys-
tem requirements of your system and installs these. Amongst others e.g. Microsoft .NET
Framework, the License Manager and the Error Reporting tool.
– It is recommended to use the Support Media V1.11.
Installation Manual 1 Introduction
SIPLACE Pro 9.2 Edition 01/2011
6
1.3.1 Computer
1
Server / Database Computer System
Software (required) Hardware (recommended)
– Preferred:
Windows Server 2008 R2 (64 Bit)
– Compatible:
Windows Server 2003 SP2 (32 and 64 Bit) 1
Windows Server 2003 R2 (32 and 64 Bit) 1
Windows Server 2008 SP2 (32 and 64 Bit) 1
– Preferred:
Microsoft SQL Server 2008 R2 /
Express Edition R2 (64 Bit)
– Compatible:
Microsoft SQL Server 2005 SP3/
Express Edition SP3 (32 and 64 Bit) 1
Microsoft SQL Server 2008 SP1 /
Express Edition SP1 (32 and 64 Bit) 1
Microsoft SQL Server 2008 R2 /
Express Edition R2 (32 Bit) 1
– Microsoft .NET Framework 3.5 SP1
– e.g. 2x Intel E5520 2.26 GHz 8MB
– 4096 MB RAM (2048 MB at least), depending
on the complexity of the data content.
– HDD SATA II 500GB
– Optional Backup drive (e.g. DAT, DVD)
– 21" monitor (19" monitor at least)
– Optional: Uninterruptible power supply
