1 Introduction Installation Manual
Edition 01/2011 SIPLACE Pro 9.2
5
Note:
Further instructions on installing operating systems, databases, networks and on backing up data
can be found in the ".\SIPLACE NET\NAVIGATION GUIDE" directory on the Support Media DVD
no.1. 1
1.3 System requirements
Notes:
– SIPLACE Pro requires an NTFS partition to be installed on. FAT or FAT32 file systems
are not supported.
– SIPLACE Pro 9.2 requires the license manager 2.2 SP1 for its operation.
– SIPLACE Pro 9.2 requires new licenses for its operation.
– The Microsoft .NET Framework 3.5 SP1 is required.
– With the installation of SIPLACE Pro it is not possible to use operating systems or data-
base versions that are no longer supported:
Windows 2000 Server/ Windows 2000 Professional and former versions,
Microsoft SQL Server 2000 SP4/ MSDE SP4 and former versions.
– A mixed operation of different SQL server versions (2005 / 2008) is not supported.
– SQL Server 64 Bit versions are only supported on Windows 64 Bit operating systems.
– The Support Media DVD included in the installation package checks the necessary sys-
tem requirements of your system and installs these. Amongst others e.g. Microsoft .NET
Framework, the License Manager and the Error Reporting tool.
– It is recommended to use the Support Media V1.11.
Installation Manual 1 Introduction
SIPLACE Pro 9.2 Edition 01/2011
6
1.3.1 Computer
1
Server / Database Computer System
Software (required) Hardware (recommended)
– Preferred:
Windows Server 2008 R2 (64 Bit)
– Compatible:
Windows Server 2003 SP2 (32 and 64 Bit) 1
Windows Server 2003 R2 (32 and 64 Bit) 1
Windows Server 2008 SP2 (32 and 64 Bit) 1
– Preferred:
Microsoft SQL Server 2008 R2 /
Express Edition R2 (64 Bit)
– Compatible:
Microsoft SQL Server 2005 SP3/
Express Edition SP3 (32 and 64 Bit) 1
Microsoft SQL Server 2008 SP1 /
Express Edition SP1 (32 and 64 Bit) 1
Microsoft SQL Server 2008 R2 /
Express Edition R2 (32 Bit) 1
– Microsoft .NET Framework 3.5 SP1
– e.g. 2x Intel E5520 2.26 GHz 8MB
– 4096 MB RAM (2048 MB at least), depending
on the complexity of the data content.
– HDD SATA II 500GB
– Optional Backup drive (e.g. DAT, DVD)
– 21" monitor (19" monitor at least)
– Optional: Uninterruptible power supply
1 Introduction Installation Manual
Edition 01/2011 SIPLACE Pro 9.2
7
1
1.3.2 Resource Requirements
1
Client Computer System
Software (required) Hardware (recommended)
– Preferred:
Windows 7 (64 Bit)
– Compatible:
Windows XP SP3 (32 Bit) 1
Windows Vista SP2 (32 and 64 Bit) 1
Windows 7 (32 Bit) 1
– Microsoft .NET Framework 3.5 SP1
– e.g. 1x Core 2 Duo E8500
Note: The SiCluster Professional GUI e.
g. uses multi core processors during parallel
optimization.
– 4096 MB RAM (2048 MB at least),
depending on the complexity of the data
content.
– HDD SATA II 250GB
– 21" monitor (19" at least) with a screen
resolution of at least 1024 x 1280 pixel
(small fonts)
Hard disk Main Memory
– Windows and program files:
= ~4000 MB
– Database and Backup:
= ~Number of optimized recipes x 20 MB
– Windows:
= ~200 MB.
– SQL Server:
= typically 500 MB (RAM requirement
depends on the data volume)
– LineControl Server:
= ~100 MB
– For every client (Desk, LineControl GUI,
Optimizer Toolkit) each:
= ~100 MByte + number of recipes x
number of placement positions / 1000 MB
