AirJet
®
954 CRD 
TECHNICAL DATA SHEET
5
www.dct.cleaning
Power supply 400V, 32A, 50Hz (3+N+PE) UL 400V, 32A, 60Hz* (3+N+PE)
Pmax 9,5 kW 9.5 kW
Compressed air connection Pipe Ø 6 mm Pipe ID 0.24 in
Recommended working pressure 4,5 – 6 Bar 65.25 – 87 PSI
Compressed air quality 3. Class ** 3. Class **
Exhaust pipe diameter Ø 100 mm ID 3.94 in
Exhaust pipe capacity 380 m
3
/h 13 400 ft
3
/hod
Minimum liquid for  rst run 2 x 200 l 2 x 52.8 gal
Service space required around the device 600 mm 23.6 in
* When using frequency convertor
** According to the norm ISO 8573-1
INSTALLATION REQUIREMENTS
BACK
VIEW
BACK
VIEW
715 mm
28.1 in
discharge of the fluids G1
input el. power
input air pressure Ø 6 mm
input air pressure ID 0.24 in
2150 mm
84.6 in
2350 mm
92.5 in
735 mm
28.9 in
Ø 100 mm
ID 3.94 in
115 mm
4.53 in
metric units imperial units
AirJet
®
954 CRD 
TECHNICAL DATA SHEET
6
www.dct.cleaning
1 process chamber – fully automatted solution
100% closed loop uid system
Cleaning and rinsing uid heating
Pneumatic door lock
Mechanical ltration
3 hot air blowers – drying
Emergency stop button
Manipulation wheels – lockable
PLC controller + 8,4“ touchscreen display
Spare parts (base kit)
STANDARD HARDWARE EQUIPMENT
3 levels of logging – operator, maintenance, technician
Standard software language mutation – CZ, ENG
Liquid and lter replacement notication – cycle counting
Possibility of 5 programs – setting option
STANDARD SOFTWARE EQUIPMENT
AirJet
®
954 CRD 
TECHNICAL DATA SHEET
7
www.dct.cleaning
Adjustable timer of cleaning uid heating
Language mutation (CZE, ENG, GER, POL, CHI, RUS, ITA, SPA, MAY, HUN)
ONLINE access to cleaning device
Upgrade machine for PROTON
OPTIONAL SOFTWARE EQUIPMENT
Common uids draining – manual control
Automatic uids relling (without pump)
Automatic uids discharging (without pump)
Filtration sandwich – external
Tanker 200 and 400 lit for operating uids
Bubbling grate for tanker 200 and 400 l
Conductivity measurement – rinse 0-2000 µS – blocking optional
Other optional equipment - the complete list of optional accessories will provide you DCT or the local distributor.
OPTIONAL HARDWARE EQUIPMENT
Mechanical basket – folding handle
Mechanical holder for basket
Mechanical basket
OPTIONAL ACCESSORY – FRAMES AND OTHERS
