193-5100 CUKYX 1.4 后侧 3-15 1.4.4 DC 电源单元 Symbol Name Remarks G1 24V Power Unit for Control G2 48V Power Unit for Motor and LED Lighting G3 24V Power Unit for Feeder (48D) G2 CN1 (24G) G3 (24A) G1 13 3-15A
193-5100
CUKYX
1.4 后侧
3-14
1.4.3 XY 马达放大器单元 ( 后侧 )
Symbol Name Remarks
A21B X1 (Rear) Axis Servo Motor Amplier
A22B Y1 (Rear) Axis Linear Motor Amplier
A23B Y2 (Rear) Axis Linear Motor Amplier
X-Axis Y2-AxisY1-Axis
A21B A22B A23B
10
3-14A
193-5100
CUKYX
1.4 后侧
3-15
1.4.4 DC 电源单元
Symbol Name Remarks
G1 24V Power Unit for Control
G2
48V Power Unit for Motor and LED Lighting
G3 24V Power Unit for Feeder
(48D)
G2
CN1
(24G)
G3
(24A)
G1
13
3-15A
193-5100
CUKYX
1.4 后侧
3-16
1.4.5 真空泵
Symbol Name Remarks
M66 Vacuum pump Motor
M66
14
3-16A
