6 Technical Training E by DEK 12/2017 Inhaltsverzeichnis
5Technical Training E by DEK 12/2017
Inhaltsverzeichnis
10.1.2.2 C_Chase Electrical Overview.. 87
10.1.3 Adjustable Width Screen Mount (AWSM) Module.. 88
10.1.3.1 AWSM Functionality.. 89
10.1.3.2 Adjustable Width Screen Mount (AWSM) Module - Exercise.. 90
10.1.3.3 Adjustable Width Screen Mount (AWSM) - Electrical and Pneumatic Overview.. 90
10.1.4 Screen Alignment.. 92
10.1.4.1 Screen Alignment Functionality.. 93
10.1.4.2 Screen Alignment Analyses.. 94
10.1.4.3 Screen Alignment Module - Electrical Overview.. 94
10.1.4.4 Screen Alignment Module - Exercise.. 95
10.1.5 Parts Exchange / Settings / Calibrations.. 95
10.1.6 Analysis Common error list.. 95
10.1.7 Maintenance.. 95
10.2 Under Screen Cleaner.. 96
10.2.1 Interchangeable Under Screen Cleaner.. 96
10.2.1.1 Interchangeable Under Screen Cleaner Functionality.. 97
10.2.1.2 Overview Interchangeable Under Screen Cleaner Electrical System.. 98
10.2.2 Parts exchange / Settings / Calibration.. 98
10.2.3 Analysis Common error list.. 99
10.2.4 Maintenance.. 99
11 Benchmark Test.. 103
12 The Perfect Print.. 109
12.1 The Perfect Print.. 109
12.2 Exercise.. 109
6 Technical Training E by DEK 12/2017
Inhaltsverzeichnis
1 Machine Safety
1.1 GENERAL
Technical Training E by DEK 12/2017 7
1 Machine Safety
1.1 GENERAL
CAUTION
Any staff working on the machine must be familiar with the safety instructions in the
technical reference manual and observe these at all times. The following safety instructions
are only an excerpt from the chapter "Operational Safety" in the machine technical
reference manual. For further detailed safety information please refer to the manuals that
was supplied with your machine.
1.2 HAZARDOUS MATERIALS
Hazardous materials, as defined by NFPA 497 (National Fire Protection Association), are not
recommended by ASM for use on this machine. If one or more hazardous materials are used,
decontamination must be carried out in accordance with SEMI S12 or equivalent local regulations.
1.3 Warnings, Prohibitions, and Cautions
The warning, prohibition and caution notices below are fitted to the machine and shown in the
relevant procedures within this manual.
NOTICE
Some of the warning symbols below may not be applicable to your machine.
Symbol Definition
PROHIBITION
MACHINE COVERS. IN ORDER TO PROTECT PERSONNEL AND TO PREVENT
DAMAGE TO THE MACHINE, COVERS ARE FITTED TO THE MACHINE FRAME.
THESE PANELS MUST ONLY BE REMOVED BY SUITABLY QUALIFIED
PERSONNEL.
WARNING
MOVING PARTS. MOVING PARTS ARE PRESENT IN THE VICINITY OF THIS
WARNING LABEL, THESE PARTS HAVE THE POTENTIAL TO CAUSE INJURY.
WARNING
BOARD CLAMPS. EXTREME CARE MUST BE EXERCISED WHEN WORKING IN
THE TOOLING AREA OF THE MACHINE TO AVOID INJURY. THE FOILS ON THE
FRONT AND REAR BOARD CLAMPS ARE VERY SHARP.
WARNING
SOLVENT SPRAY. THE UNDERSTENCIL CLEANER SPRAYS A FINE JET OF
SOLVENT SOLUTION ON TO THE CLEANER. APPROVED PROTECTIVE
CLOTHING SHOULD BE WORN.
CAUTION
RECOMMENDED SOLVENTS. ANY SOLVENTS USED MUST COMPLY WITH
LOCAL ENVIRONMENTAL GUIDELINES. ASM RECOMMEND USING SOLVENTS
THAT ARE ENVIRONMENTALLY FRIENDLY, IE CFC FREE AND WATER BASED.
SOLVENTS USED MUST HAVE FAST EVAPORATION RATES AND FLASHPOINT
SPECIFICATIONS GREATER THAN 39°C.
CAUTION
SOLVENT SOLUTION. DO NOT MIX SOLVENT SOLUTIONS. FLUSH THE SOLVENT
TANK THOROUGHLY WHEN CHANGING TO A DIFFERENT SOLVENT SOLUTION.
