Page
+$1:+$
43
Cart Clamp AF /BR
EXCEN PRO(M)
EXCEN PRO(D)
EXCEN PRO(L)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
A AM03-008028A ASSY,FEEDER BASE-CART_CLAMP_1F-2R_ASSY 1
1 FC15-001438B COVER-V1P15-FEEDER_COVER_B 1
2 EP02-001637B HARNESS-CART LOCK RELEASE SENSOR CABLE 2
3 FC09-002112B BRACKET-SENSOR_BKT_L 1 FC09-002112A
4 J70621029A NUT_PLT_A J70621029A 4
5 FC09-002513B BRACKET-V1P15-FEEDER_COVER_BKT_L_B 1
6 FC18-901969 SOCKET_HEAD_SET_SCREW 2
7 FC07-001558A BLOCK-MTV1PP-FB019A-GUIDE_PLT_H 1 FC07-000584A/ FC09-001214A
8 J72651385A GUIDE_PLT_B_R 1
9 FC29-007039B GUIDE-PRO-CC_GUIDE_COMB_A_B 1 FC09-001087A/ FC09-003679A/ FC09-
004328A/ FC29-007039A
10 EP02-001635B HARNESS-CART CLAMP SENSOR CABLE ASSY 1
11 FC18-000062A SPACER-V1_CC_SPACER_A 10
12 J71631003A GUIDE_PLT_A_R J71631003A 1
13 J71631004A GUIDE_PLT_B_L J71631004A 1
14 FC29-007040A GUIDE_BKT_H 1 FC09-001088B/ FC09-000572A
15 FC09-002113B BRACKET-SENSOR_BKT_R 1 FC09-002113A
16 FC09-002512B BRACKET-V1P15-FEEDER_COVER_BKT_R_B 1
17 FC09-001799A BRACKET-V_CARTCLAMP_CYL_COVER_D 1
18 FC28-000033A POST UNIT,TOOL-V1_CC_POST_AA;ME1:Steel 5
19 J70621036A X_GUIDE_A J70621036A 1
20 FC09-004281A CN_BKT 1 J70621030A
21 J70621035A STOPPER J70621035A 2
22 FC18-903189 TIE_MOUNT 4
23 J70621015A STOPPER_BLK_L J70621015A 1
24 FC09-001795B BRACKET-V1-CARTCLAMP_BASE_PLT_D 1
25 FC09-001798B BRACKET-PRO_CC_CYL_COVER_C 1 FC09-001798A
26 J70621016A STOPPER_BLK_R J70621016A 1
27 FC09-004282A CN_BKT_B 1 J70621039A
28 HP06-900018 FITTING [KQ2U06-00/PY6M] 2 HP06-900152
29 FC09-001794B V_CARTCLAMP_BASE_PLT_C 1
Page
+$1:+$
44
Cart Clamp AF /BR
EXCEN PRO(M)
EXCEN PRO(D)
EXCEN PRO(L)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
30 MC03-000056 BEARING,NEEDLE 2
31 FC29-006667A BRACKET-V_CC_CAM_FOLLOW_HOLDER 2 FC09-001800A
32 EP02-001990A HARNESS-FDR UNLOCK 2 SNS CABLE ASSY 2
33 FC18-000081 NUT-NUT;M12 1,ME1:Steel 2
34 J70621031A CAM_B_L J70621031A 1
35 FC29-000145A COLLAR-V1_CC_COLLAR_B;ME1:Steel 1
36 MC03-900116 BEARING 6000ZZNR 4
37 J70621013A LEVER_L J70621013A 1
38 FC18-003393A CC_HOOK_P_R 1 FC18-000344A
39 J70621017A BLOCK J70621017A 2
40 FC29-000146A COLLAR-V1_CC_COLLAR_C;ME1:Steel 2
41 FC14-000122 END,STUB-ROD END 2
42 HP06-900076 ELBOW_FITTING KQ2L06-01S 4 HP14-900109
43 HP03-000124 CYLINDER-CQ2D40-75DZ;AIR,1MPA,75MM,40MM 1 HP03-000011/ HP03-000124/ HP03-001001
44 FC18-901667 C-RING(SHAFT) 4
45 FC18-902792 SOCKET HEAD CAP SCREW [M8*35 (BL/ZN)] 2
46 FC09-001801A BRACKET-V_CARTCLAMP-CYL_FI_BLOCK_1 1
47 J70621034A CAM_B_R J70621034A 1
48 J70621014A LEVER_R J70621014A 1
49 FC18-003394A CC_HOOK_P_L 1 FC18-000352A
50 HP03-000125 CYLINDER-CDQ2D40-75DZ;AIR,1MPA,75MM,40MM 1 HP03-000012 /HP03-000025/ HP03-001002
51 FC09-001802A BRACKET-V_CARTCLAMP-CYL_FI_BLOCK_2 1
52 FC18-901194 DOWEL PIN[MS4-10] 4
53 FC18-901194 DOWEL PIN[MS4-10] 2
54 J70621029A NUT_PLT_A J70621029A 2
55 FC18-000063A PIN-V1_CC_PIN_A;ME5:Stainless steel 2
56 FC09-004326B BRACKET-MTV1PP-FB016A-CC_SENSOR_BKT;TYPE 1
57 PT03-000252A STICKER-STICKER-FEEDER_NUMBER_DC;BONDING 1
HP13-000016 TUBE-TUBE;TU0604Y 2
HP13-900079 TUBE [TU0604B] 2
