PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
Chapter Issue 6 Oct 06 Technical Reference Manual 33.51
Figure 33-5 Camera System (Rotary)
Y Axis Linear Bearings
X Axis Linear Bearing
PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
33.52 Technical Reference Manual Chapter Issue 6 Oct 06
Figure 33-6 Camera System (Linear)
Camera Y Linear Bearing Guide (left)
Camera Y Linear Bearing Guide (right)
Camera Y Encoder Strip
Camera X Encoder Strip
Camera X Linear Bearing Guide
View on Underside of Camera Mechanism
Camera
Camera Y Magnet Track
Camera X Magnet Track
PREVENTIVE MAINTENANCE
CLEANING, LUBRICATION AND MAINTENANCE DIAGRAMS
Chapter Issue 6 Oct 06 Technical Reference Manual 33.53
Figure 33-7 Chase Omni Track Bearings
View on Arrow A
Machine Front
Omni Track Bearings
(in 4 Positions)
Plan View on Machine
A
Omni Bearing Track Plate
Chase Clamp
Chase
