GEM Manual for DEK Printers Equipment Variables
Issue 1.1 March 20th, 2014 Page 121 of 152 Page 121 of 152
PRESSURE H/W
112
CLEANER PAPER ADVANCE
173
CLEANER MODEL
174
ON THE FLY
177
SCREEN TYPE
189
FIDUCIAL FINDER
192
SELECTIVE PRINT/PASS
269
MAINT. MONITORING
272
PRODUCT DIRECTORY:
279
DATA DIRECTORY :
281
AUTO FIDUCIAL SET UP
282
TOOLING MONITORING
285
2DI MOVEMENT TUNING
325
ROLL HEIGHT H/W
338
ROLL HEIGHT MONITOR
339
CAMERA IDLE POSITION
385
UNLOAD BOARD START
386
HIGH THROUGHPUT CNVR
389
AUTO RAIL WIDTH
425
ADVANCED PROFLOW
427
DOWN-LINE BOARD STOP
443
PAPER ROLL LENGTH
444
VACUUM TOOL SENSOR
450
PROFLOW SENSOR TYPE
526
CAMERA X GAIN
573
CAMERA Y GAIN
574
CAMERA X DGAIN
575
CAMERA Y DGAIN
576
CAMERA X KVEL
577
CAMERA Y KVEL
578
CAMERA X KF
579
CAMERA Y KF
580
CAMERA X KI
581
CAMERA Y KI
582
CAMERA X KR
583
CAMERA Y KR
584
CAMERA X RAMP
585
CAMERA Y RAMP
586
CAMERA X SCALE
587
CAMERA Y SCALE
588
CAMERA X IDLE
589
CAMERA Y IDLE
590
CAMERA X MAX FE
591
CAMERA Y MAX FE
592
CLEANER CAMERA Y KR
635
DEPOSIT VERIFICATION
737
BALL ESCAPE DETECT
754
ESCAPE SENSOR TYPE
759
PLATE LIFT SENSOR
839
RAIL WIDTH OFFSET
859
ADVANCE AT INITIAL
869
REMOTE PRODUCT PATH
880
REMOTE DATA PATH
881
PROGRAMMABLE BEACON
903
VAC OFF AT SEPARATE
931
GEM Manual for DEK Printers Equipment Variables
Issue 1.1 March 20th, 2014 Page 122 of 152 Page 122 of 152
ALT SWEEP START
933
RUN WITH GEM REMOTE
993
PASS THROUGH REF POS
994
HAWKEYE DATA LOGGING
999
DUAL LANE MODE
1030
REF RAIL POS
1031
DUAL SPEED BELTS
1041
FRONT L 2 R SPEED
1042
FRONT R 2 L SPEED
1043
REAR L 2 R SPEED
1044
REAR R 2 L SPEED
1045
FRONT L 2 R ALT SPEED
1046
FRONT R 2 L ALT SPEED
1047
REAR L 2 R ALT SPEED
1048
REAR R 2 L ALT SPEED
1049
VAC CHECK AFTER SEP
1064
SELECTIVE FID SWEEP
1065
PASS THR BOARD WIDTH
1071
STINGER OFFSET X
1098
STINGER OFFSET Y
1099
STINGER HARDWARE
1100
PASS THR WIDTH CALIB
1105
GERBER DIRECTORY
1114
LASER CORRECTION
1147
SMA LEVEL MON
1150
VERIFICATION
1166
TRACEABILITY
1167
TRACEABILITY DRIVE
1168
TRACEABILITY NETWORK
OUTPUT
1179
USC VAC SENSE
1180
STINGER LASER OFFSET X
1188
STINGER LASER OFFSET Y
1189
LEVEL SETTING HEIGHT
1253
SETTING PLATE DEPTH
1254
LAST COPLANARITY HEIGHT
1255
E.E.LOGGING
1264
EVENT LOG HISTORY LIMIT
1287
UPDATE NETFILES
1291
BARCODEDUPLICATEHANDLING
1296
TRANSPORT MODE
5000
MACHINE UNITS
5001
UPLINE PROTOCOL
5010
DOWNLINE PROTOCOL
5011
TRANSPORT WAIT MODE
5013
COMMS PROTOCOL
5020
EVENT RECORDING
5030
EVENT RECORDING
5035
TRANSFER PERIOD
5040
TOOLING HARDWARE
5050
CLAMP TYPE
5051
SNUGGER THICKNESS
5052
PRODUCT BARCODE H/W
5060
REMOTE BARCODE H/W
5065
NON VISION
5070
GEM Manual for DEK Printers Equipment Variables
Issue 1.1 March 20th, 2014 Page 123 of 152 Page 123 of 152
VISION OFFSET
5080
SCREEN SIZE
5090
SCREEN BARCODE H/W
5100
CHANGE MODE OPTION
5110
FIDUCIAL REFERENCE
5120
BAUD RATE
5133
PARITY
5134
WORD LENGTH :
5135
STOP BITS
5136
START CHARACTER
5140
NAME LENGTH
5150
START CHARACTER
5160
START CHARACTER
5165
NAME LENGTH
5170
NAME LENGTH
5175
BAUD RATE
5180
WORD LENGTH
5181
PARITY
5182
STOP BITS
5183
USER ID
5191
AUTO LOGIN
5194
LOCAL COPIES
5195
RECONNECT PERIOD
5196
TIMEOUT
5197
CLEANER HARDWARE
5201
PASTE DISPENSER
5202
PFLOW CONTACT POS.
5232
PFLOW DSTOP POS.
5233
DISPLAY TYPE
5300
FIDUCIAL MONITORING
5400
SCORE WARNING LEVEL
5401
VAR'N WARNING LEVEL
5402
AUTOMATIC RETRY
5403
BOARD STOP X OFFSET
6460
REMOTE BOARD STOP
6461
FIDUCIAL SEARCH
6465
AUTOSEARCH
6466
WINDOW SIZE
6467
CLEANER TYPE
6470
SPOOL BEFORE 1ST WET
6475
SOLVENT DISPENSE DURATION
6480
WET OVER BLADE
6490
DRY AFTER ONE WET
6500
DRY AFTER TWO WET
6510
WET AFTER WET
6520
DRY AFTER DRY
6530
CONSUMABLE ACTION
6535
KNEAD AFTER DISPENSE
6560
PASTE TRAILS
6570
DWELL HEIGHT
6581
DWELL SPEED
6582
IMAGE RECORDING
12069
VIDEO GAIN
13015
VIDEO OFFSET
13016
SCREEN LENGTH
14001
