SM320 Technical Reference_CS_Ver #1 [in P.N.S].pdf - 第76页
Part Photo C onveyor Ass’y 77 Page SAMSUNG TECHWIN J 9 0 8 0 7 7 5 C CO NV P CB S EN SO R CA B L E [ S M - C V 0 0 7 ] J 7 0 5 3 1 9 6 C PC B GU ID E R. C J 1 3 0 0 5 3 2 G EA R HE AD J 7 1 5 3 3 2 9 A CY L BR AC KE T- R…
Part List
C
onveyor-Moving Frame Ass'y
76 Page
SAMSUNG TECHWIN
NO.NO. LEVELLEVEL PART NO.PART NO. PART NAMEPART NAME Q'TYQ'TY TYPETYPE Old No.Old No. StockStock ReferenceReference
J2101814
J2101819
J2101817
J6602027A
J6602026A
J2101821
J7153010B
J2102048
J1300463
J2101820
J1301675
J7053709A
IDLER 1
IDLER SHAFT-M
IDLER SPACER-M
FLAT BELT(EXT)
FLAT BELT(MID)
CLAMP SHAFT
ADJUST SHAFT
STOPPER
C-RING
BUSH SPACER
BALL BUSH
SENSOR BKT S2
4
3
3
2
1
2
2
2
2
2
4
2
0135-641101
0135-641106
0135-641104
HNB-5E, 1196L, 7W
HNB-5E, 1536L, 7W
0135-641111
J7153010B
0135-641129
10MM (HOLE)
0135-641110
LM 5(M)
J7053709A
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
Part Photo
C
onveyor Ass’y
77 Page
SAMSUNG TECHWIN
J9080775C CONV PCB SENSOR CABLE [SM-CV007]
J7053196C PCB GUIDE R.C
J1300532 GEAR HEAD
J7153329A CYL BRACKET-R
J6609015B PULLEY-MOTOR
J7053736A BRACKET SENSOR PLACE
Part Photo
C
onveyor Ass’y
78 Page
SAMSUNG TECHWIN
J7053686A STOPPER [460*400]
J7153393A CONNECTION PLATE 2
J7053748A STOPPER-FRONT [510*460]
J7153392A CONNECTION PLATE 1
J6703007A THROTTLE VALVE(ELBOW)
J7053736A BRACKET SENSOR PLACE
