Chapter Issue 4 May 03 Technical Reference Manual 3.1
CHAPTER 3 MACHINE OVERVIEW
INTRODUCTION This chapter describes the function and the purpose of each of the machine
modules and the relationship and interaction between modules, if applicable.
For detailed information regarding each module refer to the relevant module
chapter in this manual.
0
$&+,1(29(59,(:
0
$&+,1(29(59,(:6
3.2 Technical Reference Manual Chapter Issue 4 May 03
MACHINE OVERVIEWS
Figure 3-1 View on Front of Machine with Printhead Covers
Item Description
1 Touchscreen Monitor
2 Two Button Control
3Mouse
4 Keyboard
5 Emergency Stop Buttons (E Stop)
6 Mains Isolator Switch
7System Button
8 Paste Roll Lamp Button
9 Tricoloured Beacon
0$&+,1(29(59,(:
0$&+,1(29(59,(:6
Chapter Issue 4 May 03 Technical Reference Manual 3.3
Figure 3-2 View on Front of Machine with Printhead Shutter
Item Description
1 Tricoloured Beacon
2 System Button - Front
3 Emergency Stop Buttons (E Stop) - Front
4 Two Button Control
5 Mains Isolator Switch
6 Paste Roll Lamp Button
7IR Receiver
8 LCD Monitor
9 Emergency Stop Button (E Stop) - Front
10 System Button - Rear
11 IR Keyboard/Mouse
