MEMO
Key No. PART No. PART NAME Q’ty
REMARKS
NOTE
6 0914B108 PLATE 1 1091301600-006
25 09141C08 NAME PLATE 1
1091301600-025
26 09141C09 NAME PLATE 1
1091301600-026
27 09141C0A NAME PLATE 1
1091301600-027
28 09141C0B NAME PLATE 1
1091301600-028
29 09141C0C NAME PLATE 1
1091301600-029
30 221AA028 ROHS:BOLT_HEX-SCT 2
1091301600-030
31 221AA028 ROHS_HEX-SCT 35
1091301600-031
33 221AA032 ROHS_HEX-SCT 51
1091301600-033
34 221HA303 ROHS_WASHER 45
1091301600-034
46 211E1210 SPACER 2
1091301600-046
50 221AA030 ROHS_HEX-SCT 10
1091301600-050
51 221HA205 WASHER 10
1091301600-051
52 221AA022 ROHS_HEX-SCT 4
1091301600-052
53 221HA040 SW04W 4
1091301600-053
54 221HA104 WASHER 4
1091301600-054
55 0914B1A6 INSULATOR_GUM 4
1091301600-055
60 221AA056 ROHS_HEX-SCT 4
1091301600-060
61 221HA007 WASHER 4
1091301600-061
62 221HA107 WASHER 4
1091301600-062
Fig. D1-1
Fig. D1
UNIT-3
Fig. D1
ELEC1
SIGMA-G4DA
SIGMA-G4DB
SIGMA-G4DC
MEMO
Fig. D1-2
ブレーカ、ノイズフィルタ
Breaker, Noise Filter
0912-002
108
101
103
110
105
109
106
107
104
112
113
115
116
117
114
111
118
119
120
123
124
125
121
122
Fig. D1
電装部１
ELECTRICAL SECTION 1
UNIT-3
Fig. D1
ELEC1
