Installation Manual, Station Software Version 601.03 SP2 Edition 11/2006
Embedded software
Machine type
Subsystem BIOS / application Version File name
X2 X3 X4
BIOS 02.00 A0300200.bhx
Application 1 02.08 A0310208.bhx
Application 2 / X 02.45 X0320245.bhx
Main axes
(A363)
Application 2 / Y 02.45 Y0320245.bhx
X X X
BIOS 02.00 A0300200.bhx
Application 1 02.08 A0310208.bhx
Application 2 / star 02.45 S0320245.bhx
Application 2 / Z 02.45 Z0320245.bhx
Revolver head axes
(A363)
Application 2 / DP 02.45 D0320245.bhx
X X X
BIOS 02.00 A0300200.bhx
Application 1 02.08 A0310208.bhx
Application 2 / Z 02.45
P0320245.bhx
Twin Head axes
(A363)
Application 2 / DP 02.45 R0320245.bhx
X X
BIOS 02.00 A0300200.bhx
Application 1 02.08 A0310208.bhx
Application 2 / star 02.45 C0320245.bhx
Application 2 / Z 02.45 W0320245.bhx
BIOS / DP
01.04
J0300104.hex
J0400104.hex
C&P20 head axes
(A363)
Application 1 / DP
01.18
J0310118.hex
J0410118.hex
X X X
BIOS 03.3F A040033F.bhx
Application 1 01.08 A0410108.bhx
Application 2 / X 04.56 A0420456.bhx
Main axes
(A364)
Application 2 / Y 04.56 A0420456.bhx
X X X
BIOS 03.3F A040033F.bhx
Application 1 01.08 A0410108.bhx
Application 2 / star 04.56 A0420456.bhx
Application 2 / Z 04.56 A0420456.bhx
Revolver head axes
(A364)
Application 2 / DP 04.56 A0420456.bhx
X X X
9 of 90
Installation Manual, Station Software Version 601.03 SP2 Edition 11/2006
Machine type
Subsystem BIOS / application Version File name
X2 X3 X4
BIOS 03.3F A040033F.bhx
Application 1 01.08 A0410108.bhx
Application 2 / Z 04.5E P042045E.bhx
Twin Head axes
(A364)
Application 2 / DP 04.56 A0420456.bhx
X X
BIOS 03.3F A040033F.bhx
Application 1 01.08 A0410108.bhx
Application 2 / star 04.56 A0420456.bhx
Application 2 / Z 04.56 A0420456.bhx
BIOS / DP
01.04
J0300104.hex
J0400104.hex
C&P20 head axes
(A364)
Application 1 / DP
01.18
J0310118.hex
J0410118.hex
X X X
BIOS 1.04 K0400104.hex
RV head (modular)
Application 1
6.04
K0410604.hex
X X X
BIOS 3.CB K06003CB.hex
RV head (16 bit x serial)
Application 1
2.09
K0610209.hex
X X X
BIOS 03.CB I01003CB.bhx
Twin Head head functions
(2 Prozessor)
Application 1 02.07 I0110207.bhx
X X
BIOS 03.CB I03003CB.bhx
Twin Head head functions
(1 Prozessor)
Application 1 02.07 I0310207.bhx
X X
BIOS
03.CB H01003CB.bhx
C&P20 head
Application 1
01.3E H011013E.bhx
X X X
BIOS
01.01
B0200101.hex
Component table
(CAN, 1MB)
Application 1
01.07
B0210107.hex
X X X
BIOS
02.01
02.00
B0400201.bhx
B0500200.bhx
Component table (X series)
Application 1
04.0D B051040D.bhx
X X X
BIOS 01.00 G0200100.hex
Tape cutter (CAN 1MB)
Application 1 01.00 G0210100.hex
X X X
BIOS 03.04 T0600304.hex
PCB conveyor
Application 1 05.4C T061054C.hex
X X X
Main/Subdistributor
BIOS 03.24 E0100324.bhx X X X
10 of 90
Installation Manual, Station Software Version 601.03 SP2 Edition 11/2006
Machine type
Subsystem BIOS / application Version File name
X2 X3 X4
Application 1 03.53 E0110353.bhx
BIOS
03.CD
V05003CD.bhx
VISION modules
Application 1
03.02
V0510302.bhx
X X X
BIOS 02.00 M0200200.bhx
MTC 2
Application 1 02.05 M0210205.bhx
X X
BIOS
02.04
L0200204.hex
L0300204.hex
Digital pressure regulation
valve
Application 1
03.06
L0210306.hex
L0310306.hex
X X X
BIOS 01.01 UA100101.hex
X-Feeders
Application 1 01.36 UA110136.hex
X X X
