In case of a loosely fitting nozzle:
* Ref. Shape Size
(mm)
Size
(in)
* JN2020 Straight Ø 8 Ø 0.31
JN8417 Straight Ø 10 Ø 0.4
* JN2015 Bent Ø 4 Ø 0.16
* JN2012 Bent Ø 6 Ø 0.24
JN6633 Bent Ø 8 Ø 0.31
JN7637 Flat 10 x 2 0.39 x 0.08
JN7638 Flat 20 x 2 0.79 x 0.08
JN7639 Flat 30 x 2 1.18 x 0.08
Straight Bent Flat
Ø Ø A x B
1. Push the nozzle tab inwards with a screw-
driver or flat-nosed pliers.
2. Assemble the nozzle onto JTT again.
Nozzle Exchanger
Turn the tool off and handle with care. The heating element and the nozzle are still hot.
Compatible Nozzles
JTT works with JN nozzles. Find the model that
best suits your soldering needs at www.jbctools.
com
* Supplied with JTSE Station
Place the heating element with its nozzle in the
nozzle changer and pull the tool to remove it.
The nozzle comes to rest in the nozzle holder.
Attach the nozzle and press the nozzle onto the
heating element with the help of the opening
in the nozzle exchanger.
1. Removing Nozzle 2. Attaching Nozzle
TC
Suction
OK
17:14
20
ºC
Power
45%
120ºC Selected
TC
Temp.
4m 38s
400
ºC
80
%
400ºC Selected
Protection
Hot Air Temp. Air Flow Selec.
TC
Suction
OK
JTT
TET
JT
TE
Use only with a 250V fuse
Employer uniquement avec
un fusible de 250V
TC
Suction
OK
12
1
2
1
2
12
Note: Only perform this operation when the element is cold and the unit is disconnected from the
mains.
Loosen the screw (1) and pull the worn heating element out of the handle (2).
Insert the new heating element, make sure its pushed all the way in (2) and tighten the screw (1).
Replacing the Heating Element
JTT
Heater Hose Set
Ref. JT-T1A (100V / 120V)
JT-T2A (230V)
JTH
Heating Element for JTT
JTH1: Ref. 0014105 (100V and 120V)
JTH2: Ref. 0014107 (230V)
Handle for JTT
Ref. JT-A (100V / 120V / 230V)
Changing the JTT Heater Hose Set
Note: Only perform this operation when the
station is turned off.
Use a spanner to unscrew the nut (1) and
remove the tool hose from the control unit (2).
Insert the new hose, make
sure it is pushed all the way
into the connector (2), and
tighten the nut (1).
TC
Suction
OK
17:14
20
ºC
Power
45%
120ºC Selected
TC
Temp.
4m 38s
400
ºC
80
%
400ºC Selected
Protection
Hot Air Temp. Air Flow Selec.
TC
Suction
OK
JTT
TET
JT
TE
Use only with a 250V fuse
Employer uniquement avec
un fusible de 250V
TC
Suction
OK
TC
Suction
OK
17:14
20
ºC
Power
45%
120ºC Selected
TC
Temp.
4m 38s
400
ºC
80
%
400ºC Selected
Protection
Hot Air Temp. Air Flow Selec.
TC
Suction
OK
JTT
TET
JT
TE
Use only with a 250V fuse
Employer uniquement avec
un fusible de 250V
TC
Suction
OK
1313
40 mm
50 mm
60 mm
80 mm
100 mm
130 mm
130 mm
para manuales - color gris
200 mm
300 mm
Maintenance
Clean periodically
Before carrying out maintenance, always allow the equipment to cool.
- Clean the station screen with a glass cleaner or a damp cloth.
- Use a damp cloth to clean the casing and the
tool. Alcohol can only be used to clean the
metal parts.
- Periodically check that the metal parts
of the tool and stand are clean so that
the station can detect the tool’s status.
- Periodically check all cables and tubes.
- Replace a blown fuse as follows:
1. Pull off the fuse holder and remove the
fuse. If necessary use a tool to lever it off.
2. Insert the new fuse into the fuse holder
and return it to the station.
- Replace any defective or damaged pieces. Use original JBC spare parts only.
- Repairs should only be performed by a JBC authorized technical service.
Fuse holder
Fuse holder
Fuse
