InJet ® 388 CRD TECHNICAL DATA SHEET www.dct.cleaning 5 metric units imperial units Power supply 400 V, 32A, 50Hz (3+N+PE) UL 400 V, 32A, 60Hz (3+N+PE) Pmax 12 kW 12 kW Connection to central air pressure Pipe Ø 6 mm Pipe…

100%1 / 8
InJet
®
388 CRD
TECHNICAL DATA SHEET
www.dct.cleaning
4
metric units imperial units
Dimensions (w x l x h) 1120 x 1360 x 2100 mm 44.1 x 53.5 x 82.7 in
Weight 420 kg 926 lbs
Ø energy consumption per cycle 2,5 kWh 2.5 kWh
Cleaning and rinsing uid consumption per cycle 0,05 – 0,3 L 1.28 - 10.24 ounces
Compressed air consumption per cycle 2 L / 5 Bar 0,53 gal /72,5 PSI
Max. dimensions of the cleaned parts 190 x 860 x 790 mm 7.48 x 33.9 x 31.1 in
Exchangeable mechanical lter
of cleaning and rinsing uid
5 - 200 μm 5 - 200 μm
Spraying pressure / 45 °C / 113 °F 2,4 bar 34,8 PSI
Cleaning uid ow rate 200 L / min 52.8 gal / min
Temperature range setting of the cleaning
and rinsing uid
From ambient temperature to 60 °C From ambient temperature to 140 °F
Conductivity range settings of the rinsing
uid in the tanks
0 – 2000 μS/cm *optional 0 – 2000 μS/cm *optional
Temperature range setting of the drying From ambient temperature to 80 °C From ambient temperature to 176 °F
Noise level < 70 dB < 70 dB
Device control PLC + 8.4“ touchscreen PLC + 8.4“ touchscreen
TECHNICAL PARAMETERS
DIMENSIONS MINIMUM SERVICE SPACE
AROUND THE MACHINE
2100 mm
82.7 in
1360 mm
53.5 in
1120 mm
44.1 in
600 mm
23.6 in
600 mm
23.6 in
600 mm
23.6 in
600 mm
23.6 in
open door
450 mm
17.7 in
InJet
®
388 CRD
TECHNICAL DATA SHEET
www.dct.cleaning
5
metric units imperial units
Power supply 400 V, 32A, 50Hz (3+N+PE) UL 400 V, 32A, 60Hz (3+N+PE)
Pmax 12 kW 12 kW
Connection to central air pressure Pipe Ø 6 mm Pipe ID 0.24 in
Recommended working pressure 5 Bar 72.5 PSI
Exhaust pipe diameter Ø 100 mm ID 3.94 in
Exhaust pipe capacity 380 m
3
/h 13400 ft
3
/h
Minimum liquid for rst ll 2 x 50 L 2 x 13,2 gal
Service space required around the device 600 mm 23.6 in
INSTALLATION REQUIREMENTS
BACK
VIEW
discharge of uids G1“
225 mm / 8.86 in
Ø 100 mm
ID 3.94 in
input air pressure 1x Ø6 mm
input air pressure 1 x ID 0.24 in
400 V, 32A, 50Hz (3+N+PE)
UL 400 V, 32A, 60Hz (3+N+PE)
490 mm
19.3 in
InJet
®
388 CRD
TECHNICAL DATA SHEET
www.dct.cleaning
6
1 process chamber, full automatic solution
100% closed loop uid system
2 arm rotation - uid powered - cleaning
2 arm rotation - uid powered - rinsing
Cleaning and rinsing uid heating
High-capacity mechanical ltration on all cycles
Hot air drying
Chimney ap - electronically controlled
Pneumatic door lock
Emergency stop button
Manipulation wheels - lockable
Electronic monitoring of the uid pressure
PLC controller + 8,4“ touchscreen
Spare parts (base kit)
STANDARD HARDWARE EQUIPMENT
Electronic monitoring of uid level
Electronic monitoring of uid pressure
Electronic cycle counter
3 level of logging - operator, maintenance, technician
1 process chamber - fully automatic solution
Spraying uid pressure - continuous measurement
Standard software language mutation - CZ, ENG
Liquid and lter replacement notication – cycle counting
Possibility of 5 programs - setting option
Smart warning - low or high pressure level
Smart warning - low uid level
STANDARD SOFTWARE EQUIPMENT
