InJet ® 388 CRD TECHNICAL DATA SHEET www.dct.cleaning 7 SW for CVA calculation ( android, machine ) Adjustable timer of cleaning uid heating Upgrade machine for PROTON 69 Language mutation (CZE, ENG, GER, POL, CHI, RUS,…
InJet
®
388 CRD
TECHNICAL DATA SHEET
www.dct.cleaning
6
1 process chamber, full automatic solution
100% closed loop uid system
2 arm rotation - uid powered - cleaning
2 arm rotation - uid powered - rinsing
Cleaning and rinsing uid heating
High-capacity mechanical ltration on all cycles
Hot air drying
Chimney ap - electronically controlled
Pneumatic door lock
Emergency stop button
Manipulation wheels - lockable
Electronic monitoring of the uid pressure
PLC controller + 8,4“ touchscreen
Spare parts (base kit)
STANDARD HARDWARE EQUIPMENT
Electronic monitoring of uid level
Electronic monitoring of uid pressure
Electronic cycle counter
3 level of logging - operator, maintenance, technician
1 process chamber - fully automatic solution
Spraying uid pressure - continuous measurement
Standard software language mutation - CZ, ENG
Liquid and lter replacement notication – cycle counting
Possibility of 5 programs - setting option
Smart warning - low or high pressure level
Smart warning - low uid level
STANDARD SOFTWARE EQUIPMENT
InJet
®
388 CRD
TECHNICAL DATA SHEET
www.dct.cleaning
7
SW for CVA calculation ( android, machine )
Adjustable timer of cleaning uid heating
Upgrade machine for PROTON 69
Language mutation (CZE, ENG, GER, POL, CHI, RUS, ITA, SPA, MAY, HUN)
Online access to cleaning device
and other equipment ...
OPTIONAL SOFTWARE EQUIPMENT
Joint liquid discharge - manual control
Automatic liquid rell
Automatic liquid discharge
Tanker 200 and 400 litres for operational liguid
1PR sandwich ltration - integrated
2PR sandwich ltration - integrated
Sandwich ltration - external
and other equipment ...
OPTIONAL HARDWARE EQUIPMENT
Mechanical table holder - stencil or PCB carrier frame
Mechanical carrier frame - PCB
Mechanical carrier frame - frameless stencils
Mechanical carrier frame - VectorGuard stencils
Mechanical carrier frame - squeegees
and other equipment ...
Traceability OFF line, CSV to SD card
Traceability OFF line, Reader, CSV to SD card
Traceability ON line, PC WIN, le
Traceability ON line, READER, PC WIN, le
Traceability ON line, PC WIN, OPC Server CD, no le
Traceability ON line, PC WIN, READER, OPC Server CD, no le
and other options ...
OPTIONAL ACCESSORY – FRAMES AND OTHERS
OPTIONAL TRACEABILITY
InJet
®
388 CRD
TECHNICAL DATA SHEET
DCT QUALITY
• main support frame
• storage tanks
• process chambers
• uid and air distribution systems
• spray arms and nozzles
• mechanical high-capacity lters
• process chamber door frame and handle
• external shielding
• active lters for rinsing DI water
STAINLESS
STEEL
DESIGN
100%
AISI
304/316
STAINLESS
STEEL
DESIGN:
Date of issue: October 2019
InJet
®
is a registration trademark of DCT Czech s.r.o.
DCT Czech s.r.o., Tovární 85, 679 21 Černá Hora, Czech republic
e-mail: info@dct.cleaning, www.dct.cleaning
EUROPEAN UNION
European Regional Development Fund
Operational Programme Enterprise
and Innovations for Competitiveness
For more information, a list of options
and a selection of suitable equipment,
please contact a DCT specialist in your
country or the manufacturer directly.
All of the InJet
®
, AirJet
®
and Sonix
®
cleaning systems
developed by DCT are characterised by the highest
quality on the market, high reliability, ease of use,
simple maintenance, an extremely long lifespan, and
the longest warranty on the cleaning system market.
These afore-mentioned benets are achieved
by the precise manual production of the machines
in the Czech Republic, and thanks to the superior quality
of the used materials and components.
Cleaning systems boast a unique all-stainless-steel
construction, which is welded manually from AISI 304
and AISI 316 stainless steel and then chemically passivated.
The cleaning systems are designed and manufactured
with a focus on ease of use by operators, simple
maintenance, and smart process parameter setting.
They are equipped with industrial PLC IDEC, a well
arranged colour touch display with 3-level access (operator,
maintenance, engineer), and with 5 adjustable cleaning
programmes as standard.
The device automatically and permanently checks all
processes, operating uid levels and process
temperatures, and also gives timely notication of the
need to replace individual consumables or uids.
Monitoring of the cleaning process history, whether
oine or online, is ensured by an optional traceability
function.
A wide range of standard hardware and software
equipment is available for every cleaning system.
However, DCT also excels by its exibility when
resolving non-standard machines and their accessories.
Our machines, together with our cleaning uids
and local application and technical support, bring
you a long-term reliable, powerful and stable
cleaning process, even under the most demanding
continuous operation conditions.
With all its cleaning systems, DCT oers a wide range
of hardware and software equipment, special frames
with hitches for the parts you want to clean, and countless
variants in addition to the basic process monitoring options
which use traceability.
