NETWORKING
CONNECTION TO A NETWORK SERVICE
22.6 Chapter Issue 1 Sep 02
CONNECTION TO A NETWORK SERVICE
Important Safety
Considerations
Whenever a machine is indirectly controlled eg, when using a network to control
its movements, there may be safety issues to consider. DEK printing machines
are fitted with several safety interlocks to protect operators and maintainers.
WARNING
SAFETY DEVICES. THE SAFETY FEATURES DESIGNED IN TO THE MACHINE
ARE FOR THE PROTECTION OF ALL OPERATOR AND MAINTENANCE
PERSONNEL. DEK STRONGLY RECOMMEND SAFETY DEVICES ARE NEVER
OVERRIDDEN.
In addition to the above warning and before operating the machinery remotely,
DEK recommend that adequate safety systems are in place to ensure that all
personnel are clear of the moving parts in the printer and any external machin-
ery which may be in partial or full control of the networked host.
Minimum System
Requirement
The minimum system requirement for the host PC is as follows:
• IBM Compatible PC (running Windows NT4 minimum)
• VDU with 800 x 600 Pixels (256 colours)
• Network (LAN for GEM) and/or Serial Port
(for RS232 Serial GEM [GS/GSX Only])
Operating
Environment
• Windows NT4 (supported by DEK)
NOTE
Where DEK Software for Productivity Tools eg, Remote Product Changeover,
Off-Line editor etc. are to be used, the installer must be logged on with
Administrator level access in order for the security key device driver software to
be installed.
NETWORKING
CONNECTION TO A NETWORK SERVICE
Chapter Issue 1 Sep 02 22.7
Hardware
Installation
An LAN RJ45 connector is available at the external services rear panel, this
connector provides the interface to the customer’s network. Connecting a cable
to the network is the only hardware installation requirement, however for some
applications it may be necessary to connect other devices eg, a barcode reader.
The network connection uses a Ethernet 10BaseT type the ‘T’ stands for twisted
pair, this arrangement enables transmission speed to 10Mb/s at a maximum
cable length of 100m.
Figure 22-4 External Services (Rear Panel Removed)
Item Description
1 6SK13 LAN RJ45
+
2
4
V
+24V
+
2
4
V
(
E
-
S
T
O
P
)
+
24
V
(E-
ST
O
P
)
+
1
2
V
+
12V
+
5
V
+5
V
D
O
W
N
L
I
N
E
R
E
A
D
Y
D
OWN
L
INE
READ
Y
R
S
2
3
2
R
S
23
2
D
O
W
N
L
I
N
E
DOW
N
LINE
U
P
L
I
N
E
UPL
IN
E
D
E
K
M
A
C
H
I
N
E
DEK
MACHINE
U
P
L
IN
E
R
E
A
D
Y
U
P
LIN
E
R
EADY
D
O
W
N
L
I
N
E
A
VA
I
L
A
B
L
E
D
O
W
NLINEA
VAI
LA
B
LE
S
E
N
D
D
O
W
N
L
I
N
E
SE
N
D
D
O
W
NL
IN
E
S
E
N
D
U
P
L
I
N
E
S
END
U
P
LI
NE
D
E
K
M
/
C
N
AV
A
I
L
A
B
L
E
D
E
K
M/CNAV
A
ILAB
L
E
M
U
L
T
I
-
I
N
T
E
R
F
A
C
E
U
N
I
T
M
ULTI
-
I
N
T
E
R
F
ACE
UN
I
T
F
R
O
M
D
E
K
M
A
C
H
I
N
E
FROM
D
EK
MA
C
HINE
+24V
+24V (E-STOP)
+12V
+5V
DOWNLINE READY
RS 232
DOWNLINE
UPLINE
DEK MACHINE
UPLINE READY
DOWNLINE AVAILABLE
SEND DOWNLINE
SEND UPLINE
DEK M/CN AVAILABLE
MULTI-INTERFACE UNIT
FROM
DEK
MACHINE
6SK13 Host Comms
LAN RJ45
NETWORKING
CONNECTION TO A NETWORK SERVICE
22.8 Chapter Issue 1 Sep 02
8 Way RJ45
Connector
Internally the LAN RJ45 connection is routed to 3SK02 card slot X13 of the PC
enclosure rear panel. The connections (to connector A) are shown below:
NOTE
The connection above is wired as DEK would recommend. It is possible that a
customer network connection may differ from the one shown, if a problem exists
in installation the connection at the customer network end of the cable may need
to be configured accordingly.
Pin No. Signal Pin No. Signal
1 +ve Transmit 5 Not Used
2 -ve Transmit 6 -ve Receive
3 +ve Receive 7 Not Used
4 Not Used 8 Not Used
BN
BN
W/
BN
W/
BN
O
O
W/
O
W/
O
G
G
W/
G
W/
G
BL
BL
W/
BL
Pin 1
Connector A (Pin View)
Connector B (Pin View)
Connection Diagram for Reverse RJ - 45 Cable
Pin 1
W/
BL
