1. Introduction
Thetargetmodelandversionareasfollows.
Table1.1Targetmodelandversion
Itemname Object Remarks
Targetmodel YS24(DL),YS24X(DL)
Targetversion V3.26STDR1.000orlater(Mounter)
2. Outline of functions
“BoardDataChangewithoutStopFunction”hasbeenadded.
Beforethisfunctionadded,inthecaseofthechangingtheboarddata,itwasnecessarytomake
wholemachinetheRESETstate.Fromthisversion,youcanchangetheboarddataononelane
whiletheotherlanecontinuesproducing.Thissavestimestoppingthemachineforchangingthe
boarddata,andtheoperationratioofthemachineimproves.
Thisfunctionisactivewhenthemountmodeis“ParallelLanes”.
3. Limitation
• LaneSelectSwitchisnecessarytobeattached.
TheretrofitkittoattachLaneSelectSwitch
KKEM86B0000“SEL,RETROFITKIT”…forfeedercartmachines
KKEM86B1000“SEL,RETROFITKIT”…forfixedfeederbankmachines
• ThisfunctionisavailableonlywithDualLaneSystem“TypeN”installed.
• WhenthisfunctionisusedwiththeAutomaticProgramChangeoverfunction(Op003),
thecombinedboarddata(CYGX)isnotavailable.
Tousethecombinedboarddata,pleaseinvalidatethisfunction(SeeChapter.4).
SMT Software Engineering Group
IMOperationsYAMAHAMOTORCO.,LTD.
MDOC-SOFT50119
3/8
4. Setting method
4.1 Setting at “Machine”
Set[Machine]–[MachineInformation]–[OptionSetting]–[DetailSetting]–[BoardDataChange
withoutStop]to“ON”(seeFig4.1).
Fig4.1[DetailSetting]screen
SMT Software Engineering Group
IMOperationsYAMAHAMOTORCO.,LTD.
MDOC-SOFT50119
4/8
5. Operation Method of Changing Board Data
5.1 Change in the whole lane state is RESET
Thereisnochangeintheboarddatachangingmethodinthestateofwholelanereset.
5.2 Change in the one side lane state is RUNNING
Resetalanewhichyouwanttochangeitsboarddata,andselectthenewonefromtheBoard
data select screen. You can select the board data even while the other lane is running (see
Fig.5.1).
Fig5.1[Boarddataselect]screen
Boarddataselectisavailableevenwhentheotherlaneisrunning.
Boarddataisselectableonlyonthelaneinaresetstate.
